height-adjustable bench
Section: SCREENS AND GABLES
SCREEN MOUNTING KIT ASSEMBLY
2.3
STEP 1: Fasten Screen Bar Subassembly and Mounting Bracket to the Screen
NOTE: If 48" & 54" Desk Edge Screen is specified, Rectangular Grommet CANNOT be
installed at the centre.
Installation Guides
STEP 2: Mark Centreline at the bottom of the Worksurface with pencil as shown.
Date: May 2019
HABN_221b
MARK CENTRELINE
Page: 3 of 4
