Teknion Navigate height-adjustable bench Manual page 182

height-adjustable bench
Section: SCREENS AND GABLES
ITEM
PREVIEW
NO.
1. NAVIGATE END GABLE, METAL, SINGLE SIDED, HAB (HNBCGEMS)
1.1
1.2
1.3
1.4
1.5
Part & Product Identification
DESCRIPTION PART NUMBER QTY.
INSIDE COVER
ASSY FOR
METAL END N09-8863L\30
GABLE, SINGLE
SIDED, HAB
OUTSIDE
COVER ASSY
FOR METAL
N09-8864\30
END GABLE,
SINGLE SIDED,
HAB
2A1 FOAM
RUBBER 3/16
THICK 1/2"
E08-0135
WIDE 12.5"
LONG, GREY
CLOSED CELL
GABEL
CONNECTING A16-3651
PLATE
#10X1/2" TAP
E01-0023
SCR, QUAD,PAN
Installation Guides
ITEM
PREVIEW
NO.
2. NAVIGATE MID GABLE, METAL, SINGLE SIDED, HAB (HNBCGMMS)
2.1
1
2.2
2.3
1
2.4
2
2
2.5
2
2.6
Date: Sept 2019 Page: 2 of 7
HABN_225d
DESCRIPTION PART NUMBER QTY.
TOP COVER
FOR METAL
MID GABLE
A16-7491\60
W/POWER
POLE, DOUBLE
SIDED, HAB
BACK TOP
COVER FOR
METAL MID A16-7566A
GABLE, SINGLE
SIDED, HAB
SIDE COVER
ASSY FOR
METAL MID N09-8876AR\30
GALBE, SINGLE
SIDED, HAB
SIDE COVER
ASSY FOR
METAL MID N09-8876AL\30
GALBE, SINGLE
SIDED, HAB
FRONT COVER
ASSY FOR
N09-5182
METAL MID
GABLE, HAB
1/2" DIAMETER
x 1/8" THICK
CIRCULAR D03-0059
RARE EARTH
MAGNET
1
1
1
1
2
4
