height-adjustable bench
Section:
SOLID GABLES & CABLE CHANNEL
NOTE: Parts of the Frames are
hidden for Illustartion Pupose.
STEP 17a: If Mid Gable Power Pole is specified. Attach Top Covers onto the Highlighted extrusions on the Side and Front Cover assemblies as shown.
Repeat Step 1-15 Install End Gable and Cable Channel on another side of the Table.
TOP COVER W/ POWER POLE CUTOUT (OPTIONAL)
3.4
Installation Guides
NOTE: Parts of the Frames are
hidden for Illustartion Pupose.
3.4
Date: Feb 2022
Page: 16 of 18
HABN_223b
