Teknion Navigate height-adjustable bench Manual page 189

height-adjustable bench
Section: SCREENS AND GABLES
ITEM
PREVIEW
NO.
1. NAVITAGE END GABLE, SOLID, SINGLE SIDED, HAB (HNBCGESS30)
1.1
1.2
1.3
Part & Product Identification
DESCRIPTION PART NUMBER QTY.
COVER FOR END
GABLE, SINGLE C07-4700\30
SIDED, HAB
INSIDE COVER
ASSY FOR WOOD
END GABLE, N09-8869R\30
SINGLE SIDED,
HAB
BOTTOM BRACKET
FOR WOOD END A16-3020
GABLE, HAB
Installation Guides
ITEM
PREVIEW
NO.
1.4
1
1.5
1.6
1.7
2. NAVIGATE MID GABLE, SOLID, SINGLE SIDED, HAB (HNBCGMSS)
1
2.1
2.2
2
2.3
Date: Sept 2019
HABN_225e
DESCRIPTION PART NUMBER QTY.
HANGING
BRACKET FOR
A16-3021
WOOD END
GABLE, HAB
1/4-20 UNCx0.500"
2A,CROSS/SQ.COM
B.SOCK.,TRS.HEAD, E01-0110
MACH.SCR.,STEEL,
ZN
#10X1/2" TAP SCR,
E01-0023
QUAD,PAN
GABEL
CONNECTING A16-3651
PLATE
TOP COVER FOR
WOOD MID GABLE
W/POWER POLE, A16-7456\60
DOUBLE SIDED,
HAB
BACK TOP COVER
FOR WOOD MID
A16-7571A
GABLE, SINGLE
SIDED, HAB
SIDE COVER FOR
MID GABLE,
C07-4718AR\30
SINGLE SIDED,
HAB
Page: 2 of 10
2
4
2
2
1
1
1
