Teknion Navigate height-adjustable bench Manual page 136

height-adjustable bench
Section: SCREENS & GABLES
ITEM NO.
1.1
1.2.1
1.2.2
1.2.3
2.1
2.2
2.3
2.4
Part & Product Identification
PREVIEW
1. Navigate End of Run Fabric Screen. (HNBTEF) x1
1.2. FABRIC END SCREEN MOUNTING BRKT KIT, DOUBLE SIDED, HAB (X06-0620) x1
1/4-20X5/8" MACH SCR, BLACK, QUAD,TRUSS
2. NAVIGATE END SCREEN GABLE - METAL (HNBCGSMN) x1
TOP COVER FOR END SCREEN GABLE, HNB
Installation Guides
DESCRIPTION
NAVIGATE END OF RUN FABRIC SCREEN
END SCREEN BRKT ASSY, INNER, HAB
END SCREEN BRKT, OUTER, HAB
INSIDE COVER ASSY END SCREEN GABLE
#10X1/2" TAP SCR, QUAD,PAN
GABEL CONNECTING PLATE
Date: Sept 2019 Page: 2 of 6
HABN_223e
PART NUMBER QTY.
HNBTEF 1
N09-9090 2
A16-7728 2
E01-0113 12
A16-7651-X 1
N09-9124-X 1
E01-0023 2
A16-3651 2
Rev. 01
