height-adjustable bench
Section: SCREENS & GABLES
INSTALL BRACKET
23
STEP 1:Attach Bracket to Stretcher bar using Screws provided.
Installation Guides
22
NOTE: Refer to HABN_101 for
installation steps for thr Frame Link.
STEP 2: Install Frame Link to join both frames.
NOTE: Refer to HABN_101 for installation steps. Frame Link must be ordered
seperately.
Date: Sept 2019
HABN_225g
INSTALL FRAME LINK
Page: 5 of 11
