height-adjustable bench
Installation Guides
Date: Sept 2019
Page: 4 of 8
Section:
SCREENS AND GABLES
HABN_222a
INSERT SPRINGS
LOCK CLAMP
2.6
2.5
2.3
STEP 2: Insert Springs into the Clamps' slots.
STEP 3: Use Allen Key to rotate Mounting Nuts and lock Clamps into Centre Rail.
