Teknion Navigate height-adjustable bench Manual page 277

height-adjustable bench
Section: ELECTRICS
Description: NAVIGATE POWER POLE 120
ATTACH CEILING PLATES
A5a
STEP 9: Attach Ceiling Plates to Power Pole under the ceiling.
Installation Guides
STEP 10: Push T-nuts inside holes from the top of the ceiling tile. Wrap Cover plates around
the Power Pole and fasten using hardware provided.
Date:
HABN_324
FASTEN SCREWS
Sep 2024
Page No: 7 of 7
A5d
A5e
A5f
