height-adjustable bench
Section:
SCREENS AND GABLES
ATTACH SUPPORT BRACKETS
STEP 3: Insert Mounting Pin into the holes inside the Fabric Screen
Installation Guides
1
STEP 4: Rotate Mounting Nuts parallel with the Center Rail Channel, then attach Fabric
Screen into the Center Rail Channel
Date: Sept 2019
HABN_222c
ATTACH SCREEN
Page: 4 of 6
