height-adjustable bench
FRAMES AND WORKSURFACES
Section:
Description: SINGLE SIDED HA FRAME
A1 - Navigate HAB Leg
OR
Assy
(N09-8583L) x1
A2 - Navigate HAB Leg
Assy
OR
(N09-8583R) x1
A3 - Navigate Cross
Beam
(A16-6481) x1
A5 - Single Sided Bench
Rear Leg Assy
(N09-8573L) x1
A7 - Navigate Strut
(A25-0630) x2
A9 - Control Cover
(B02-0739) x1
Part and Product Identification
Navigate Single Sided Std. Range Electric Frame (HNBFNZ)x1
A - Frame Assembly (N09-9082) x1 or (N09-9070) x1
Navigate HAB Leg
Assy, Extended
A11 - Leg Top Cap
(N09-8585_L) x1
(A25-0668) x2
Navigate HAB Leg
A15 - Navigate Digital
Assy, Extended
Switch
(N09-8585_R) x1
(N09-8183) x1
A19 - Motor Cable
A4 - HAB Stretcher PVC -500 mm
Assembly
(N09-8402\05) x0 or x1 or x2
(N09-8606) x2
A22a - Screw 1/4-20x5/8,
A6 - Single Sided Bench
A22d - M5x0.8-10, Flat
Rear Leg Assy
(N09-8573L) x1
A22g - Flat Quad Wd
A8 - Navigate Strut
Cover
(A25-0631) x2
A10 - Navigate Control
Module
(N09-8185) x1
Installation Guides
A12 - Counter Weight
(A25-7750) x0 or x8
OR
A16 - Navigate Simple
Switch
(N09-8192) x1
A20 - Motor Cable
PVC -1000mm
(N09-8402\10) x0 or x1
A22 - Hardware Kit (X05-0478)x1
QD MCHN
(E01-0992) x12
Head Screw
(E01-0989) x4
Screw
(E04-0090) x9
A22j - Linak Memory 90
Deg Mounting Brkt
(A16-3970) x1
A13 - Counter Weight,
Tall 1/2"
(A16-13119) x0 or x8
OR
A17 - Display Switch w/
Up/Down Memory
(N09-5600)x1
A21 - Motor Cable
A22b - M6x1, 14mm Flat
Head Screw
(E01-1249) x16
A22e - 3/16" Wire Clamp
(B02-0598) x4
A22h - #10 Pan Quad Screw
(E01-1009) x2
A22k - Wd Screw Pan
Quad #8x5/8"
(E04-0091) x2
Date: Sep 2024 Page No: 2 of 14
HABN_124 Rev. No: 3
A14 - Counter Weight,
Tall 1/8"
(A16-13121) x0 or x2
OR
A18 - Linak Up/Down
Switch
(N09-5796) x1
PVC -2000mm
(N09-8402\20) x0 or x1
A22c -Machine Screw 5/16-18 x
3/4, Socket Screw
(E01-1035) x4
A22f - Cable Clamp 3/8"
(B02-0558) x5
A22i - Grommet Bushing
(B02-0557) x2
A22l - #8x1 1/4" Wd Screw
(E04-0074) x2
