Teknion Navigate height-adjustable bench Manual page 64

height-adjustable bench
Section: SCREENS AND GABLES
ITEM
ILLUSTRATION
NO.
1
2 N/A
2.1
2.2
2.3
2.4
2.5
Installation Guides
Part & Product Identification
PART
NUMBER
N03-2735-X FABRIC DESK EDGE SCREEN SUB-ASSY - HAB
X06-0338-X FABRIC DESK EDGE SCREEN MOUNTING KIT, HAB
A16-2959-X DESK EDGE SCREEN MOUNTING BRKT, HAB
1/4-20 X 1" MACHINE SCREW; QUADREX; FLAT HEAD;
E01-0008
E03-0640 SLOTTED WASHER, 1"OD x 3/8 ID x 1/16 THK, ZINC
E07-0097 #10 X 1", PAN, QUADREX WOOD SCREW,DEEP THREAD,
DESK EDGE FABRIC PERSONAL SCREEN LEVELING
B05-0098
DESCRIPTION
ZINC
ZINK
SHIM
Date: May 2019 Page: 2 of 6
HABN_221c
QTY.
1
1
1
46": 2
52-82": 3
46": 2
52-82": 3
10
46-58": 2
64-82": 4
