Teknion Navigate height-adjustable bench Manual page 199

height-adjustable bench
Section: METAL GABLES & CABLE CHANNEL
ITEM
PREVIEW
NO.
1
2
3
4
5
Part & Product Identification
PART
DESCRIPTION
NUMBER
SIDE COVER ASSY FOR
METAL MID GABLE, N09-8788X-X
DOUBLE SIDED, HAB
SIDE COVER ASSY FOR
METAL MID GABLE, N09-8876R-X
SINGLE SIDED, HAB
BACK COVER ASSY FOR
METAL TRANSITION N09-9083L-X
GABLE, HAB
FRONT COVER ASSY FOR
N09-5182
METAL MID GABLE, HAB
BACK COVER ASSY FOR
N09-9086
METAL MID GABLE, HAB
Installation Guides
ITEM
QTY. PREVIEW
NO.
6
1
7
1
8
1
9
1
10
1 11
Date: Sept 2019
HABN_225f
PART
DESCRIPTION
NUMBER
TOP COVER FOR METAL
MID GABLE W/POWER
A16-7491-X
POLE, DOUBLE SIDED,
HAB
BACK TOP COVER FOR
METAL MID GABLE, A16-7566X
SINGLE SIDED, HAB
BRACKET ASSY. FOR
TRANSITION GABLE, N09-9089
HAB
1/2" DIAMETER x 1/8"
THICK CIRCULAR RARE D03-0059
EARTH MAGNET
SCREW,TAPPING,#6 X
3/8",QUADREX,PAN,TYPE E01-0081
F
1/4-20 UNCx0.500"
2A,CROSS/SQ.COMB.SOC
E01-0110
K.,TRS.HEAD,MACH.SCR.,
STEEL,ZN
Page: 2 of 6
Rev. 00
QTY.
1
1
1
3
3
2
