height-adjustable bench
Section:
SCREENS & GABLES
MOUNT SIDE COVER ASSEMBLY
2
NOTE: Parts of the
Frames are Hidden for
Illustration purpose.
STEP 6: Mount the Side Cover Assembly for Single Sided frame ontothe Stretch Bar As
shown.
Installation Guides
MOUNT BACK COVER ASSEMBLY
STEP 7: Mount the Back Cover Assembly for Transition onto the Frame Link As shown.
Date: Sept 2019
HABN_225g
5
NOTE: Parts of the
Frames are Hidden for
Illustration purpose.
Page: 8 of 11
