height adjustable bench
Section:
FRAMES & WORKSURFACE
ATTACH BOTTOM BRACKET TO HAB FRAME
Stretcher Bar :
HAB Frame
5
STEP 3: Align Bottom Bracket & HAB Frame Stretcher Bar holes. Slide Bottom Bracket up
& fasten it to HAB Frame Stretcher Bar with Mach Screws provided
Installation Guides
NOTE: Make sure to level both
Frames before tightening the
system link nuts
1
2
STEP 4: Fully tighten Top Bracket Nuts to secure Bottom Bracket in place.
TIGHTEN BRACKET NUTS
4
Date: May 2019
Page: 4 of 5
HABN_122
