height-adjustable bench
Installation Guides
Date: Sept 2019
Page: 4 of 6
Section:
SCREENS & GABLES
HABN_223e
LINE UP INSIDE COVER AND BRACKET
SECURE INSIDE COVER TO CONNECTOR
2.2
2.3
2.2
STEP 3: Line up the Cable Channel Bracket with the Inside Cover, and place against the
STEP 4: Use Screws provided to secure the Inside Cover to the Gable Connector
horizontal frame
