Teknion Navigate height-adjustable bench Manual page 219

height-adjustable bench
Section: SCREENS AND GABLES
Description: SCREEN ACCESSORIES
POSITION ALIGNMENT COVER
A2
STEP 1: Position Alignment Cover to the Top edge of the Screen.
Installation Guides
B2
STEP 2: Align the Alignment Bracket to the Bottom Edge of the Cover, use the Alignment
Cover as Clearance.
ALIGN BRACKET
NOTE: Use the Gap created by the
Alignment cover as the Clearance.
B1
Date: Sept 2020 Page No: 2 of 4
HABN_226
A1
B1
