Teknion Navigate height-adjustable bench Manual page 111

height-adjustable bench
Section: SOLID GABLES & CABLE CHANNEL
ITEM
PREVIEW
NO.
3. Navigate Mid Gable - Solid - Mid Condition (HNBCGMSN) x1
3.1
3.2
3.3
3.4 &
3.5
3.6
Part & Product Identification
PART
DESCRIPTION
NUMBER
SIDE COVER FOR MID
GABLE, DOUBLE SIDED, C05-8921-X
HAB
SIDE COVER FOR MID
GABLE, DOUBLE SIDED, C05-8863-X
HAB
FRONT COVER FOR MID
C05-8864
GABLE, HAB
TOP COVER FOR WOOD
A16-3087-X
MID GABLE W/POWER
POLE, DOUBLE SIDED,
A16-3088-X
HAB
HANGING BRACKET,
FOR WOOD MID GABLE, A16-3203
HAB
BOTTOM CONNECTING
BRKT FOR WOOD MID A16-3026
GABLE, HAB
Installation Guides
ITEM
QTY.
NO.
3.7
3.8
1
3.9
3.10
1
3.11
3.12
2
3.13
1
&
Each
4
3.14
4
PREVIEW DESCRIPTION
FRONT HANGING BRKT
FOR WOOD MID GABLE,
HAB
BOTTOM BRKT FOR
WOOD MID GABLE, HAB
1/4-20 UNCx0.500"
2A,CROSS/SQ.COMB.
GABEL BOTTOM ANGLE
BAR, DOUBLE SIDED,
HAB
GABEL CONNECTING
PLATE
#10X1/2" TAP SCR,
QUAD,PAN
SCREW, WOOD,#6 X
7/16", DEEP THREAD,
QUAD, TRUSS
TOP COVER FOR WOOD
MID GABLE, HAB
(OPTIONAL)
Date: Feb 2022 Page: 4 of 18
HABN_223b
PART
QTY.
NUMBER
A16-3028 2
A16-3027 2
E01-0110 12
A16-3655-X 2
A16-3651 4
E01-0023 4
E04-0050 10
A16-3029-X 2
