Teknion Navigate height-adjustable bench Manual page 56

height-adjustable bench
Section: SCREENS AND GABLES
ITEM
ILLUSTRATION
NO.
1
2 N/A
2.1
2.2
2.3
2.4
2.5
Part & Product Identification
PART
NUMBER
H01-1921-X 10mm CLEAR (CL) TEMPERED GLASS SCREEN, HAB
10mm FROST (FT) ETCHED TEMPERED GLASS SCREEN,
H02-047-X
H01-1868-X 6mm CLEAR (CL) TEMPERED GLASS SCREEN, HAB
H01-0466-X 6mm FROST (FT) ETCHED TEMPERED GLASS SCREEN, HAB
X06-0337-X 10mm GLASS DESK EDGE SCREEN MOUNTING KIT, HAB
X06-0336-X 6mm GLASS DESK EDGE SCREEN MOUNTING KIT, HAB
N09-5046-X DESK EDGE SCREEN BAR-SUBASSEMBLY FOR GLASS, HAB
DESK EDGE SCREEN MOUNTING BRKT SUB ASSY FOR
N09-5048-X
E03-0523 NYLON BUSH.; OD. 1/2" ID. 0.316" TH. 0.234 (# 13RS050071)
#10 X 1", PAN, QUADREX WOOD SCREW,DEEP THREAD,
E07-0097
E01-0752
E01-0484
Installation Guides
DESCRIPTION
HAB
GLASS, HAB
ZINK
1/4-20 X 7/8" FHMS, SS, QUADREX
1/4-20 X 3/4" MACH SCRW, FLT
Date: May 2019 Page: 2 of 4
HABN_221a
QTY.
1
1
1
1
46-52": 3
58-64": 4
70-82": 5
46": 10
52-58": 14
64-70": 18
76-82": 22
46-52": 3
58-64": 4
70-82": 5
