Teknion Navigate Single-Sided Frame HNBFNZ Assembly Instructions Manual

Height-adjustable bench
Hide thumbs Also See for Navigate Single-Sided Frame HNBFNZ:
Table of Contents

Advertisement

Quick Links

Download this manual
height-adjustable bench - Navigate
INDEX
By Section
Product
Product Name
Code
INSTALLATION SUPPORT DOCUMENTS
Typical Installation Sequence
NAVIGATE
FRAMES AND WORKSURFACE
Navigate Frame
HNBFNA
Navigate Frame Link
HNBFNF
Navigate Rectangular Worksurface
HNBWRN
Navigate Systems Link
HNBFNS
Navigate 120 Frame
HNBFNT
Navigate 120 Worksurface
HNBWTN
Navigate Wire Channel
HNBFCN
Navigate Power Module
HNBEPM
Navigate E-Chain Vertical Cable ManagerHNBEEE
Navigate Power Pole
HNBEPP
Navigate 120 Mid Gable
HNBCGMMT
Navigate Ceiling Feed
HNBECF
Navigate Single-Sided Frame
HNBFNZ
Navigate Single-Sided Rectangular
HNBWES
Extended Worksurface
Navigate Single-Sided Rectangular
HNBWRS
Worksurface
SCREENS AND GABLES
Navigate Desk Edge Screen - Glass
HNBCDG
Navigate Desk Edge Screen - Solid
HNBCDS
Navigate Desk Edge Screen - Fabric
HNBCDF
Navigate Fixed Center Screen - Glass
HNBCFG
Navigate Fixed Center Screen - Solid
HNBCFS
Navigate Fixed Center Screen - Fabric
HNBCFF
Navigate Cable Channel
HNBFCN
Navigate End Gable - Metal
HNBCGEMN
Navigate Mid Gable - Metal
HNBCGMMN
Navigate Cable Channel
HNBFCN
Navigate Mid Gable - Solid
HNBCGMSN
Navigate End Gable - Solid
HNBCGESN
Navigate End Cover - Metal
HNBCCEMN 223c
Navigate Mid Cover - Metal
HNBCCMMN
Navigate End Screen Cover - Metal
HNBCCSMN 223d
Navigate End of Run Screen - Fabric
HNBTEF
January 2020
*Click on the desired Installation Guide to jump to the Guide
page.
Guide
Last
No.
Updated
Product Name
Navigate End Cover - Metal
Sep 2018
Navigate Mid Cover - Metal
Navigate End Screen Cover - Metal
Navigate End of Run Screen - Fabric
121
Jan 2020
Navigate End Screen Gable - Metal
Navigate End of Run Screen - Fabric
Navigate Single-Sided Corridor Screen - HNBLSF
122
May 2019
Fabric
May 2020
123
Navigate Single-Sided Corridor Screen - HNBLSS
Solid
Navigate 120 Mid Cover
Navigate Single-Sided End Cover - Metal HNBCCEMS 225a
Navigate Single-Sided Mid Cover - Metal
Navigate Single-Sided End Screen
Cover - Metal
Navigate Single-Sided End of Run
124
Jan 2020
Screen - Fabric
Navigate Single-Sided End Screen
Gable - Metal
Navigate Single-Sided End of Run
Screen - Solid
Navigate Single-Sided End Gable - Metal HNBCGEMS 225d
221a
May 2019
Navigate Single-Sided Mid Gable - Metal HNBCGMMS
221b
May 2019
Navigate Single-Sided End Gable - Solid HNBCGESS 225e
221c
May 2019
Navigate Single-Sided Mid Gable - Solid HNBCGMSS
222a
Sep 2019
Navigate Single-Sided Transition Mid
222b
Sep 2019
Gable - Metal
222c
Sep 2019
Navigate Single-Sided Transition Mid
223a
Sep 2019
Gable - Solid
ELECTRICS
Navigate Power Harness
223b
Sep 2019
Navigate Chicago Power Module
Navigate Power Module
Navigate Receptacle Outlet
May 2019
Navigate I-Connector
Navigate Chicago Power Module
Aug 2019
Navigate Single-Sided Chicago Power
Module
Product
Guide
Last
Code
No.
Updated
Product Name
HNBCCEMN 223c
May 2020
Navigate Base Feed
Navigate Base Feed Cover
HNBCCMMN
May 2020
HNBCCSMN 223d
Navigate Chicago Base Feed
Navigate Split Base Feed
HNBTEF
HNBCGSMN 223e
Sep 2019
Navigate Ceiling Feed
Navigate Chicago Ceiling Feed
HNBTEF
224
Sep 2019
Navigate Power Pole - End
Navigate Ceiling Feed
Navigate Chicago Ceiling Feed
Navigate Power Pole - Mid
HNBCCMMT 224a
May 2019
Navigate Power Pole(Single Sided Bench) HNBEPP
Sep 2019
Navigate Power Conservation System
Navigate Single-Sided Chicago Power
HNBCCSMS 225b
Sep 2019
Module
Center Electrical Grommet
HNBTSF
HNBCGSMS 225c
Sep 2019
HNBTSS
Sep 2019
Sep 2019
HNBCGMMR 225f
Sep 2019
HNBCGMSR 225g
Sep 2019
321a
Sep 2019
HNBEPH
HNBEPMCH
HNBEPM
HNBERO
HNBEIC
HNBEPMCH 321b
Sep 2019
HNBEPSCH
Product
Guide
Last
Code
No.
Updated
321c
Sep 2019
HNBEBF
HNBEBC
HNBEBFCH
HNBEBFS
322a
Sep 2019
HNBECF
HNBECFCH
HNBEPP
322b
Sep 2019
HNBECF
HNBECFCH
HNBEPP
323
May 2019
HNBEPC
HNBEPSCH 324
Sep 2019
325
Sep 2019
HNBECEG
PAGE 1 OF 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Navigate Single-Sided Frame HNBFNZ and is the answer not in the manual?

Questions and answers

Related Manuals for Teknion Navigate Single-Sided Frame HNBFNZ

Summary of Contents for Teknion Navigate Single-Sided Frame HNBFNZ

  • Page 1 height-adjustable bench - Navigate INDEX *Click on the desired Installation Guide to jump to the Guide By Section page. Product Guide Last Product Guide Last Product Guide Last Product Name Code Updated Product Name Code Updated Product Name Code Updated INSTALLATION SUPPORT DOCUMENTS Navigate End Cover - Metal HNBCCEMN 223c...
  • Page 2 height-adjustable bench Installation Guides Date: Jan 2020 Page: 1 of 19 Section: FRAMES AND WORKSURFACES HABN_121 Rev. Navigate Single-Sided Frame (HNBFNZ), Navigate Single-Sided Rectangular Extended Worksurface (HNBWES) NOTE: Refer to COM_151a for Cable Organizer installation NOTE: Refer to COM_151b for Plastic Tray Cable Management...
  • Page 3 height-adjustable bench Installation Guides Date: Jan 2020 Page: 2 of 19 Section: FRAMES AND WORKSURFACES HABN_121 Part & Product Identification ITEM ITEM PREVIEW DESCRIPTION PART NUMBER QTY. PREVIEW DESCRIPTION PART NUMBER QTY. 1. NAVIGATE STANDARD RANGE ELECTRIC FRAME (HNBFNA) NAVIGATE STRUT ALU A25-0630\23 CAST 23 LEG ASSY, STD RANGE...
  • Page 4 height-adjustable bench Installation Guides Date: Jan 2020 Page: 3 of 19 Section: FRAMES AND WORKSURFACES HABN_121 Part & Product Identification ITEM ITEM PREVIEW DESCRIPTION PART NUMBER QTY. PREVIEW DESCRIPTION PART NUMBER QTY. (P-2184) 2. NAVIGATE SINGLE SIDED - HARDWARE KIT (X05-0498) x2 GROMMET BUSHING, B02-0557...
  • Page 5 height-adjustable bench Installation Guides Date: Jan 2020 Page: 4 of 19 Section: FRAMES AND WORKSURFACES HABN_121 Part & Product Identification ITEM ITEM PREVIEW DESCRIPTION PART NUMBER QTY. PREVIEW DESCRIPTION PART NUMBER QTY. MOTOR CABLE PVC N09-8402\05 FREE, 500MM MOTOR CABLE PVC N09-8402/10 FREE, 1000MM NAVIGATE...
  • Page 6 height-adjustable bench Installation Guides Date: Jan 2020 Page: 5 of 19 Section: FRAMES AND WORKSURFACES HABN_121 INSTALL HEIGHT-ADJUSTABLE LEGS STEP 1: Slide Height-Adjustable Legs into the Cross Beam as shown above.
  • Page 7 height-adjustable bench Installation Guides Date: Jan 2020 Page: 6 of 19 Section: FRAMES AND WORKSURFACES HABN_121 FASTEN SCREWS TO SECURE LEGS STEP 2: Fasten Screws to secure Legs to Top Channel.
  • Page 8 height-adjustable bench Installation Guides Date: Jan 2020 Page: 7 of 19 Section: FRAMES AND WORKSURFACES HABN_121 REPEAT STET 1 TO STEP 2 ATTACH STRETCHER BAR TO LEGS STEP 3: Repeat Step 1 and Step 2, for the other Leg Assembly. STEP 4: Attach Stretcher Bar to Legs as shown above, with screws provided.
  • Page 9 height-adjustable bench Installation Guides Date: Jan 2020 Page: 8 of 19 Section: FRAMES AND WORKSURFACES HABN_121 ATTACH STRUTS TO ALL LEG ASSEMBLIES STEP 5: Attach Struts to all Leg Assemblies.
  • Page 10 height-adjustable bench Installation Guides Date: Jan 2020 Page: 9 of 19 Section: FRAMES AND WORKSURFACES HABN_121 ATTACH STRUT COVERS TO STRUTS STEP 6: attach Struct Covers to Struts installed with screws provided.
  • Page 11 height-adjustable bench Installation Guides Date: Jan 2020 Page: 10 of 19 Section: FRAMES AND WORKSURFACES HABN_121 INSTALL FRAME LINK (OPTIONAL) NOTE: Frame Link is not included with Frame. Must order Separately. STEP 7: Fasten Frame Link to one of the table frame Stretcher Bars first, as indicated. Bring over second frame, and attach Stretcher Bar to Frame Link as shown above.
  • Page 12 height-adjustable bench Installation Guides Date: Jan 2020 Page: 11 of 19 Section: FRAMES AND WORKSURFACES HABN_121 ATTACH POWER MODULE (OPTIONAL) ATTACH POWER MODULE COVER (OPTIONAL) STEP 8a: Attach Power Module as shown above. STEP 8b: Attach Power Module Cover as shown above.

  • Page 13: Wire Connection

    height-adjustable bench Installation Guides Date: Jan 2020 Page: 12 of 19 Section: FRAMES AND WORKSURFACES HABN_121 WIRE CONNECTION NOTE: Make sure that the dongle is connected to the Control Box. STEP 9: Connect all the wires...
  • Page 14 height-adjustable bench Installation Guides Date: Jan 2020 Page: 13 of 19 Section: FRAMES AND WORKSURFACES HABN_121 ATTACH WORKSURFACE TO FRAME STEP 10: Attach Worksurface to Frame with screws provided.
  • Page 15 height-adjustable bench Installation Guides Date: Jan 2020 Page: 14 of 19 Section: FRAMES AND WORKSURFACES HABN_121 ALIGN WORKSURFACES STEP 11: Align Worsurfaces as shown above.
  • Page 16 height-adjustable bench Installation Guides Date: Jan 2020 Page: 15 of 19 Section: FRAMES AND WORKSURFACES HABN_121 ATTACH SWITCH TO WORKSURFACE STEP 12: Attach Switch to Worksurface as shown above, with screws provided.
  • Page 17 height-adjustable bench Installation Guides Date: Jan 2020 Page: 16 of 19 Section: FRAMES AND WORKSURFACES HABN_121 ATTACH CABLE CLAMPS Rear View Front View 1.13.6 1.13.5 1.13.7 1.13.7 STEP 13: Using Wire/Cable Clips and screws, organize wires as shown above.
  • Page 18 height-adjustable bench Installation Guides Date: Jan 2020 Page: 17 of 19 Section: FRAMES AND WORKSURFACES HABN_121 ATTACH CONTROL BOX TO WORKSURFACE STEP 14: Attach Control Box to Worksurface with screws provided.
  • Page 19 height-adjustable bench Installation Guides Date: Jan 2020 Page: 18 of 19 Section: FRAMES AND WORKSURFACES HABN_121 ATTACH CONTROL BOX STEP 15: Attach Control Box Cover as shown above.
  • Page 20 height-adjustable bench Installation Guides Date: Jan 2020 Page: 19 of 19 Section: FRAMES AND WORKSURFACES HABN_121 CABLE ORGANIZER (OPTIONAL) PLASTIC TRAY CABLE MANAGEMENT (OPTIONAL) NOTE: Refer to COM_151a for Cable Organizer installation NOTE: Refer to COM_151b for Plastic Tray Cable Management STEP 16a: Refer to COM_151a for Cable Organizer.
  • Page 21 height adjustable bench Installation Guides Date: May 2019 Page: 1 of 5 Section: FRAMES & WORKSURFACE HABN_122 Rev. 1 NAVIGATE SYSTEMS LINK (HNBFNS) End Leg height- adjustable Bench (HAB) Frame IMPORTANT: The System Link is not intended to provide structural support to the Interpret Frame. Interpret Frame The System Link MUST ONLY be installed to Complete Interpret Frames with End Legs.
  • Page 22 height adjustable bench Installation Guides Date: May 2019 Page: 2 of 5 Section: FRAMES & WORKSURFACE HABN_122 Part & Product Identification ITEM NO. PREVIEW DESCRIPTION PART NUMBER QTY. SYSTEM LINK TOP BRKT SUB ASSY, HAB TO N09-5120 INTERPRET SYSTEM LINK BOTTOM BRACKET, HAB TO INTERPRET A16-3051 SYSTEM LINK COVER, HAB TO INTERPRET A16-3200...
  • Page 23 height adjustable bench Installation Guides Date: May 2019 Page: 3 of 5 Section: FRAMES & WORKSURFACE HABN_122 ATTACH TOP BRACKET TO INTERPRET FRAME PLACE BOTTOM BRACKET IN PLACE Center Beam Interpret Frame NOTE: DO NOT fully tighten nuts STEP 1: Using Interpret Frame Nuts, fasten Top Bracket to Center Beam of Interpret Frame, STEP 2: Place Bottomg Bracket in plscce by inserting Top Bracket studs into Bottom Bracket as shown.
  • Page 24 height adjustable bench Installation Guides Date: May 2019 Page: 4 of 5 Section: FRAMES & WORKSURFACE HABN_122 ATTACH BOTTOM BRACKET TO HAB FRAME TIGHTEN BRACKET NUTS Stretcher Bar : HAB Frame NOTE: Make sure to level both Frames before tightening the system link nuts STEP 3: Align Bottom Bracket &...
  • Page 25 height adjustable bench Installation Guides Date: May 2019 Page: 5 of 5 Section: FRAMES & WORKSURFACE HABN_122 ROUTE CABLES THROUGH SYSTEM LINK INSTALL FRAME LINK COVER UNDERSIDE VIEW OPTIONAL Connects to Interpret Connects to STEP 5: Route cables through System Link to electrically connect both systems STEP 6: Insert the Top Bracket hooks into the vertical slots on the System Link Cover and allow Cover to slide slightly down...
  • Page 26 height-adjustable bench Installation Guides Date: Jan 2020 Page: 1 of 25 Section: FRAMES AND WORKSURFACES HABN_123 Rev. 00 Navigate 120 Frame, Navigate 120 Worksurface NOTE: If YEYA is specified, refer to COM_151a NOTE: If YEYS is specified, refer to COM_151b...
  • Page 27 height-adjustable bench Installation Guides Date: Jan 2020 Page: 2 of 25 Section: FRAMES AND WORKSURFACES HABN_123 Part & Product Identification ITEM ITEM PREVIEW DESCRIPTION PART NUMBER QTY. PREVIEW DESCRIPTION PART NUMBER QTY. 1. NAVIGATE 120 FRAME (HNBFNT) NAVIGATE 120 HAB MID GABLE STRATCHER N09-8966 FRAME ASSY.
  • Page 28 height-adjustable bench Installation Guides Date: Jan 2020 Page: 3 of 25 Section: FRAMES AND WORKSURFACES HABN_123 Part & Product Identification ITEM PART ITEM PART PREVIEW DESCRIPTION QTY. PREVIEW DESCRIPTION NUMBER QTY. NUMBER Display Switch with NAVIGATE STRUT A25-0630-X Up/Down Memory N09-5600 ALU CAST 23 (55DPF1C00012016)
  • Page 29 height-adjustable bench Installation Guides Date: Jan 2020 Page: 4 of 25 Section: FRAMES AND WORKSURFACES HABN_123 Part & Product Identification ITEM PART ITEM PART PREVIEW DESCRIPTION NUMBER QTY. PREVIEW DESCRIPTION NUMBER QTY. (550105) 3/16” MOTOR WIRE CLAMP, CABLE PVC N09-8402\05 1.14.5 B02-0598 FREE, 500MM...
  • Page 30 height-adjustable bench Installation Guides Date: Jan 2020 Page: 5 of 25 Section: FRAMES AND WORKSURFACES HABN_123 Part & Product Identification ITEM ITEM PREVIEW DESCRIPTION PART NUMBER QTY. PREVIEW DESCRIPTION PART NUMBER QTY. (720025) WD SCREW 3. CABLE ORGANIZER, WITH FELT COVER - YEYA01 (OPTIONAL) 1.14.12 PAN QUAD #8x5/8"...
  • Page 31 height-adjustable bench Installation Guides Date: Jan 2020 Page: 6 of 25 Section: FRAMES AND WORKSURFACES HABN_123 Part & Product Identification ITEM PREVIEW DESCRIPTION PART NUMBER QTY. YEPD2A Bracket PB03-E007-01 #8-1/2 PAN, QUADREX, TYPE B FS8-5-8-PB WD SCREW PAN QUAD #12X7/8" BLACK E04-0087 OXIDE (720022) 5.
  • Page 32 height-adjustable bench Installation Guides Date: Jan 2020 Page: 7 of 25 Section: FRAMES AND WORKSURFACES HABN_123 LEVELLER ADJUSTMENT - 1 LEVELLER ADJUSTMENT - 2 STEP 1: Adjust the leveller to have a 0.5" gap STEP 2: Adjust the leveller to have a 0.5" gap...
  • Page 33 height-adjustable bench Installation Guides Date: Jan 2020 Page: 8 of 25 Section: FRAMES AND WORKSURFACES HABN_123 ASSEMBLE LEG AND MID GABLE STRATCHER ATTACH POWER POLE MOUNT (OPTIONAL) NOTE: For Mid Gable Assembly, refer to HABN_224b NOTE: For Power Pole Assembly, refer to HABN_324 1.14.3 STEP 3: Assemble Legs and Mid Gable Stratcher as shown above.
  • Page 34 height-adjustable bench Installation Guides Date: Jan 2020 Page: 9 of 25 Section: FRAMES AND WORKSURFACES HABN_123 ASSEMBLE CENTRE LEG TOP MOUNT 1.14.2 STEP 5: Assemble Centre Top Mount with screws provided.
  • Page 35 height-adjustable bench Installation Guides Date: Jan 2020 Page: 10 of 25 Section: FRAMES AND WORKSURFACES HABN_123 PLACE CROSS BEAM STEP 6: Place Cross Beam as shown above.
  • Page 36 height-adjustable bench Installation Guides Date: Jan 2020 Page: 11 of 25 Section: FRAMES AND WORKSURFACES HABN_123 FASTEN CROSS BEAM TO TOP MOUNT 1.14.2 STEP 7: Fasten Cross Beam with screws provided.
  • Page 37 height-adjustable bench Installation Guides Date: Jan 2020 Page: 12 of 25 Section: FRAMES AND WORKSURFACES HABN_123 PLACE LEG ASSEMBLIES STEP 8: Place Leg Assembly as shown above.
  • Page 38 height-adjustable bench Installation Guides Date: Jan 2020 Page: 13 of 25 Section: FRAMES AND WORKSURFACES HABN_123 FASTEN LEG ASSEMBLIES TO FRAME STEP 9: Fasten Leg Assembly with screws provided.
  • Page 39 height-adjustable bench Installation Guides Date: Jan 2020 Page: 14 of 25 Section: FRAMES AND WORKSURFACES HABN_123 ALIGN STRETCHER WELDMENT STEP 10: Align Stretcher Weldment as shown above.
  • Page 40 height-adjustable bench Installation Guides Date: Jan 2020 Page: 15 of 25 Section: FRAMES AND WORKSURFACES HABN_123 ATTACH STRETCHER WELDMENT 1.14.3 1.14.3 STEP 11: Assemble Stretcher Weldment with screws provided.
  • Page 41 height-adjustable bench Installation Guides Date: Jan 2020 Page: 16 of 25 Section: FRAMES AND WORKSURFACES HABN_123 ATTACH STRUTS TO FRAME 1.14.2 STEP 12: Attach Struts with screws provided.
  • Page 42 height-adjustable bench Installation Guides Date: Jan 2020 Page: 17 of 25 Section: FRAMES AND WORKSURFACES HABN_123 ATTATCH STRUT COVERS 1.14.4 STEP 13: Attach Strut Cover with screws provided as shown.

  • Page 43: Power Module (Optional)

    height-adjustable bench Installation Guides Date: Jan 2020 Page: 18 of 25 Section: FRAMES AND WORKSURFACES HABN_123 POWER MODULE (OPTIONAL) POWER MODULE COVER (OPTIONAL) STEP 14a: Attach Power Module as shown above STEP 14b: Attach Power Module Cover as shown above...

  • Page 44: Wire Connection

    height-adjustable bench Installation Guides Date: Jan 2020 Page: 19 of 25 Section: FRAMES AND WORKSURFACES HABN_123 WIRE CONNECTION See NOTE A NOTE: Wire Channel is hidden for Illustration Purpose 1.11 1.13 1.14.9 1.12 NOTE A NOTE: Make sure that the dongle is connected to the Control Box.
  • Page 45 height-adjustable bench Installation Guides Date: Jan 2020 Page: 20 of 25 Section: FRAMES AND WORKSURFACES HABN_123 WORKSURFACE AND SWITCH - 1 1.14.13 1.14.1 STEP 16: Place Worksurface on the Frame Assembly and fasten with screws provided. Place the Switch under the Worksurface and fasten with screws provided.
  • Page 46 height-adjustable bench Installation Guides Date: Jan 2020 Page: 21 of 25 Section: FRAMES AND WORKSURFACES HABN_123 WORKSURFACE AND SWITCH - 2 Reward: Align top and edges of all Worksurfaces STEP 17: Place Worksurface on the frame and align side edges and top surfaces with other Worksurfaces.
  • Page 47 height-adjustable bench Installation Guides Date: Jan 2020 Page: 22 of 25 Section: FRAMES AND WORKSURFACES HABN_123 WORKSURFACE AND SWITCH - 3 1.14.14 STEP 18: Fasten Worksurface with the Frame Assembly.
  • Page 48 height-adjustable bench Installation Guides Date: Jan 2020 Page: 23 of 25 Section: FRAMES AND WORKSURFACES HABN_123 CONTROL BOX COVER - 1 1.14.6 1.10 NOTE: Integrated power bars must be plugged into receptacles in the Navigate Wire Channel STEP 19: Fasten screws to the Control Modules as shown. Then, attach Control Box Cover.
  • Page 49 height-adjustable bench Installation Guides Date: Jan 2020 Page: 24 of 25 Section: FRAMES AND WORKSURFACES HABN_123 CONTROL BOX COVER - 2 1.10 STEP 20: Attach Control Box Cover.
  • Page 50 height-adjustable bench Installation Guides Date: Jan 2020 Page: 25 of 25 Section: FRAMES AND WORKSURFACES HABN_123 ATTACH FELT COVER CABLE ORGANIZER ATTACH DUAL PLASTIC TRAY CABLE MANAGEMENT NOTE: If YEYA is specified, refer to COM_151a NOTE: If YEYS is specified, refer to COM_151b STEP 21a: IF YEYA is Specified, Refer to Complement Guide Com151a STEP 21b: If YEYS is Specified, Refer to Complement Guide COM_151b.
  • Page 51 height-adjustable bench Installation Guides Date: Jan 2020 Page: 1 of 15 Section: FRAMES AND WORKSURFACES HABN_124 Rev. 0 Navigate Single-Sided Frame (HNBFNZ), Navigate Single-Sided Rectangular Extended Worksurface (HNBWES) 1.11...
  • Page 52 height-adjustable bench Installation Guides Date: Jan 2020 Page: 2 of 15 Section: FRAMES AND WORKSURFACES HABN_124 Part & Product Identification ITEM ITEM PREVIEW DESCRIPTION PART NUMBER QTY. PREVIEW DESCRIPTION PART NUMBER QTY. 1. NAVIGATE SINGLE-SIDED FRAME (HNBFNZ) SINGLE SIDE BENCH N09-8573L REAR LEG ASSY.
  • Page 53 height-adjustable bench Installation Guides Date: Jan 2020 Page: 3 of 15 Section: FRAMES AND WORKSURFACES HABN_124 Part & Product Identification ITEM PART ITEM PART PREVIEW DESCRIPTION QTY. PREVIEW DESCRIPTION QTY. NUMBER NUMBER M5 X 0.8 -10, FLAT 1.13.4 HEAD CAP E01-0989 SCREW (680214) COUNTER...
  • Page 54 height-adjustable bench Installation Guides Date: Jan 2020 Page: 4 of 15 Section: FRAMES AND WORKSURFACES HABN_124 Part & Product Identification ITEM ITEM PREVIEW DESCRIPTION PART NUMBER QTY. PREVIEW DESCRIPTION PART NUMBER QTY. 2. ELECTRICS MEMORY N09-5600 SWITCH PB-NAV-N09- 8157 POWER BAR PB-NAV-N09- 8737 NAVIGATE...
  • Page 55 height-adjustable bench Installation Guides Date: Jan 2020 Page: 5 of 15 Section: FRAMES AND WORKSURFACES HABN_124 Part & Product Identification ITEM PREVIEW DESCRIPTION PART NUMBER QTY. 3. NAVIGATE SINGLE SIDED WORKSURFACE HNBWES NAVIGATE EXTENDED RECTANGULAR WORKSURFACE, HAB HNBWRS...
  • Page 56 height-adjustable bench Installation Guides Date: Jan 2020 Page: 6 of 15 Section: FRAMES AND WORKSURFACES HABN_124 ATTACH LEGS TO CROSS BEAM FASTEN LEGS TO CROSS BEAM STEP 1: Attach Leg Assembly to Cross Beam as shown above. STEP 2: Fasten Leg Assembly to the Cross Beam with screws provided.
  • Page 57 height-adjustable bench Installation Guides Date: Jan 2020 Page: 7 of 15 Section: FRAMES AND WORKSURFACES HABN_124 ASSEMBLE STRUT ATTACH STRUT COVERS 1.13.4 1.13.2 STEP 3: Attach Struts as shown above with screws provided. STEP 4: Attach Strut Covers with screws provided.
  • Page 58 height-adjustable bench Installation Guides Date: Jan 2020 Page: 8 of 15 Section: FRAMES AND WORKSURFACES HABN_124 ASSEMBLE STRETCHER REMOVE COVER FROM LEG 1.13.3 STEP 5: Attach Stretcher to Frame as shown above. STEP 6: Remove covers from Counterbalance Legs.
  • Page 59 height-adjustable bench Installation Guides Date: Jan 2020 Page: 9 of 15 Section: FRAMES AND WORKSURFACES HABN_124 ADD WEIGHTS TO COUNTERBALANCE ATTACH STRETCHER BARS 1.10 STEP 7: Place Counterweights inside Counterbalance Leg. STEP 8: Attach Stretcher Bars to Legs...
  • Page 60 height-adjustable bench Installation Guides Date: Jan 2020 Page: 10 of 15 Section: FRAMES AND WORKSURFACES HABN_124 POWER BAR (OPTIONAL) POWER BAR COVER (OPTIONAL) STEP 9a: Attach Power Bar as shown above. STEP 9b: Attach Power Bar Cover as shown above.
  • Page 61 height-adjustable bench Installation Guides Date: Jan 2020 Page: 11 of 15 Section: FRAMES AND WORKSURFACES HABN_124 WIRE CONNECTION 1.12 1.13 NOTE: Make sure that the dongle is connected to the Control Box STEP 10: Connect all the wires as shown above.
  • Page 62 height-adjustable bench Installation Guides Date: Jan 2020 Page: 12 of 15 Section: FRAMES AND WORKSURFACES HABN_124 ATTACH WORKSURFACE TO THE FRAME 1.13.12 STEP 11: Place Worksurface on the Frame Assembly and fasten with screws provided. Attach the Switch under the Worksurface and fasten with screws.
  • Page 63 height-adjustable bench Installation Guides Date: Jan 2020 Page: 13 of 15 Section: FRAMES AND WORKSURFACES HABN_124 ATTACH CONTROL BOX COVER 1.13.8 1.11 STEP 12: Fasten screws to the Control Module as shown above. Then, attach Control Box Cover.
  • Page 64 height-adjustable bench Installation Guides Date: Jan 2020 Page: 14 of 15 Section: FRAMES AND WORKSURFACES HABN_124 ATTACH CABLE CLAMPS Rear View Front View 1.13.6 1.13.5 1.13.7 1.13.7 STEP 13: Using Wire/Cable Clips and screws, organize wires as shown above.
  • Page 65 height-adjustable bench Installation Guides Date: Jan 2020 Page: 15 of 15 Section: FRAMES AND WORKSURFACES HABN_124 CABLE ORGANIZER (OPTIONAL) PLASTIC TRAY CABLE MANAGEMENT (OPTIONAL) NOTE: Refer to COM_151b for Plastic Tray Cable Management NOTE: Refer to COM_151a for Cable Organizer installation STEP 14a: Refer to COM_151a for Cable Organizer STEP 14b: Refer to COM_151b for Dual Plastic Tray Cable Management...
  • Page 66 height-adjustable bench Installation Guides Date: May 2019 Page: 1 of 4 Section: SCREENS AND GABLES HABN_221a Rev. 0 DESK EDGE SCREEN - GLASS (HNBCDG)
  • Page 67 height-adjustable bench Installation Guides Date: May 2019 Page: 2 of 4 Section: SCREENS AND GABLES HABN_221a Part & Product Identification ITEM PART ILLUSTRATION DESCRIPTION QTY. NUMBER H01-1921-X 10mm CLEAR (CL) TEMPERED GLASS SCREEN, HAB 10mm FROST (FT) ETCHED TEMPERED GLASS SCREEN, H02-047-X H01-1868-X 6mm CLEAR (CL) TEMPERED GLASS SCREEN, HAB...
  • Page 68 height-adjustable bench Installation Guides Date: May 2019 Page: 3 of 4 Section: SCREENS AND GABLES HABN_221a SCREEN MOUNTING KIT ASSEMBLY MARK CENTRELINE STEP 1: Fasten Screen Bar Subassembly and Mounting Bracket to the Glass Screen STEP 2: Mark Centreline at the bottom of the Worksurface with pencil as shown. NOTE: If 48"...
  • Page 69 height-adjustable bench Installation Guides Date: May 2019 Page: 4 of 4 Section: SCREENS AND GABLES HABN_221a ATTACH & ALIGN SCREEN SECURE SCREEN Bottom View Detail View STEP 3: Attatch Mounting Bracket to the back of the Worksurface. Make sure the cut out of STEP 4: Fasten mounting Bracket to the underside of the Worksurface as shown.
  • Page 70 height-adjustable bench Installation Guides Date: May 2019 Page: 1 of 4 Section: SCREENS AND GABLES HABN_221b Rev. 0 DESK EDGE SCREEN - SOLID (HNBCDS)
  • Page 71 height-adjustable bench Installation Guides Date: May 2019 Page: 2 of 4 Section: SCREENS AND GABLES HABN_221b Part & Product Identification ITEM PART ILLUSTRATION DESCRIPTION QTY. NUMBER C05-8870-X DESK EDGE WOOD SCREEN, HAB X06-0339-X SOLID DESK EDGE SCREEN MOUNTING KIT, HAB A16-2959-X DESK EDGE SCREEN MOUNTING BRKT, HAB N09-5045-X...
  • Page 72 height-adjustable bench Installation Guides Date: May 2019 Page: 3 of 4 Section: SCREENS AND GABLES HABN_221b SCREEN MOUNTING KIT ASSEMBLY MARK CENTRELINE STEP 1: Fasten Screen Bar Subassembly and Mounting Bracket to the Screen STEP 2: Mark Centreline at the bottom of the Worksurface with pencil as shown. NOTE: If 48"...
  • Page 73 height-adjustable bench Installation Guides Date:May 2019 Page: 4 of 4 Section: SCREENS AND GABLES HABN_221b ATTACH & ALIGN SCREEN SECURE SCREEN STEP 3: Attatch Mounting Bracket to the back of the Worksurface. Make sure the cut out of STEP 4: Fasten mounting Bracket to the underside of the Worksurface as shown. he Bracket aligns with the marked Centreline.
  • Page 74 height-adjustable bench Installation Guides Date: May 2019 Page: 1 of 6 Section: SCREENS AND GABLES HABN_221c Rev. 0 DESK EDGE SCREEN - FABRIC (HNBCDF)
  • Page 75 height-adjustable bench Installation Guides Date: May 2019 Page: 2 of 6 Section: SCREENS AND GABLES HABN_221c Part & Product Identification ITEM PART ILLUSTRATION DESCRIPTION QTY. NUMBER N03-2735-X FABRIC DESK EDGE SCREEN SUB-ASSY - HAB X06-0338-X FABRIC DESK EDGE SCREEN MOUNTING KIT, HAB A16-2959-X DESK EDGE SCREEN MOUNTING BRKT, HAB 1/4-20 X 1"...
  • Page 76 height-adjustable bench Installation Guides Date: May 2019 Page: 3 of 6 Section: SCREENS AND GABLES HABN_221c SCREEN MOUNTING KIT ASSEMBLY INSERT WASHER & TIGHTEN BRACKET Side View STEP 1: Fasten Screen Bar Subassembly and Mounting Bracket to the Screen looseley. STEP 2: Insert Slotted Washers to Screws between Bracket and Fabric Frame, then Tighten the Screws fully.
  • Page 77 height-adjustable bench Installation Guides Date: May 2019 Page: 4 of 6 Section: SCREENS AND GABLES HABN_221c MARK CENTRELINE STEP 3: Mark Centreline at the bottom of the Worksurface with a pencil as shown.
  • Page 78 height-adjustable bench Installation Guides Date: May 2019 Page: 5 of 6 Section: SCREENS AND GABLES HABN_221c ATTACH & ALIGN SCREEN SECURE SCREEN Detail View Detail View STEP 4: Attatch Mounting Bracket to the back of the Worksurface. Make sure the cut-out of STEP 5: Fasten mounting Bracket to the underside of the Worksurface as shown.
  • Page 79 height-adjustable bench Installation Guides Date: May 2019 Page: 6 of 6 Section: SCREENS AND GABLES HABN_221c ATTACH SHIMS ATTACH SHIMS OPTIONAL OPTIONAL STEP 6a: Unmount the screen, attach Shims by the edge of the bracket as illustrated and STEP 6b: Unmount the screen and attach Shims on the screen's side of the bracket as reinstall Screen.
  • Page 80 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 8 Section: SCREENS AND GABLES HABN_222a Rev. 01 Fixed Centre Screen - Glass (HNBCFG)
  • Page 81 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 8 Section: SCREENS AND GABLES HABN_222a Part & Product Identification ITEM ILLUSTRATION PART NUMBER DESCRIPTION QTY. 10mm CLEAR (CL) TEMPERED GLASS, FULL STYLE, FIXED HEIGHT SCREEN, H01-1860-X 10mm FROST (FT) ETCHED TEMPERED GLASS, FULL STYLE, FIXED HEIGHT H02-0467-X SCREEN, HAB 2.
  • Page 82 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 8 Section: SCREENS AND GABLES HABN_222a INSERT CLAMP INTO CENTRE RAIL CLAMP LOCATIONS EQ = Eually Spaced FRONT VIEW MAX 27" MAX 27" NOTE: Make sure to USE ALL THE CLAMPS PROVIDED and space them as indicated on these drawings.
  • Page 83 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 8 Section: SCREENS AND GABLES HABN_222a INSERT SPRINGS LOCK CLAMP STEP 2: Insert Springs into the Clamps' slots. STEP 3: Use Allen Key to rotate Mounting Nuts and lock Clamps into Centre Rail.

  • Page 84: Install End Caps

    height-adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 8 Section: SCREENS AND GABLES HABN_222a INSTALL END CAPS INSERT RUBBER PADS AND SCREEN STEP 4: Insert both End Caps into Clamps STEP 5: Insert Rubber pads and Glass Screen into Clamps, as shown.
  • Page 85 height-adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 8 Section: SCREENS AND GABLES HABN_222a INSERT SPACERS SIDE VIEW STEP 6: Insert spacers as shwon, on one side first, in between the Rubber Pads and the Clamps. Insert remaining spacers on the other side...
  • Page 86 height-adjustable bench Installation Guides Date: Sept 2019 Page: 7 of 8 Section: SCREENS AND GABLES HABN_222a LOCK IN PLACE & LEVEL SCREEN (SIDE 1) LOCK IN PLACE & LEVEL SCREEN (SIDE 2) Opposite Side STEP 7a: Tighten Set Screws on both sides at the same time to make sure the Glass is located STEP 7b: Tighten Set Screws on both sides at the same time to make sure the Glass is located in the centre of the Clamps.
  • Page 87 height-adjustable bench Installation Guides Date: Sept 2019 Page: 8 of 8 Section: SCREENS AND GABLES HABN_222a INSTALL BOTTOM COVERS SIDE VIEW STEP 8: Mount Bottom Covers on both sides of Clamps. NOTE: Make sure Covers click on the springs.
  • Page 88 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 7 Section: SCREENS AND GABLES HABN_222b Rev. 01 Fixed Centre Screen - Solid (HNBCFS)
  • Page 89 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 7 Section: SCREENS AND GABLES HABN_222b Part & Product Identification PART ITEM NO. DESCRIPTION QTY. ILLUSTRATION NUMBER C05-8955-X WOOD PANEL, FULL STYLE, FIXED HEIGHT SCREEN, HAB 2. WOOD CLAMP SUB ASSY. (N09-3980) (SEE PAGE 3 FOR QTY) A25-0395 CLAMP, WOOD CASUAL SCREEN A25-0396...
  • Page 90 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 7 Section: SCREENS AND GABLES HABN_222b INSERT CLAMP INTO CENTRE RAIL CLAMP LOCATIONS EQ = Eually Spaced FRONT VIEW 27" MAX 27" MAX NOTE: Make sure to use all the clamps provided and space them as indicated on these drawings.
  • Page 91 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 7 Section: SCREENS AND GABLES HABN_222b INSERT SPRINGS LOCK CLAMP STEP 2: Insert Springs into the Clamps' slots. STEP 3: Use Alen Key to rotate Mounting Nuts and lock Clamps into Centre Rail.
  • Page 92 height-adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 7 Section: SCREENS AND GABLES HABN_222b INSTALL END CAPS FRONT SPACERS AND SCREEN STEP 4: Insert both End Caps into Clamps STEP 5: Insert front spacers and Screen into Clamps, as shown.
  • Page 93 height-adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 7 Section: SCREENS AND GABLES HABN_222b INSERT SPACERS SIDE VIEW STEP 6: Insert the remaining spacers spacers as shown on the remaining side.
  • Page 94 height-adjustable bench Installation Guides Date: Sept 2019 Page: 7 of 7 Section: SCREENS AND GABLES HABN_222b SECURE SCREEN INSTALL BOTTOM COVERS STEP 7: Secure Screen by tightening Set Screws as shown. STEP 8: Mount Bottom Covers on both sides of Clamps. NOTE: Make sure Covers click as they are pushed into place.
  • Page 95 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 6 Section: SCREENS AND GABLES HABN_222c Rev. 02 NAVIGATE FIXED CENTER SCREEN (HNBCFF)
  • Page 96 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 6 Section: SCREENS AND GABLES HABN_222c Part & Product Identification ITEM NO. PREVIEW DESCRIPTION PART NUMBER QTY. HNB FIXED CENTRE SCREEN - FRAMED FABRIC HNBCFFXX MOUNTING KIT (X03-0283) SCREEN MOUNTING PIN A18-0251 BUSHING - FABRIC SCREEN B02-0469...
  • Page 97 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 6 Section: SCREENS AND GABLES HABN_222c ASSEMBLE SUPPORT BRACKET INSERT ALLEN KEY STEP 1: Attach Mounting Pin, Support Bracket and Bushing as shown STEP 2: Insert Allen Key through the hole on the Mounting Pin...
  • Page 98 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 6 Section: SCREENS AND GABLES HABN_222c ATTACH SUPPORT BRACKETS ATTACH SCREEN STEP 3: Insert Mounting Pin into the holes inside the Fabric Screen STEP 4: Rotate Mounting Nuts parallel with the Center Rail Channel, then attach Fabric Screen into the Center Rail Channel...
  • Page 99 height-adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 6 Section: SCREENS AND GABLES HABN_222c TIGHTEN MOUNTING NUTS REMOVE ALLEN KEYS STEP 5: Rotate Allen Key to tighten Mounting Nuts STEP 6: Remove Allen Keys...
  • Page 100 height-adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 6 Section: SCREENS AND GABLES HABN_222c PRESS DOWN ON SCREEN SECURE SCREEN STEP 7: Press Fabric Screen down and make sure Frame is secured with Bushing STEP 8: Fasten Support Brackets with Fabric Screen with Screws provided...
  • Page 101 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a Rev. 01 Navigate End Gable - Metal (HNBCGEMN), Navigate Mid Gable - Metal (HNBCGMMN), Navigate Cable Channel (HNBFCN)
  • Page 102 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a Part & Product Identification ITEM PART ITEM PART PREVIEW DESCRIPTION PREVIEW DESCRIPTION NUMBER NUMBER 1. Navigate Wire Channel (HNBFCN) x1 1/4-20X5/8" MACH SCR, E01-0113 CABLE BLACK,...
  • Page 103 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a Part & Product Identification ITEM PART ITEM PART PREVIEW DESCRIPTION QTY. PREVIEW DESCRIPTION QTY. NUMBER NUMBER 3. Navigate Mid Gable - Metal (HNBCGMMN) x1 2.
  • Page 104 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a REMOVE SUPPORT BRACKETS NOTE: Make sure the Bolts do not come out of the assembly. STEP 1: Remove Support Brackets.
  • Page 105 height-adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a APPLY FOAM RUBBERS ATTACH SUPPORT BRACKET STEP 2: Attach Foam Rubbers onto the centre of the Table Legs' inner side. STEP 3: Insert Support Bracket through the cut-out on the Inside Cover Assembly as shown.
  • Page 106 height-adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a ATTACH CONNECTING PLATES TO FRAME LEGS MOUNT INSIDE COVER NOTE: Parts of the Frames are hidden for Illustration Purpose. Stretcher STEP 4: Loosen Legs Hex Bolt on both Legs to allow enought clearance for gable connecting STEP 5: Mount Inside Cover Assembly onto Frame Stretcher Bar.
  • Page 107 height-adjustable bench Installation Guides Date: Sept 2019 Page: 7 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a SECURE INSIDE COVER ASSEMBLY TO FRAME FASTEN INSIDE COVER IN PLACE STEP 6: Secure Inside Cover Assembly to Stretcher Bar with Bolts. STEP 7: Make sure the face of the Inside Cover Assembly is flush with the Leg.
  • Page 108 height-adjustable bench Installation Guides Date: Sept 2019 Page: 8 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a MOUNT OUTSIDE COVER ASSEMBLY Opposite side view STEP 8:Mount Outside Cover Assembly to the highlighted part of the Inside Cover Assembly as shown.
  • Page 109 height-adjustable bench Installation Guides Date: Sept 2019 Page: 9 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a MID POWER POLE SUPPORT PLATE (OPTIONAL) NOTE:Please refer to installation guide HABN_322b. Connecting Bracket 1/4-2, 5/8" Long Screw NOTE: Cable Channels are Hidden for Illustration Purpose. Optional: If Mid Power Pole is specified.
  • Page 110 height-adjustable bench Installation Guides Date: Sept 2019 Page: 10 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a ATTACH SUPPORT BRACKET SCREEN AND GABLES NOTE: Parts of the Frames are NOTE: Please refer to Specification Drawing hidden for Illustration Purpose. to mount the correct Side Cover Assembly STEP 9: Insert Support Bracket through the cut-out on the Side Cover Assembly.
  • Page 111 height-adjustable bench Installation Guides Date: Sept 2019 Page: 11 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a SECURE SIDE COVER ASSEMBLY CABLE CHANNEL ASSEMBLY NOTE:Install Cable Channel Cover Plate on Cable Channel Where E-Chain is not specified or unused location. NOTE: Electrics are not included with the Cable Channel.
  • Page 112 height-adjustable bench Installation Guides Date: Sept 2019 Page: 12 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a ATTACH CABLE CHANNEL & CENTER RAIL SECURE CABLE CHANNEL Underside View STEP 12: Align holes on Support Brackets, Cable Channel Assembly. Insert Bolts inside STEP 13: Secure Cable Channel in place with Nuts.
  • Page 113 height-adjustable bench Installation Guides Date: Sept 2019 Page: 13 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a ATTACH SUPPORT BRACKET MOUNT SIDE COVER ASSEMBLY STEP 14: Insert Support Bracket through the cut-out on the Side Cover Assembly. STEP 15: Mount Side Cover Assembly onto the Stretcher Bar as shown.
  • Page 114 height-adjustable bench Installation Guides Date: Sept 2019 Page: 14 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a SECURE SIDE COVER ASSEMBLY ATTACH MAGNET NOTE: Attach Magnets approximately to the locations to the legs NOTE: Parts of the Frame are hidden for Illustration Purpose.
  • Page 115 height-adjustable bench Installation Guides Date: Sept 2019 Page: 15 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a MOUNT FRONT COVER ASSEMBLIES NOTE: Legs are Hidden for Illustration Purpose. NOTE: Make sure Magnets are attached to the Legs. STEP 18: Mount Front Covers onto the Side Covers as shown in Detail View. Repeat this on the other side as well. NOTE: Make sure Magnets are attached to the legs...
  • Page 116 height-adjustable bench Installation Guides Date: Sept 2019 Page: 16 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a CABLE CHANNEL ASSEMBLY ATTACH TOP COVER NOTE: Parts of the Frames are hidden for Illustration Purpose. STEP 19: Align holes on Support Brackets, Cable Channel Assembly. Insert Bolts inside STEP 20: Attach Top Covers onto the highlighted extrusions on the Side and Front Cover Center Rail Extrusion through Cable Channel Assembly and Brackets as shown.
  • Page 117 height-adjustable bench Installation Guides Date: Sept 2019 Page: 17 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a TOP COVER WITH POWER POLE COUTOUT (OPTIONAL) NOTE: Only when Power Pole option is selected. STEP 21: If Mid gable Power Pole is Specified, attach Top Covers onto the hightlighted extrusions on the Side and Front Cover Assemblies as shown.
  • Page 118 height-adjustable bench Installation Guides Date: Sept 2019 Page: 18 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a CENTER RAIL EXTRUSION CAP STEP 22: Insert Center Rail Extrusion Caps onto Center Rail Extrusion as Shown.
  • Page 119 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 20 Section: SOLID GABLES & CABLE CHANNEL HABN_223b Rev.01 Navigate Mid Gable - Solid (HNBCGMSN), Navigate Cable Channel (HNBFCN), Navigate End Gable - Solid (HNBCGESN) 3.10 3.11...
  • Page 120 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 20 Section: SOLID GABLES & CABLE CHANNEL HABN_223b Part & Product Identification ITEM PART ITEM PART PREVIEW DESCRIPTION QTY. PREVIEW DESCRIPTION QTY. NUMBER NUMBER 1. Navigate Wire Channel (HNBFCN) x1 1/4-20X5/8"...
  • Page 121 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 20 Section: SOLID GABLES & CABLE CHANNEL HABN_223b Part & Product Identification ITEM PART ITEM PART PREVIEW DESCRIPTION PREVIEW DESCRIPTION NUMBER NUMBER 2. Navigate End Gable - Solid (HNBCGESN) x1 1/4-20 UNCx0.500"...
  • Page 122 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 20 Section: SOLID GABLES & CABLE CHANNEL HABN_223b Part & Product Identification ITEM PART ITEM PART PREVIEW DESCRIPTION QTY. PREVIEW DESCRIPTION QTY. NUMBER NUMBER FRONT HANGING BRKT 3. Navigate Mid Gable - Solid - Mid Condition (HNBCGMSN) x1 FOR WOOD MID GABLE, A16-3028 BOTTOM BRKT FOR...
  • Page 123 height-adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 20 Section: SOLID GABLES & CABLE CHANNEL HABN_223b Part & Product Identification ITEM PART ITEM PART PREVIEW DESCRIPTION QTY. PREVIEW DESCRIPTION QTY. NUMBER NUMBER 4. Navigate Wire Channel_Single Sided (HNBFCN_S) x1 5/16-18 HEX NUT, 1/2 A/F, E01-0755...
  • Page 124 height-adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 20 Section: SOLID GABLES & CABLE CHANNEL HABN_223b REMOVE SUPPORT BRACKETS STEP 1: Remove Support Brackets.
  • Page 125 height-adjustable bench Installation Guides Date: Sept 2019 Page: 7 of 20 Section: SOLID GABLES & CABLE CHANNEL HABN_223b ATTACH GABLE SUPPORT BRACKET ATTACH SUPPORT BRACKET STEP 2: Attach and Fasten Gable Brackets. STEP 3: Insert Support Bracket through the cut-out on the Inside Cover Assembly as shown.
  • Page 126 height-adjustable bench Installation Guides Date: Sept 2019 Page: 8 of 20 Section: SOLID GABLES & CABLE CHANNEL HABN_223b ATTACH CONNECTING PLATES TO FRAME LEGS MOUNT INSIDE COVER ASSEMBLY NOTE: Parts of the Frame are hidden for Illustration Purpose. Leveler Leg Hex Bolt STEP 4: Loosen Legs Hex Bolt on both Legs to allow enough clearance for gable connecting STEP 5: Mount Inside Cover Assembly onto Frame Stretcher Bar.
  • Page 127 height-adjustable bench Installation Guides Date: Sept 2019 Page: 9 of 20 Section: SOLID GABLES & CABLE CHANNEL HABN_223b SECURE INSIDE COVER IN PLACE SECURE INSIDE COVER ASSEMBLY TO FRAME STEP 6: Make sure the face of the Inside Cover Assembly is flush with the Leg. Secure Inside STEP 7: Secure Inside Cover Assembly to Stretcher Bar with Bolts.
  • Page 128 height-adjustable bench Installation Guides Date: Sept 2019 Page: 10 of 20 Section: SOLID GABLES & CABLE CHANNEL HABN_223b MOUNT OUTSIDE COVER ASSEMBLY NOTE: Parts of the Frame are hidden for Illustration Purpose. Section View Section View STEP 8:Mount Outside Cover Assembly to the highlighted part of the Inside Cover Assembly as shown.
  • Page 129 height-adjustable bench Installation Guides Date: Sept 2019 Page: 11 of 20 Section: SOLID GABLES & CABLE CHANNEL HABN_223b ATTACH CONNECTING PLATES TO FRAME Leg Hex Bolt 3.11 STEP 9: Loosen Hex Bolt to allow enough room for Gable Connecting Plate. Fasten Gable Connecting Plates to Frame Legs.
  • Page 130 height-adjustable bench Installation Guides Date: Sept 2019 Page: 12 of 20 Section: SOLID GABLES & CABLE CHANNEL HABN_223b MOUNT BOTTOM ANGLE BAR MID POWER POLE SUPPORT PLATE 3.12 3.10 Connecting Bracket 3.10 Hex Bolt 5/16" x1" Long ZP NOTE: Refer to installation Underside View 3.12 guide...
  • Page 131 height-adjustable bench Installation Guides Date: Sept 2019 Page: 13 of 20 Section: SOLID GABLES & CABLE CHANNEL HABN_223b ATTACH MID GABLE SUPPORT BRACKET MOUNT SIDE COVER ASSEMBLY NOTE: Parts of the Frame are hidden for Illustration Purpose. 3.14 3.15 3.13 NOTE: Please Refer to Specificstion Drawing to mount the correct side Cover Assembly.
  • Page 132 height-adjustable bench Installation Guides Date: Sept 2019 Page: 14 of 20 Section: SOLID GABLES & CABLE CHANNEL HABN_223b SECURE SIDE COVER ASSEMBLY CABLE CHANNEL ASSEMBLY NOTE:Install Cable Channel Cover Plate on Cable Channel Where E-Chain is not specified or unused location. NOTE: Electrics are not included with the Cable Channel.
  • Page 133 height-adjustable bench Installation Guides Date: Sept 2019 Page: 15 of 20 Section: SOLID GABLES & CABLE CHANNEL HABN_223b ATTACH CABLE CHANNEL & CENTER RAIL SECURE CABLE CHANNEL Underside View NOTE: Electrics Components to be installed on Cable Channel before connecting to support Bracket.
  • Page 134 height-adjustable bench Installation Guides Date: Sept 2019 Page: 16 of 20 Section: SOLID GABLES & CABLE CHANNEL HABN_223b MOUNT FRONT COVER ASSEMBLY Sectrion View STEP 16: Mount Front Covers onto the Frame Link and Bottom connecting Brackets.
  • Page 135 height-adjustable bench Installation Guides Date: Sept 2019 Page: 17 of 20 Section: SOLID GABLES & CABLE CHANNEL HABN_223b TOP COVER W/ POWER POLE CUTOUT (OPTIONAL) NOTE: Parts of the Frames are hidden for Illustartion Pupose. NOTE: Parts of the Frames are hidden for Illustartion Pupose.
  • Page 136 height-adjustable bench Installation Guides Date: Sept 2019 Page: 18 of 20 Section: SOLID GABLES & CABLE CHANNEL HABN_223b ATTACH TOP COVER NOTE: Parts of the Frames are Hidden for Illustration Purpose. 3.16 STEP 17b: Rest Top Covers onto Gable structures as Shown.
  • Page 137 height-adjustable bench Installation Guides Date: Sept 2019 Page: 19 of 20 Section: SOLID GABLES & CABLE CHANNEL HABN_223b CENTER RAIL EXTRUSION CAP STEP 18: Insert Center Rail Extrusion Caps onto Center Rail Extrusion as Shown.
  • Page 138 height-adjustable bench Installation Guides Date: Sept 2019 Page: 20 of 20 Section: SOLID GABLES & CABLE CHANNEL HABN_223b INSTALL CABLE CHANNEL (120 FRAME) INSTALL CABLEE CHANNEL (SINGLE SIDED FRAME) 120 Frame Single Sided Frame NOTE: Follow the similiar steps to Install Cable Channel onto the 120 Frame.
  • Page 139 height-adjustable bench Installation Guides Date: May 2019 Page: 1 of 4 Section: SCREENS & GABLES HABN_223c Rev. 01 Navigate End Cover - Metal (HNBCCEMN), Navigate Mid Cover - Metal (HNBCCMMN) Note: Mid Cover with Power Pole Cut-out is Shown as Example. For Cable Channel installation procedures, please refer to guide HABN_223a/223b...
  • Page 140 height-adjustable bench Installation Guides Date: May 2019 Page: 2 of 4 Section: SCREENS & GABLES HABN_223c Part & Product Identification ITEM NO. PREVIEW DESCRIPTION PART NUMBER QTY. END COVER, DOUBLE SIDED, HAB A16-7445-X MID COVER, DOUBLE SIDED, HAB A16-7446-X...
  • Page 141 height-adjustable bench Installation Guides Date: May 2019 Page: 3 of 4 Section: SCREENS & GABLES HABN_223c PLACE END COVER & BRACKET ON FRAME BAR SECURE END COVER IN PLACE Note: Support Bracket ships with Cable Channel. For Cable Channel installation procedures, please refer to guide HABN_223a/223b STEP 1: Slide Cable Channel Support Bracket into End Cover, making sure holes align.
  • Page 142 height-adjustable bench Installation Guides Date: May 2019 Page: 4 of 4 Section: SCREENS & GABLES HABN_223c PLACE MID COVER ON STRETCHER BARS SECURE MID COVER IN PLACE Note: For Cable Channel installation procedures, please refer to guide HABN_223a/223b STEP 3: Place Metal Mid Cover on top of Stretcher Bars and Cable Channel Support STEP 4: Use Screws provided with Support Brackets to secure Metal Mid Cover in place.
  • Page 143 height-adjustable bench Installation Guides Date: Aug 2019 Page: 1 of 5 Section: SCREENS & GABLES HABN_223d Rev. 01 Navigate End Screen Cover - Metal (HNBCCSMN), Navigate End of Run Screen (HNBTEF) 1.2.1 1.2.2...
  • Page 144 height-adjustable bench Installation Guides Date: Aug 2019 Page: 2 of 5 Section: SCREENS & GABLES HABN_223d Rev. 01 Part & Product Identification ITEM NO. PREVIEW DESCRIPTION PART NUMBER QTY. 1. Navigate End of Run Fabric Screen (HNBTEF) x1 NAVIGATE END OF RUN FABRIC SCREEN HNBTEF-X 1.2.
  • Page 145 height-adjustable bench Installation Guides Date: Aug 2019 Page: 3 of 5 Section: SCREENS & GABLES HABN_223d ATTACH BRACKETS TO SCREEN ATTACH BRACKETS TO FRAME NOTE: Ensure the Screen is leveled. 1.2.3 1.2.2 1.2.3 1.2.1 STEP 1: Attach Outer Brackets to Screen using Screws provided. STEP 2: Attach Inner Brackets to Frame using Screws provided.
  • Page 146 height-adjustable bench Installation Guides Date: Aug 2019 Page: 4 of 5 Section: SCREENS & GABLES HABN_223d ATTACH SCREEN TO FRAME PLACE END COVER & BRACKET ON FRAME BAR NOTE: Support Bracket ships with Cable Channel. For Cable Channel installation procedures, please refer to guide HABN_223a/223b 1.2.2 1.2.1...
  • Page 147 height-adjustable bench Installation Guides Date: Aug 2019 Page: 5 of 5 Section: SCREENS & GABLES HABN_223d INSTALL END COVER PLACE TOP COVER IN POSITION NOTE: Parts of the Frame are hidden for Illustration purpose. STEP 5: Secure Inside Cover in place using Support Bracket screws STEP 6: Place Top Cover on top of Inside Cover...
  • Page 148 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 6 Section: SCREENS & GABLES HABN_223e Rev. 01 Navigate End Screen Gable - Metal (HNBCGSMN), Navigate End of Run Screen (HNBTEF) 1.2.2 1.2.1...
  • Page 149 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 6 Section: SCREENS & GABLES HABN_223e Rev. 01 Part & Product Identification ITEM NO. PREVIEW DESCRIPTION PART NUMBER QTY. 1. Navigate End of Run Fabric Screen. (HNBTEF) x1 NAVIGATE END OF RUN FABRIC SCREEN HNBTEF 1.2.
  • Page 150 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 6 Section: SCREENS & GABLES HABN_223e ATTACH OUTER BRACKETS TO SCREEN ATTACH GABLE CONNECTORS TO LEGS NOTE: Ensure the Screen is Leveled. NOTE: Bolts come with the Table Frame. 1.2.2 1.2.3 STEP 1: Attach Outer Bracket to End Screen using Screws provided STEP 2: Loosen Bolts that come with the Table Frame, and slide Gable Connector to...
  • Page 151 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 6 Section: SCREENS & GABLES HABN_223e LINE UP INSIDE COVER AND BRACKET SECURE INSIDE COVER TO CONNECTOR STEP 3: Line up the Cable Channel Bracket with the Inside Cover, and place against the STEP 4: Use Screws provided to secure the Inside Cover to the Gable Connector horizontal frame...
  • Page 152 height-adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 6 Section: SCREENS & GABLES HABN_223e SCREW COVER TO BRACKET ATTACH BRACKETS TO FRAME NOTE: Support Bracket ships with Cable Channel. For Cable Channel installation procedures, please refer to guide HABN_223a/223b 1.2.3 1.2.1 STEP 5: Screw the Inside Cover to the bracket using the Screws provided in the Cable...
  • Page 153 height-adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 6 Section: SCREENS & GABLES HABN_223e ATTACH END SCREEN TO FRAME PLACE TOP COVER ON FRAME NOTE: Raise the 1.2.2 frame to its' maximum height before placing the Top Cover NOTE: Parts of the Frame are Hidden for Illustration Purpose.
  • Page 154 height-adjustable bench Installation Guides Date: May 2019 Page: 1 of 4 Section: SCREENS & GABLES HABN_224a Rev. 00 Navigate 120 Mid Cover - Metal (HNBCCMMT)
  • Page 155 height-adjustable bench Installation Guides Date: May 2019 Page: 2 of 4 Section: SCREENS & GABLES HABN_224a Rev. 00 Part & Product Identification ITEM NO. PREVIEW DESCRIPTION PART NUMBER QTY. TOP COVER MID GABLE WELDED ASSY. 120 NAV. HAB N09-8988X SPACER MID GABLE 120 NAVIGATE HAB A16-7672 COVER PLATE MID-GABLE 120 NAVIGATE HAB A16-7449...
  • Page 156 height-adjustable bench Installation Guides Date: May 2019 Page: 3 of 4 Section: SCREENS & GABLES HABN_224a Rev. 00 ATTACH COVER PLATE TO FRAME ATTACH SPACER TO FRAME NOTE: Bracket and Screws come NOTE: Please refer to HABN_123 with Cable Channel for hardware components required STEP 1: Attach the Cover Plate to the Legs and Mid-Gable Stretcher Assembly using the STEP 2: Attach the Spacer to the Mid-Gable Stretcher Frame along with the Bracketm using...
  • Page 157 height-adjustable bench Installation Guides Date: May 2019 Page: 4 of 4 Section: SCREENS & GABLES HABN_224a Rev. 00 PLACE TOP COVER STEP 3: Place the Top Cover on top of the Assembly.
  • Page 158 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 8 Section: SCREENS AND GABLES HABN_224 Rev. Navigate Single-Sided Corridor Screen – Fabric (HNBLSF), Navigate Single-Sided Corridor Screen – Solid (HNBLSS) 1.5.3 1.5.1 1.5.2...
  • Page 159 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 8 Section: SCREENS AND GABLES HABN_224 Part & Product Identification ITEM PART ITEM PART PREVIEW DESCRIPTION QTY. PREVIEW DESCRIPTION QTY. NUMBER NUMBER 1. NAVIGATE SINGLE SIDED CORRIDOR SCREEN - FABRIC (HNBLSF) 1.5.
  • Page 160 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 8 SCREENS AND GABLES Section: HABN_224 Part & Product Identification ITEM PART ITEM PART PREVIEW DESCRIPTION QTY. PREVIEW DESCRIPTION QTY. NUMBER NUMBER 2. NAVIGATE SINGLE SIDED CORRIDOR SCREEN - SOLID (HNBLSS) 2.3.

  • Page 161: Attach Brackets

    height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 8 Section: SCREENS AND GABLES HABN_224 ATTACH BRACKETS ASSEMBLE T-NUTS NOTE: HNBLSF Shown 1.5.1 1.5.2 1.5.3 1.5.4 STEP 1a: Attach Brackets as shown above with screws provided. STEP 2a: Assemble T-Nuts as shown above.
  • Page 162 height-adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 8 Section: SCREENS AND GABLES HABN_224 ATTACH BRACKETS ASSEMBLE T-NUTS NOTE: HNBLSS Shown 2.3.3 2.3.1 2.3.2 2.3.4 STEP 1b: Attach Brackets as shown above with screws provided. STEP 2b: Assemble T-Nuts as shown above.
  • Page 163 height-adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 8 Section: SCREENS AND GABLES HABN_224 ALIGN T-NUTS NOTE: Frame and Worksurface Assmbly is not shown for illustration purpose. STEP 3: Align T-Nuts parallel to the wire channel.
  • Page 164 height-adjustable bench Installation Guides Date: Sept 2019 Page: 7 of 8 Section: SCREENS AND GABLES HABN_224 FASTEN SCREWS NOTE: Worksurface not shown for illustration purpose. STEP 4: Fasten T-Nuts with an Allen Key. Make sure the screen is perpendicular to the ground.
  • Page 165 height-adjustable bench Installation Guides Date: Sept 2019 Page: 8 of 8 Section: SCREENS AND GABLES HABN_224 ADJUST LEVERLLERS (OPTIONAL) STEP 5: Using a wrench, adjust Levellers to achieve stability.
  • Page 166 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 4 Section: SCREENS AND GABLES HABN_225a Rev. Navigate Single-Sided End Cover – Metal (HNBCCEMS), Navigate Single-Sided Mid Cover – Metal (HNBCCMMS)
  • Page 167 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 4 Section: SCREENS AND GABLES HABN_225a Part & Product Identification ITEM ITEM PREVIEW DESCRIPTION PART NUMBER QTY. PREVIEW DESCRIPTION PART NUMBER QTY. 1. NAVIGATE END COVER, SINGLE SIDED, HAB (HNBCCEMS30L) 3.
  • Page 168 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 4 Section: SCREENS AND GABLES HABN_225a PLACE GABLE COVER (RIGHT) PLACE GABLE COVER (LEFT) STEP 1a: Place the End Gable Cover - Right as shown above. STEP 1b: Place the End Gable Cover - Left as shown above.
  • Page 169 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 4 Section: SCREENS AND GABLES HABN_225a PLACE THE MID GABLE COVER STEP 3: Place Mid-Gable Cover as shown above.
  • Page 170 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 6 Section: SCREENS AND GABLES HABN_225b Rev. 0 NAVIGATE SINGLE-SIDED END SCREEN COVER (HNBCCSMS), NAVIGATE SINGLE-SIDED END OF RUN SCREEN - FABRIC (HNBTSF)
  • Page 171 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 6 Section: SCREENS AND GABLES HABN_225b Part & Product Identification ITEM PREVIEW DESCRIPTION PART NUMBER QTY. NAVIGATE END OF RUN FABRIC SCREEN SS HNBTSF-X 2. FABRIC END SCREEN MOUNTING BRKT KIT, SINGLE SIDED, HAB (X06-0618) x1 END SCREEN BRKT ASSY, INNER, SINGLE N09-9207 SIDED, HAB...
  • Page 172 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 6 Section: SCREENS AND GABLES HABN_225b ATTACH BRACKETS TO SCREEN ATTACH BRACKETS TO FRAME STEP 1: Attach Outer Brackets to Screen using Screws provided. STEP 2: Attach Inner Brackets to Frame using Screws provided.
  • Page 173 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 6 Section: SCREENS AND GABLES HABN_225b ATTACH SCREEN TO FRAME (WITH CORRIDOR SCREEN ONLY) NOTE: For the installation instructions of the Wire Channel (HNBFCN), refer to guide HABN_225d/225e. For the Corridor Screen (HNBLS), refer to guide HAB_224.
  • Page 174 height-adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 6 Section: SCREENS AND GABLES HABN_225b ATTACH SCREEN TO FRAME PLACE INSIDE COVER ON FRAME NOTE: If the Screen is tilted forwards or backwards, the slots in the Outer/Inner Brackets allow the screen to be adjusted STEP 4: Attach the End Screen to the Frame using the Screws Provided.
  • Page 175 height-adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 6 Section: SCREENS AND GABLES HABN_225b PLACE TOP COVER IN POSITION STEP 6: Place Top Cover on top of the Inside Cover...
  • Page 176 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 6 Section: SCREENS AND GABLES HABN_225c Rev. 0 NAVIGATE SINGLE-SIDED END OF RUN SCREEN GABLE (HNBCGSMS), NAVIGATE SINGLE-SIDED END OF RUN SCREEN - SOLID (HNBTSS)
  • Page 177 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 6 Section: SCREENS AND GABLES HABN_225c Part & Product Identification ITEM ITEM PREVIEW DESCRIPTION PART NUMBER QTY. PREVIEW DESCRIPTION PART NUMBER QTY. STICK ON CLEAR BUMPER D04-0050 4. NAVIGATE END SCREEN GABLE, SINGLE SIDED, HAB (HNBCGSMS) x1 NAVIGATE END SCREEN, HNBTSS-X SOLID, SINGLE SIDED, HAB...
  • Page 178 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 6 Section: SCREENS AND GABLES HABN_225c ATTACH OUTER BRACKETS TO SCREEN ATTACH GABLE CONNECTORS TO LEGS NOTE: Ensure the screen is leveled. NOTE: Bolts come with the Table Frame STEP 1: Attach Outer Brackets to the End Screen using Screws provided. STEP 2: Loosen Bolts that come with the Table Frame, and slide the Gable Connectors to the underside of the legs.
  • Page 179 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 6 Section: SCREENS AND GABLES HABN_225c PLACE INSIDE COVER ON FRAME SECURE INSIDE COVER TO CONNECTOR STEP 3: Place the Inside Cover on the Frame. Ensure the Inside Cover Brackets are mounted STEP 4: Use Screws provided to secure the Inside Cover to the Gable Connector.
  • Page 180 height-adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 6 Section: SCREENS AND GABLES HABN_225c ATTACH BRACKETS TO FRAME ATTACH BUMPER (OPTIONAL) NOTE: For the installation instructions of the Wire Channel (HNBFCN), refer to guide HABN_225d/225e. For the Corridor Screen (HNBLS), refer to guide HABN_224.
  • Page 181 height-adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 6 Section: SCREENS AND GABLES HABN_225c ATTACH END SCREEN TO FRAME PLACE TOP COVER ON FRAME NOTE: Raise the frame to its' MAXIMUM height before placing the Top Cover. NOTE: If the screen is tilted forwards or backwards, the slots in the Outer/Inner brackets allow the screen to be adjusted.
  • Page 182 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 7 Section: SCREENS AND GABLES HABN_225d Rev. Navigate Single-Sided End Gable - Metal (HNBCGEMS), Navigate Single-Sided Mid Gable - Metal (HNBCGMMS) HNBCGEMS shown HNBCGMMS shown...
  • Page 183 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 7 Section: SCREENS AND GABLES HABN_225d Part & Product Identification ITEM ITEM PREVIEW DESCRIPTION PART NUMBER QTY. PREVIEW DESCRIPTION PART NUMBER QTY. 1. NAVIGATE END GABLE, METAL, SINGLE SIDED, HAB (HNBCGEMS) 2.
  • Page 184 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 7 Section: SCREENS AND GABLES HABN_225d ATTACH CONNECTING PLATES TO FRAME LEGS MOUNT INSIDE COVER STEP 1: Loosen Leg Hex Bolt to attach Gable Connecting Plates to Frame leg. Then, Fasten STEP 2:Mount Inside Cover Assembly onto Frame Stretcher Bar.
  • Page 185 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 7 Section: SCREENS AND GABLES HABN_225d FASTEN INSIDE COVER IN PLACE APPLY FOAM RUBBERS STEP 3: Make sure the face of the Inside Cover Assembly is flush with the Leg. Secure Inside STEP 4: Attach Foam Rubbers onto the center of the Frame Legs' inner side.
  • Page 186 height-adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 7 Section: SCREENS AND GABLES HABN_225d MOUNT OUTSIDE COVER ASSEMBLY Side View Detailed Isometric View STEP 5: Mount Outside Cover Assembly to the highlighted part of the Inside Cover Assembly as shown.
  • Page 187 height-adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 7 Section: SCREENS AND GABLES HABN_225d MOUNT SIDE COVER ASSEMBLY NOTE: Installation of HNBCGMSS shown Side View STEP 7: Mount Side Cover Assembly as shown above.

  • Page 188: Front Cover Assembly

    height-adjustable bench Installation Guides Date: Sept 2019 Page: 7 of 7 Section: SCREENS AND GABLES HABN_225d FRONT COVER ASSEMBLY PLACE TOP COVERS STEP 8: Place the magnet then, mount Front Cover Assembly as shown above. STEP 9: Place Back Top Cover and Top Cover as shown above.
  • Page 189 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 10 Section: SCREENS AND GABLES HABN_225e Rev. Navigate Single-Sided End Gable - Solid (HNBCGESS), Navigate Single-Sided Mid Gable - Solid (HNBCGMSS) 2.13...
  • Page 190 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 10 Section: SCREENS AND GABLES HABN_225e Part & Product Identification ITEM ITEM PREVIEW DESCRIPTION PART NUMBER QTY. PREVIEW DESCRIPTION PART NUMBER QTY. 1. NAVITAGE END GABLE, SOLID, SINGLE SIDED, HAB (HNBCGESS30) HANGING BRACKET FOR A16-3021...
  • Page 191 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 10 Section: SCREENS AND GABLES HABN_225e Part & Product Identification ITEM PART ITEM PART PREVIEW DESCRIPTION QTY. PREVIEW DESCRIPTION QTY. NUMBER NUMBER GABLE CONNECTING 2.11 A16-3651 PLATE SIDE COVER FOR MID C07- GABLE, SINGLE 4718AL\30...
  • Page 192 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 10 Section: SCREENS AND GABLES HABN_225e ATTACH CONNECTION PLATES TO FRAME LEGS ATTACH SUPPORT BRACKETS STEP 1: Loosen Legs Hex Bolt to allow enough room for Gable Connecting Plate. Fasten STEP 2: Fasten Brackets to Outside Cover Assembly Gable Connecting Plates to Frame Legs.
  • Page 193 height-adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 10 Section: SCREENS AND GABLES HABN_225e MOUNT INSIDE COVER ASSEMBLY MOUNT INSIDE COVER ASSEMBLY STEP 3: Mount Inside Cover Assembly onto Stretcher Bar. STEP 4: Secure Inside Cover Assembly to Gable Connecting Plate on both sides using Tap Quad Pan screws provided.
  • Page 194 height-adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 10 Section: SCREENS AND GABLES HABN_225e MOUNT OUTSIDE COVER ASSEMBLY STEP 5: Mount Outside Cover Assembly to Stretcher Bar as shown above.
  • Page 195 height-adjustable bench Installation Guides Date: Sept 2019 Page: 7 of 10 Section: SCREENS AND GABLES HABN_225e ATTACH CONNECTING PLATES TO FRAME LEGS MOUNT BOTTOM ANGLE BAR 2.17 2.11 STEP 6: Loosen Legs Hex Bolt to allow enough room for Gable Connecting Plate. Fasten STEP 7: Mount Bottom Angle Bar and secure to Gable Connecting Plate on both sides using Gable Connecting Plates to Frame Legs Tap Quad Pan screws provided...
  • Page 196 height-adjustable bench Installation Guides Date: Sept 2019 Page: 8 of 10 Section: SCREENS AND GABLES HABN_225e ATTACH SUPPORT BRACKETS - 1 ATTACH SUPPORT BRACKETS - 2 2.12 2.16 2.14 2.18 2.16 2.16 STEP 8: Fasten Brackets and Cover Plates to Side Cover Assemblies as shown. STEP 9: Fasten Brackets and Cover Plates to Front Covers as shown.
  • Page 197 height-adjustable bench Installation Guides Date: Sept 2019 Page: 9 of 10 Section: SCREENS AND GABLES HABN_225e MOUNT SIDE COVER ASSEMBLY STEP 10: Mount Side Cover Assembly onto the Stretcher Bar as shown.
  • Page 198 height-adjustable bench Installation Guides Date: Sept 2019 Page: 10 of 10 Section: SCREENS AND GABLES HABN_225e MOUNT FRONT COVER ASSEMBLY PLACE TOP COVERS STEP 11: Mount Front Covers onto the Frame Link and Bottom Connecting Brackets. STEP 12: Place Top Covers as shown above.
  • Page 199 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 6 Section: METAL GABLES & CABLE CHANNEL HABN_225f Rev. 00 Navigate Single-Sided Transition Mid-Gable - Metal (HNBCGMMR)
  • Page 200 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 6 Section: METAL GABLES & CABLE CHANNEL HABN_225f Rev. 00 Part & Product Identification ITEM PART ITEM PART PREVIEW DESCRIPTION QTY. PREVIEW DESCRIPTION QTY. NUMBER NUMBER TOP COVER FOR METAL MID GABLE W/POWER A16-7491-X POLE, DOUBLE SIDED,...

  • Page 201: Install Bracket

    height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 6 Section: METAL GABLES & CABLE CHANNEL HABN_225f Rev. 00 INSTALL BRACKET INSTALL FRAME LINK NOTE: Refer to HABN_101 for installation steps for the Frame Link STEP 1: Attach Bracket to stretcher bar using Screws provided. STEP 2: Install Frame Link to join both frames.
  • Page 202 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 6 Section: METAL GABLES & CABLE CHANNEL HABN_225f Rev. 00 ASSEMBLE BACK COVER ATTACH SIDE COVER TO FRAME NOTE: Bracket and Screws included with Wire Channel, refer to HABN_223a for more steps.
  • Page 203 height-adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 6 Section: METAL GABLES & CABLE CHANNEL HABN_225f Rev. 00 ATTACH SIDE COVER INSTALL BACK COVER STEP 5: Hook Side Cover over stretcher bar on Single-Sided Frame. STEP 6: Hook Back Cover assembly over the corners of rhe Side Covers. The magnet should stick to the leg of the Single-Sided Frame.
  • Page 204 height-adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 6 Section: METAL GABLES & CABLE CHANNEL HABN_225f Rev. 00 ATTACH FRONT COVER PLACE TOP COVER ON GABLE STEP 7: Place magnets in between the rivets at the bottom of the Front Cover. Hook corners STEP 8: Raise the tables, then place the Top Cover on top of the gable assembly.
  • Page 205 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 11 Section: SCREENS & GABLES HABN_225g Rev. 0 Navigate Transition Mid Gable - Solid (HNBCGMSR) NOTE: HNBCGMSR_L is Shown as an Example.
  • Page 206 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 11 Section: SCREENS & GABLES HABN_225g Part & Product Identification ITEM PREVIEW DESCRIPTION PART NUMBER QTY. 1. NAVIGATE TRANSITION MID GABLE, SOLID (HNBCGMSR)x1 SIDE COVER FOR MID GABLE, DOUBLE SIDED, HAB C07-4593X-X SIDE COVER FOR MID GABLE, SINGLE SIDED, HAB C07-4718R-X...
  • Page 207 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 11 Section: SCREENS & GABLES HABN_225g Part & Product Identification ITEM PREVIEW DESCRIPTION PART NUMBER QTY. 1. NAVIGATE TRANSITION MID GABLE, SOLID (HNBCGMSR)x1 GABEL CONNECTING PLATE A16-3651 HANGING BRACKET, FOR WOOD MID GABLE, A16-3203 BOTTOM CONNECTING BRKT ,WOOD MID A16-3026...
  • Page 208 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 11 Section: SCREENS & GABLES HABN_225g Part & Product Identification ITEM PART PREVIEW DESCRIPTION QTY. NUMBER 1. NAVIGATE TRANSITION MID GABLE, SOLID (HNBCGMSR)x1 HANGING BRACKET, FOR WOOD MID GABLE, A16-7569R SINGLE SIDED, HAB CORNER BRKT, TRANSITION SOLID MID GABLE, A16-7732...
  • Page 209 height-adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 11 Section: SCREENS & GABLES HABN_225g INSTALL BRACKET INSTALL FRAME LINK NOTE: Refer to HABN_101 for installation steps for thr Frame Link. STEP 1:Attach Bracket to Stretcher bar using Screws provided. STEP 2: Install Frame Link to join both frames.
  • Page 210 height-adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 11 Section: SCREENS & GABLES HABN_225g ATTACH CONNECTING PLATES MOUNT BOTTOM ANGLE BAR NOTE: Parts of the Frames are Hidden for Illustration purpose. STEP 3: Loosen Hex Bolt to allow enough room for gable connecting Plate. Fasten Gable STEP 4: Mount both Bottom Angle Bars and Secure to Gable Connecting Plates on both Connecting plates to the Frame Legs.
  • Page 211 height-adjustable bench Installation Guides Date: Sept 2019 Page: 7 of 11 Section: SCREENS & GABLES HABN_225g ATTACH MID GABLE SUPPORT BRACKETS STEP 5: Secure the Brackets and Cover Plates to Side cover, Back Cover, Front Cover and Transition Cover as shown. Rotate Screws Clockwise to Fasten.
  • Page 212 height-adjustable bench Installation Guides Date: Sept 2019 Page: 8 of 11 Section: SCREENS & GABLES HABN_225g MOUNT SIDE COVER ASSEMBLY MOUNT BACK COVER ASSEMBLY NOTE: Parts of the Frames are Hidden for Illustration purpose. NOTE: Parts of the Frames are Hidden for Illustration purpose.
  • Page 213 height-adjustable bench Installation Guides Date: Sept 2019 Page: 9 of 11 Section: SCREENS & GABLES HABN_225g ATTACH TRANSITION GABLE COVER SECURE TRANSITION GABLE COVER NOTE: Parts of the Frames are Hidden for Illustration purpose. NOTE: Parts of the Frames are Hidden for Illustration purpose.
  • Page 214 height-adjustable bench Installation Guides Date: Sept 2019 Page: 10 of 11 Section: SCREENS & GABLES HABN_225g MOUNT SIDE COVER ASSEMBLY MOUNT FRONT COVER ASSEMBLY NOTE: Parts of the Frames are Hidden for Illustration purpose. NOTE: Parts of the Frames are Hidden for Illustration purpose.
  • Page 215 height-adjustable bench Installation Guides Date: Sept 2019 Page: 11 of 11 Section: SCREENS & GABLES HABN_225g ATTACH TOP COVER NOTE: Parts of the Frames are Hidden for Illustration purpose. STEP 12: Rest Top Cover ontoGable Assembly as shown.
  • Page 216 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 8 Section: ELECTRICS HABN_321a Rev. 01 Navigate Power Module (HNBEPM), Navigate Receptacle Outlet (HNBERO), Navigate Power Harness (HNBEPH)
  • Page 217 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 8 Section: ELECTRICS HABN_321a Part & Product Identification ITEM ITEM PREVIEW DESCRIPTION PART NUMBER QTY. PREVIEW DESCRIPTION PART NUMBER QTY. 1. NAVIGATE POWER MODULE (HNBEPM) #8-18X1/2"CROSS SQUARE E07-0012 COMB.SELF COMMUNICATION PLUG OUTLET $OUTLET ASSY...
  • Page 218 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 8 Section: ELECTRICS HABN_321a ASSEMBLE OUTLET HOUSING FASTEN SCREWS STEP 1: Place Outlet Housing over Power Module. STEP 2: Fasten Outlet Housing with screws provided.
  • Page 219 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 8 Section: ELECTRICS HABN_321a ASSEMBLE RECEPTACLE FASTEN SCREWS STEP 3: Slide and engage Receptacles into Outlet Housing STEP 4: Fasten Receptacles with screws provided.
  • Page 220 height-adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 8 Section: ELECTRICS HABN_321a ASSEMBLE PLATES STEP 5: Attach the Bezel by snapping it onto the Housing. Then, attach Blank Plate onto the Bezel.

  • Page 221: Power Module Assembly

    height-adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 8 Section: ELECTRICS HABN_321a POWER MODULE ASSEMBLY - 1 STEP 6: Fasten Power Module assembly to underside of Cable Tray, make sure to line up holes of Cable Tray to holes from Brackets.
  • Page 222 height-adjustable bench Installation Guides Date: Sept 2019 Page: 7 of 8 Section: ELECTRICS HABN_321a POWER MODULE ASSEMBLY - 2 M-Clip Hanger-Club Talk Bracket NOTE: Installer is to determine the layout for Hanger-Club Talk Bracket and M-Clip within the rectangular area. STEP 7: Assemble M-Clips and Hanger-Club Talk Brackets.
  • Page 223 height-adjustable bench Installation Guides Date: Sept 2019 Page: 8 of 8 Section: ELECTRICS HABN_321a POWER HARNESS ASSEMBLY NOTE: M-Clips are not illustrated STEP 8: Connect pre-assembled Base Feed to Power Module. If Power Harness is specified, connect Power Harness to Power Module.
  • Page 224 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 7 Section: ELECTRICS HABN_321b Rev. 01 Navigate Chicago Power Module (HNBEPMCH), Navigate Single-Sided Chicago Power Module (HNBEPMCH) NOTE: Single-Sided Power Module follows same step.
  • Page 225 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 7 Section: ELECTRICS HABN_321b Part & Product Identification ITEM NO. PREVIEW DESCRIPTION PART NUMBER QTY. 1. CHICAGO POWER MODULE (HNBEPMCH) SHEET MATAL HOUSING, CHICAGO MPA16-E020 OUTLET BOX, NAVIGAT HAB Inner Housing Assembly JNECPB Screw,#8x1/2"...
  • Page 226 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 7 Section: ELECTRICS HABN_321b LOOSEN SCREWS DISASSEMBLE INNER HOUSING STEP 1: Remove Screws from the Inner Housings to loosen. STEP 2: Disassemble Inner Housing Assembly.
  • Page 227 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 7 Section: ELECTRICS HABN_321b MAKE WIRE CONNECTIONS FASTEN SCREWS NOTE: Licensed Electrician need to make the Wire Connections. Before attaching the Inner Housing to Metal Housing. NOTE: The Wires are hidden for illustration purpose.
  • Page 228 height-adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 7 Section: ELECTRICS HABN_321b ATTACH CHICAGO POWER MODULE TO WIRE CHANNEL NOTE: Base Feed is pre-assembled STEP 5: Fasten Chicago Power Module assembly to underside of Cable Tray, Make sure to lineup holes of cable tray to holes Brackets.
  • Page 229 height-adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 7 Section: ELECTRICS HABN_321b POWER MODULE ASSEMBLY - 1 WARNING! *Do not connect to power source until installation is complete. *Connection to the building power source must be performed by a licensed electrician. *Not following these instruction could result in damage and/or injury.
  • Page 230 height-adjustable bench Installation Guides Date: Sept 2019 Page: 7 of 7 Section: ELECTRICS HABN_321b POWER MODULE ASSEMBLY - 2 M-Clip Hanger-Club Talk Bracket NOTE: Installer is to determine the layout for Hanger-Club Talk Bracket and M-Clip within the rectangular area. STEP 7: Assemble M-Clips and Hanger-Club Talk Brackets.
  • Page 231 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 10 Section: ELECTRICS HABN_321c Rev. 01 Navigate Base Feed (HNBEBF), Navigate Base Feed Cover (HNBEBC), Navigate Chicago Base Feed (HNBEBFCH), Navigate Split Base Feed (HNBEBFS)
  • Page 232 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 10 Section: ELECTRICS HABN_321c Part & Product Identification PART PART PREVIEW DESCRIPTION QTY. PREVIEW DESCRIPTION QTY. NUMBER NUMBER 1. Base Feed - End Condition (HNBEBF_E) x1 5. Chicago Base Feed (HNBEBFCH_M) x1 Base Feed w HNBEBF-END Chicago Base...
  • Page 233 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 10 Section: ELECTRICS HABN_321c INSTALL SPLIT BASE FEED INSTALL BOX COVER (OPTIONAL) NOTE: Cable Channel is hidden for Illustration Purpose. Pilot Holes Pilot Holes NOTE: Connect the Base Power Harness (HNBEPH) (24") Feed to the Power Harness.
  • Page 234 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 10 Section: ELECTRICS HABN_321c INSTALL BASE FEED ATTACH BASE FEED & INSTALL CABLE TRAY NOTE: Installation for Chicago Base Feed (HNBEBFCH) is Power Harnes (HNBEPH) (24") similar to Base Feed (HNBEBF). NOTE: HNBEBF is Shown.
  • Page 235 height-adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 10 Section: ELECTRICS HABN_321c INSTALL BASE FEED COVER LOOSEN SCREW STEP 4: Fasten Bracket to underside of Stretch bar. STEP 5: Loosen screw to allow the cover bracket to adjust the height.
  • Page 236 height-adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 10 Section: ELECTRICS HABN_321c ADJUST COVER TIGHTEN SCREW Finish Floor STEP 6: Adjust cover so it rest on Finish Floor. STEP 7: Tighten screw to Secure it.
  • Page 237 height-adjustable bench Installation Guides Date: Sept 2019 Page: 7 of 10 Section: ELECTRICS HABN_321c INSERT CABLE INTO BASE FEED COVER Underside View STEP 8: Insert Base Feed cable into Base Feed Cvoer as shown on illustration above.
  • Page 238 height-adjustable bench Installation Guides Date: Sept 2019 Page: 8 of 10 Section: ELECTRICS HABN_321c ORIENTATION OF BASE FEED (OPTIONAL) Parallel Orientation Vertical Orientation STEP 9a: Remove Screws and Determine the orientstion for Mid Bracket.
  • Page 239 height-adjustable bench Installation Guides Date: Sept 2019 Page: 9 of 10 Section: ELECTRICS HABN_321c INSTALL MID BASE FEED NOTE: Wire channel and other elctrics are Hidden for illustration purposes. STEP 9b: Fasten Middle Bracket and Base Feed. Install assembly to Stretcher bar as shown. Installation for Chicago Power Module is Similar.
  • Page 240 height-adjustable bench Installation Guides Date: Sept 2019 Page: 10 of 10 Section: ELECTRICS HABN_321c NOTE Wire Management M-Clips NOTE: Installer is to Determine the layout for the data, wire managemnet bracket and m-clips in the hatched area.
  • Page 241 height adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 9 Section: ELECTRICS HABN_322a Rev. 01 Navigate Ceiling Feed (HNBECF), Navigate Chicago Ceiling Feed (HNBECFCH), Navigate Power Pole - End(HNBEPP_E) NOTE: Parts of the Frame are hidden for illustration purpose.
  • Page 242 height adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 9 Section: ELECTRICS HABN_322a Part & Product Identification ITEM ITEM PREVIEW DESCRIPTION PART NUMBER QTY. PREVIEW DESCRIPTION PART NUMBER QTY. 2. Power Pole - End (HNBEPP_E) x1 Ceiling Feed HNBECF AEA23-E014- Upper Pole Cover...
  • Page 243 height adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 9 Section: ELECTRICS HABN_322a INSTALL BRACKET TO POWER POLE ALLIGN LOWER POWER POLE TO HAB FRAME 2.10 2.10 (Do Not Fully Tighten) HAB Frame Stretcher Bar STEP 1:Fasten Bracket to Lower Power Pole Extrusion. Do not fully tighten as bracket needs STEP 2: Bring Lower Power Pole Extrusion underneath Height Adjustable Bench (HAB) to slide up or down.
  • Page 244 height adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 9 Section: ELECTRICS HABN_322a SECURE BOTTOM EXTRUSION TO FRAME TIGHTEN BRACKET TO LOWER POWER POLE Underside View 2.10 STEP 3: Use Screws and washers Provided to fasten Power Pole Bracket to HAB Frame as STEP 4: Make sure lower pole ectrusion sits on the floor &...
  • Page 245 height adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 9 Section: ELECTRICS HABN_322a CEILING CUT OUT INSTALL UPPER EXTRUSION Top Portion Shown 3 1/2" 3 1/2" Power Pole length Bottom Portion Shown =distance + 3" STEP 5:Mark Power Pole position on the ceiling using Plum Bob line. Cut 3 1/2" x 3 1/2" STEP 6: Insert Upper Power Pole extrusion inside ceiling cut-out (Uncut edge down).
  • Page 246 height adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 9 Section: ELECTRICS HABN_322a INSTALL CEILING FEED INSTALL CEILING FEED STEP 7: Drop Ceiling Feed cable down through ceiling cut-out down along the Power Pole. STEP 8: Feed cable underneath Bracket. Slide junction box bracket inside Power Pole Extrusion.
  • Page 247 height adjustable bench Installation Guides Date: Sept 2019 Page: 7 of 9 Section: ELECTRICS HABN_322a ATTACH LOWER COVER ATTACH UPPER COVER STEP 9: Tuck Cable and attach Power Pole Covers by engaging them into Lower Extrusion. STEP 10: Insert Upper Covers inside ceiling cut-out then engage into Upper Power Pole Extrusion.
  • Page 248 height adjustable bench Installation Guides Date: Sept 2019 Page: 8 of 9 Section: ELECTRICS HABN_322a ATTACH CEILING PLATE & DRILL HOLES INSTALL PLATES 2.11 NOTE: Wire Channel is hiddden for Illustration Purpose. 2.10 STEP 11: Attach Ceiling Plates to Power Pole under the Ceiling. Drill holes for T-Nuts using STEP 12: Push T-nuts inside holes from the Top of the Ceiling tile.
  • Page 249 height adjustable bench Installation Guides Date: Sept 2019 Page: 9 of 9 Section: ELECTRICS HABN_322a COVER PLATES INSTALL Backside View STEP 13: Expose the adhesive of the double sided tape on the back of the Cover Plate and slide Cover Plate from the top to cover cut-out on the side of Power Pole.
  • Page 250 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 10 Section: ELECTRICS HABN_322b Rev. 1 Navigate Power Pole - Mid (HNBEPP_M), Navigate Power Pole Single Sided - Mid (HNBEPP_S), Navigate Ceiling Feed (HNBECF) & Navigate Chicago Ceiling Feed (HNBECF) NOTE: HNBEPP_M is shown as an Example.
  • Page 251 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 10 Section: ELECTRICS HABN_322b Part & Product Identification ITEM PART ITEM PART PREVIEW DESCRIPTION QTY. PREVIEW DESCRIPTION QTY. NUMBER NUMBER AEA23-E014- Upper Pole Cover Ceiling Feed HNBECF Ceiling plate for MPA15-2666 Chicago Ceiling EPQE...
  • Page 252 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 10 Section: ELECTRICS HABN_322b Part & Product Identification ITEM PART ITEM PART PREVIEW DESCRIPTION QTY. PREVIEW DESCRIPTION QTY. NUMBER NUMBER 3. Power Pole - Mid (HNBEPM_S) x1 Lower Pole Body- Mid AEA21-0200-09 Connecting Bracket MPA15-E064...
  • Page 253 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 10 Section: ELECTRICS HABN_322b CONNECT BRACKET ASSEMBLY ATTACH LOWER EXTRUSION NOTE: Cable Channels are Underside View Hidden for Illustration Purpose. Opposite Side NOTE: Cable Channels are NOTE: Install Connection Hidden for Illustration Purpose. Bracket then proceed Mid- Gable-Installation.
  • Page 254 height-adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 10 Section: ELECTRICS HABN_322b MOUNT CONNECTING BRACKET (SINGLE SIDED) ATTACH LOWER EXTRUSION (SINGLE SIDED) Frame Link NOTE: Step 1b and 2b are only for the Installation of Power Pole Single Sided - Mid Condition.
  • Page 255 height-adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 10 Section: ELECTRICS HABN_322b SECURE BOTTOM EXTRUSION CEILING CUT OUT NOTE: Frame Legs are hidden for illustration purpose. Power Pole Length = distance + 3" STEP 3: Fasten Bracket to Lower Power Pole STEP 4: Mark Power Pole position on the cieling using Plum Bob line.
  • Page 256 height-adjustable bench Installation Guides Date: Sept 2019 Page: 7 of 10 Section: ELECTRICS HABN_322b INSTALL UPPER EXTRUSION CEILING FEED ASSEMBLY NOTE: Cable Channels are Hidden for Illustration Purpose. STEP 5: Insert Upper Power Pole Extrusion inside Ceiling Cut-Out (Uncut edge down). STEP 6: Drop Ceiling Feed cable down through ceiling Cut-out down along the Power Pole Drop Power Pole Upper Extrusion on the Top of Lower Extrusion and Connect them Slide junction box Inside the Power Pole Extrusion.

  • Page 257: Cable Management

    height-adjustable bench Installation Guides Date: Sept 2019 Page: 8 of 10 Section: ELECTRICS HABN_322b CABLE MANAGEMENT NOTE: Cable Channel are Hidden for Illustration Purpose. Mid Gable Top Cover Cable Channel STEP 7: Open Mid-Gable Top Cover and Connect Ceiling Feed and fish to the underside of the Cable Channel.
  • Page 258 height-adjustable bench Installation Guides Date: Sept 2019 Page: 9 of 10 Section: ELECTRICS HABN_322b ATTACH LOWER COVER ATTACH UPPER COVER NOTE: Frame Legs and Cable Channel are hidden for Illuatration Purpose. Cieling STEP 8: Tuck cable and attach Power Pole Covers by engaging them into Lower Extrusion. STEP 9: Insert Upper Covers inside ceiling cut-out then engage into Upper Power Pole Extrusion.
  • Page 259 height-adjustable bench Installation Guides Date: Sept 2019 Page: 10 of 10 Section: ELECTRICS HABN_322b ATTACH CEILING PLATE & DRILL HOLES SECURE PLATES 2.10 WARNING:Don't connect to power source untill installation is copmlete. All wire connections must be performed by a licensed electrician in accordance with applicable codes and regulations.
  • Page 260 height adjustable bench Installation Guides Section: ELECTRICS Date: Sept 2019 Page No: 1 of 6 Description: NAVIGATE POWER CONSERVATION SYSTEM HABN_323 Rev. No: 01 Power Conservation System (HNBEPC) Part and Product Identification A - #8 x 3/4 Slf Tping Scrw FS8x.075QPTEKS x4 B - Control Box Control Box-12.11 x1...
  • Page 261 height adjustable bench Installation Guides Section: ELECTRICS Date: Sept 2019 Page No: 2 of 6 Description: NAVIGATE POWER CONSERVATION SYSTEM HABN_323 INSTALL POWER CONSERVATION SYSTEM CONNECT POWER CONSERVATION SYSTEM STEP 1: Install Power Conservation System beneath Cable Channel using Self Tapping Screws STEP 2: Connect Power Conservation System to Base Feed and Power Module...
  • Page 262 height adjustable bench Installation Guides Section: ELECTRICS Date: Sept 2019 Page No: 3 of 6 Description: NAVIGATE POWER CONSERVATION SYSTEM HABN_323 MOUNT WORKSURFACES MOUNT SENSORS STEP 3: Mount Worksurfaces STEP 4: Mount Sensors using Wood Screws...
  • Page 263 height adjustable bench Installation Guides Section: ELECTRICS Date: Sept 2019 Page No: 4 of 6 Description: NAVIGATE POWER CONSERVATION SYSTEM HABN_323 DESCRIPTION R 8.0' Note: Sensor placement will be based on location of User, Length of CAT3 Cable, and Desk Configuration...
  • Page 264 height adjustable bench Installation Guides Section: ELECTRICS Date: Sept 2019 Page No: 5 of 6 Description: NAVIGATE POWER CONSERVATION SYSTEM HABN_323 CONNECT SENSOR TO POWER CONSERVATION SYSTEM Note: Press CAT3 Cable into Wire Manager STEP 5: Connect Sensor to Sensor using CAT3 Cable...
  • Page 265 height adjustable bench Installation Guides Section: ELECTRICS Date: Sept 2019 Page No: 6 of 6 Description: NAVIGATE POWER CONSERVATION SYSTEM HABN_323 SENSOR GANGING STEP 6: Connect Sensors together using CAT3 Cable...
  • Page 266 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 8 Section: ELECTRICS HABN_324 Rev. 00 Navigate Power Pole (HNBEPP), Navigate Ceiling Feed (HNBECF)
  • Page 267 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 8 Section: ELECTRICS HABN_324 Part & Product Identification ITEM ITEM PREVIEW DESCRIPTION PART NUMBER QTY. PREVIEW DESCRIPTION PART NUMBER QTY. 1. Navigate Power Pole (HNBEPP) MOUNTING BRKT MID 120 MPA16-E042 LOWER POLE HAB POWER AEA23-E014...
  • Page 268 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 8 Section: ELECTRICS HABN_324 Part & Product Identification ITEM ITEM PREVIEW DESCRIPTION PART NUMBER QTY. PREVIEW DESCRIPTION PART NUMBER QTY. 1/4-20 5/8 " FS1-4-20X5- LONG SCREW 8RPM FOR ECPQ Screw,#8x1/2" RND, ROB, FS8 x 1-2-RRB BRIGHT ZINC...

  • Page 269: Install Brackets

    height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 8 Section: ELECTRICS HABN_324 INSTALL BRACKETS ATTACH LOWER EXTRUSION 1.10 STEP 1: Install Bracket to Mid Gable Top Mounting Plate. STEP 2: Align and attach Lower Power Pole to Connecting Bracket as shown.
  • Page 270 height-adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 8 Section: ELECTRICS HABN_324 ATTACH LOWER EXTRUSION FASTEN SCREWS STEP 3: Insert Upper Power Pole Extrusion inside ceiling cut-out (uncut edge down). Drop STEP 4: Connect Upper and Lower Extrusion together using Connection Plate and Screws. Power Pole Upper Extrusion on the top of Lower Extrusion.

  • Page 271: Junction Box Installation

    height-adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 8 Section: ELECTRICS HABN_324 JUNCTION BOX INSTALLATION WIRE MANAGEMENT NOTE: Junction Box Wire not shown STEP 5: Slide Junction Box Bracket inside the Power Pole Extrusion. STEP 6: Drop Ceiling Feed cable down through ceiling cut-out down along the Power Pole.
  • Page 272 height-adjustable bench Installation Guides Date: Sept 2019 Page: 7 of 8 Section: ELECTRICS HABN_324 ATTACH LOWER COVER ATTACH UPPER COVER STEP 7: Tuck cable and attach Power Pole Covers by engaging them into Lower Extrusion STEP 8: Insert Upper Covers inside ceiling cut-out then engage into Upper Power Pole Extrusion.
  • Page 273 height-adjustable bench Installation Guides Date: Sept 2019 Page: 8 of 8 Section: ELECTRICS HABN_324 ATTACH CEILING PLATES FASTEN SCREWS 1.11 1.12 1.13 STEP 9: Attach Ceiling Plates to Power Pole under the ceiling. STEP 10: Push T-nuts inside holes from the top of the ceiling tile. Wrap Cover plates around the Power Pole and fasten using hardware provided.
  • Page 274 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 4 Section: ELECTRICS HABN_325 Rev. CENTER ELECTRICAL GROMMET (HNBECEG)
  • Page 275 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 4 Section: ELECTRICS HABN_325 Part & Product Identification ITEM ITEM PREVIEW DESCRIPTION PART NUMBER QTY. PREVIEW DESCRIPTION PART NUMBER QTY. 1. NAVIGATE CENTER ELECTRICAL GROMMET (HNBECEG) XEPB-PD- POWER MODULE USBAC GROMMET YEAG01-RAW COVER...
  • Page 276 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 4 Section: ELECTRICS HABN_325 ASSEMBLE ATTACHMENTS MOUNT POWER MODULE STEP 1: Assemble Plate, Bracket Mount, and Power Module with screws provided. STEP 2: Mount Power Module as shown above.
  • Page 277 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 4 Section: ELECTRICS HABN_325 PLACE GROMMET COVER STEP 3: Place the Grommet Cover as shown above.
