Teknion Navigate height-adjustable bench Manual page 207

height-adjustable bench
Section: SCREENS & GABLES
ITEM
NO.
20
21
22
23
24
25
Installation Guides
Part & Product Identification
PREVIEW
1. NAVIGATE TRANSITION MID GABLE, SOLID (HNBCGMSR)x1
DESCRIPTION
HANGING BRACKET, FOR WOOD MID GABLE,
SINGLE SIDED, HAB
CORNER BRKT, TRANSITION SOLID MID GABLE,
HAB
BRACKET ASSY. FOR TRANSITION GABLE, HAB
1/4-20 UNCx0.500"
2A,CROSS/SQ.COMB.SOCK.,TRS.HEAD,MACH.SCR.,ST
EEL,ZN
#10X1/2" TAP SCR, QUAD,PAN
SCREW, WOOD,#6 X 7/16", DEEP THREAD, QUAD,
TRUSS
Date: Sept 2019 Page: 4 of 11
HABN_225g
PART
QTY.
NUMBER
A16-7569R 1
A16-7732 1
N09-9089 1
E01-0110 20
E01-0023 4
E04-0050 10
