Teknion Navigate height-adjustable bench Manual page 190

height-adjustable bench
Section: SCREENS AND GABLES
ITEM
PREVIEW
NO.
2.4
2.5
2.6
2.7
2.8
2.9
2.10
Part & Product Identification
PART
DESCRIPTION
NUMBER
SIDE COVER FOR MID
C07-
GABLE, SINGLE
4718AL\30
SIDED, HAB
FRONT COVER FOR
C05-8864
MID GABLE, HAB
HANGING BRACKET,
FOR WOOD MID A16-3203
GABLE, HAB
BOTTOM
CONNECTING BRKT
A16-3026
FOR WOOD MID
GABLE, HAB
FRONT HANGING
BRKT FOR WOOD MID A16-3028
GABLE, HAB
BOTTOM BRKT FOR
WOOD MID GABLE, A16-3027
HAB
MID GABEL BOTTOM
ANGLE BAR, SINGLE A16-7572\30
SIDED, HAB
Installation Guides
ITEM
QTY. PREVIEW
NO.
2.11
1
2.12
2
2.13
2.14
2
2.15
4
2.16
1
2
2.17
2
2.18
Date: Sept 2019
HABN_225e
PART
DESCRIPTION
NUMBER
GABLE CONNECTING
A16-3651
PLATE
COVER PLATE FOR
A16-3689
CABLE CUTOUT, HAB
BACK HANGING
BRKT FOR WOOD MID
A16-7573
GABLE, SINGLE
SIEDED, HAB
HANGING BRACKET,
FOR WOOD MID
A16-7569R
GABLE, SINGLE
SIDED, HAB
HANGING BRACKET,
FOR WOOD MID
A16-7569L
GABLE, SINGLE
SIDED, HAB
1/4-20 UNCx0.500"
2A,CROSS/SQ.COMB.S
E01-0110
OCK.,TRS.HEAD,MAC
H.SCR.,STEEL,ZN
#10X1/2" TAP SCR,
E01-0023
QUAD,PAN
SCREW, WOOD,#6 X
7/16", DEEP THREAD, E04-0050
QUAD, TRUSS
Page: 3 of 10
QTY.
4
2
1
1
1
12
4
4
