Teknion Navigate height-adjustable bench Manual page 233

height-adjustable bench
Section: ELECTRICS
MAKE WIRE CONNECTIONS
NOTE: The Wires are hidden
for illustration purpose.
STEP 3: Make the Wire Connections and Attach the Inner housing.
Installation Guides
NOTE: Licensed Electrician need
to make the Wire Connections.
Before attaching the Inner
Housing to Metal Housing.
FASTEN SCREWS
NOTE: The Wires are hidden
for illustration purpose.
STEP 4: Place Outer Housing as shown above.
Fasten with screws provided then, place the Blank Plate.
Date: Sept 2019 Page: 4 of 7
HABN_321b
1.1
1.3
1.4
