Section:
FRAMES AND WORKSURFACES
Description:
120 HA FRAME
NOTE: The Unit must be leveled at the exact location of
use. If moved after installation or initial leveling, follow
Step 1 and Re-align according to the floor profile.
NOTE: Adjust the Levelers to bring the legs into the same horizontal plane determined with the self-leveling laser leveler, before proceeding to the next step. Refer to Step 1 to adjust levelers.
ALIGN LEGS
Date:
Jan 2024
HABN_123
NOTE: Use Laser Mark
tool to check alignment.
Laser Mark
Page No:
9 of 18
