height-adjustable bench
Section: SCREENS & GABLES
SCREW COVER TO BRACKET
NOTE: Support Bracket ships with
Cable Channel. For Cable Channel
installation procedures, please refer
to guide HABN_223a/223b
STEP 5: Screw the Inside Cover to the bracket using the Screws provided in the Cable
Channel
Installation Guides
2.2
ATTACH BRACKETS TO FRAME
1.2.3
STEP 6: Secure Inner Bracket to frame using the Screws provided.
Date: Sept 2019 Page: 5 of 6
HABN_223e
1.2.1
