SCREENS AND GABLES
HABN_225d
ATTACH CONNECTING PLATES TO FRAME LEGS
MOUNT INSIDE COVER
1.1
1.4
STEP 1: Loosen Leg Hex Bolt to attach Gable Connecting Plates to Frame leg. Then, Fasten
STEP 2:Mount Inside Cover Assembly onto Frame Stretcher Bar.
the Hex Bolt.
