height-adjustable bench - Navigate
INDEX
By Section
Product
Product Name
Code
INSTALLATION SUPPORT DOCUMENTS
Typical Installation Sequence
NAVIGATE
FRAMES AND WORKSURFACE
Navigate Frame
HNBFNA
Navigate Frame Link
HNBFNF
Navigate Rectangular Worksurface
HNBWRN
Navigate Systems Link
HNBFNS
Navigate 120 Frame
HNBFNT
Navigate 120 Worksurface
HNBWTN
Navigate Single-Sided Frame
HNBFNZ
Navigate Single-Sided Rectangular
HNBWES
Extended Worksurface
Navigate Single-Sided Rectangular
HNBWRS
Worksurface
SCREENS AND GABLES
Navigate Desk Edge Screen - Glass
HNBCDG
Navigate Desk Edge Screen - Solid
HNBCDS
Navigate Desk Edge Screen - Fabric
HNBCDF
Navigate Fixed Center Screen - Glass
HNBCFG
Navigate Fixed Center Screen - Solid
HNBCFS
Navigate Fixed Center Screen - Fabric
HNBCFF
Navigate Cable Channel
HNBFCN
Navigate End Gable - Metal
HNBCGEMN
Navigate Mid Gable - Metal
HNBCGMMN
Navigate Cable Channel
HNBFCN
Navigate Mid Gable - Solid
HNBCGMSN
Navigate End Gable - Solid
HNBCGESN
Navigate End Cover - Metal
HNBCCEMN 223c
Navigate Mid Cover - Metal
HNBCCMMN
Navigate End Screen Cover - Metal
HNBCCSMN 223d
Navigate End of Run Screen - Fabric
HNBTEF
Jan 2024
*Click on the desired Installation Guide to jump to the Guide
page.
Guide
Last
No.
Updated
Product Name
SCREENS AND GABLES
Sep 2018
Navigate End Screen Gable - Metal
Navigate End of Run Screen - Fabric
Navigate Wire Channel - Single Sided
121
Jan 2024
Navigate Single-Sided Corridor Screen - HNBLSF
Fabric
Navigate Single-Sided Corridor Screen - HNBLSS
122
May 2019
Solid
123
Jan 2024
Navigate 120 Mid Cover
Navigate 120 Mid Gable Solid
124
Sep 2024
Navigate 120 Mid Gable, Metal
Navigate Single-Sided End Cover - Metal HNBCCEMS
Navigate Single-Sided Mid Cover - Metal
Navigate Single-Sided End Screen
Cover - Metal
Navigate Single-Sided End of Run
221a
May 2019
Screen - Fabric
221b
May 2019
Navigate Single-Sided End Screen
221c
May 2019
Gable - Metal
222a
Sep 2019
Navigate Single-Sided End of Run
222b
Sep 2019
Screen - Solid
222c
Sep 2019
Navigate Single-Sided End Gable - Metal HNBCGEMS
223a
Feb 2022
Navigate Single-Sided Mid Gable - Metal HNBCGMMS
Navigate Single-Sided End Gable - Solid HNBCGESS
Navigate Single-Sided Mid Gable - Solid HNBCGMSS
223b
Feb 2022
Navigate Single-Sided Transition Mid
Gable - Metal
Navigate Single-Sided Transition Mid
May 2019
Gable - Solid
Navigate End of Run Screen - Solid
Aug 2019
Navigate Single Sided Solid Screen
Connection Bracket
Product
de
Last
Code
No.
Updated
Product Name
ELECTRICS
223e Sep 2019
Navigate Power Harness
HNBCGSMN
Navigate Power Module
HNBTEF
223f Sep 2024
Navigate Receptacle Outlet
HNBFCNS
224 Sep 2019
Navigate I-Connector
Navigate Chicago Power Module
Navigate Single-Sided Chicago Power
Module
224a May 2019
Navigate Base Feed
HNBCCMMT
224b Sep 2019
Navigate Base Feed Cover
HNBCGMST
Navigate Chicago Base Feed
HNBCGMMT
225a Sep 2019
Navigate Split Base Feed
Navigate Ceiling Feed
225b Sep 2019
Navigate Chicago Ceiling Feed
HNBCCSMS
Navigate Power Pole - End
Navigate Ceiling Feed
HNBTSF
Navigate Chicago Ceiling Feed
225c Sep 2019
Navigate Power Pole - Mid
HNBCGSMS
Navigate Power Pole(Single Sided Bench) HNBEPP
Navigate Power Conservation System
HNBTSS
Navigate Power Pole 120
225d Sep 2019
Navigate Ceiling Feed
Center Electrical Grommet
225e Sep 2019
Navigate E-Chain Vertical Cable Manager HNBEEE
225f Sep 2019
HNBCGMMR
225g Sep 2019
HNBCGMSR
225h Sep 2024
HNBTES
226 Sep 2020
HNBLBS
Product
Guide
Last
Code
No.
Updated
Sep 2019
321a
HNBEPH
HNBEPM
HNBERO
HNBEIC
HNBEPMCH 321b
Sep 2019
HNBEPSCH
321c
May 2022
HNBEBF
HNBEBC
HNBEBFCH
HNBEBFS
Sep 2019
322a
HNBECF
HNBECFCH
HNBEPP
May 2022
322b
HNBECF
HNBECFCH
HNBEPP
323
Sep 2024
HNBEPC
HNBEPPT 324
Sep 2024
HNBECF
HNBECEG 325
Sep 2019
326
Sep 2023
PAGE 1 OF 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Teknion Navigate height-adjustable bench
Summary of Contents for Teknion Navigate height-adjustable bench
- Page 1 height-adjustable bench - Navigate INDEX *Click on the desired Installation Guide to jump to the Guide By Section page. Product Guide Last Product Last Product Guide Last Product Name Code Updated Product Name Code Updated Product Name Code Updated INSTALLATION SUPPORT DOCUMENTS SCREENS AND GABLES ELECTRICS Typical Installation Sequence...
- Page 2 Section: FRAMES AND WORKSURFACES Date: Jan 2024 1 of 16 Page No: Description: DOUBLE SIDED HA FRAME HABN_121 Rev. No: 2 Navigate Double-Sided HA Frame (HNBFNA), Frame Link (HNBFNF) and Navigate Rectangular Worksurface (HNBWRN)
- Page 3 Section: FRAMES AND WORKSURFACES Date: Jan 2024 2 of 16 Page No: Description: DOUBLE SIDED HA FRAME HABN_121 Rev. No: 2 Part and Product Identification A - Navigate Standard Range Electric Frame (HNBFNA)x1 Frame Assembly (N09-8679)x1 A6 - Navigate Strut Cover (A25-0631)x4 A1 - Navigate HAB Leg Assy (N09-8583L)x2...
- Page 4 Section: FRAMES AND WORKSURFACES Date: Jan 2024 3 of 16 Page No: Description: DOUBLE SIDED HA FRAME HABN_121 Rev. No: 2 Part and Product Identification A - Navigate Standard Range Electric Frame (HNBFNA)x1 A15 - Power Supply A16 - Cable Felt Organizer A17 - Plastic Tray Cable A18 - Plastic Tray Cable (I04-0100)x2...
- Page 5 Section: FRAMES AND WORKSURFACES Date: Jan 2024 Page No: 4 of 16 Description: DOUBLE SIDED HA FRAME HABN_121 INSTALL HEIGHT-ADJUSTABLE LEGS FASTEN SCREWS TO SECURE LEGS A14b STEP 1: Slide Height-Adjustable legs into the cross beam as shown above. STEP 2: Fasten screws to secure legs to Top Channel.
- Page 6 Section: FRAMES AND WORKSURFACES Date: Jan 2024 Page No: 5 of 16 Description: DOUBLE SIDED HA FRAME HABN_121 REPEAT STEP 1 & STEP 2 ATTACH STRETCHER BAR TO LEGS A14c STEP 3: Repeat Step 1 to Step 2, for the other leg assembly. STEP 4: Attach Stretcher Bar to legs as shown above, with screws provided.
- Page 7 Section: FRAMES AND WORKSURFACES Date: Jan 2024 Page No: 6 of 16 Description: DOUBLE SIDED HA FRAME HABN_121 ATTACH STRUTS TO ALL LEG ASSEMBLIES A14b STEP 5: Attach Struts to all leg assemblies.
- Page 8 Section: FRAMES AND WORKSURFACES Date: Jan 2024 Page No: 7 of 16 Description: DOUBLE SIDED HA FRAME HABN_121 ATTACH STRUTS COVERS TO STRUTS A14d STEP 5: Attach Struts covers to struts installed with screws provided.
- Page 9 Section: FRAMES AND WORKSURFACES Date: Jan 2024 Page No: 8 of 16 Description: DOUBLE SIDED HA FRAME HABN_121 INSTALL FRAME LINK (OPTIONAL) STEP 7: Fasten Frame Link to one of the table frame Stretcher Bars first, as indicated. Bring over second frame and attach stretcher bar to Frame link as shown above.
- Page 10 Section: FRAMES AND WORKSURFACES Date: Jan 2024 Page No: 9 of 16 Description: DOUBLE SIDED HA FRAME HABN_121 ATTACH POWER MODULE (OPTIONAL) ATTACH POWER MODULE COVER (OPTIONAL) STEP 8a: Attach Power Module as shown above. STEP 8b: Attach Power Module Cover as shown above.
- Page 11 Section: FRAMES AND WORKSURFACES Date: Jan 2024 Page No: 10 of 16 Description: DOUBLE SIDED HA FRAME HABN_121 WIRE CONNECTIONS A10a A14i NOTE: Make sure that the Dongle is connected to the control box. A10b STEP 9: Make the Wire Connections as shown above.
- Page 12 Section: FRAMES AND WORKSURFACES Date: Jan 2024 Page No: 11 of 16 Description: DOUBLE SIDED HA FRAME HABN_121 ATTACH WORKSURFACE TO FRAME A14a A14a STEP 10: Attach Worksurface to Frame with screws provided.
- Page 13 Section: FRAMES AND WORKSURFACES Date: Jan 2024 Page No: 12 of 16 Description: DOUBLE SIDED HA FRAME HABN_121 ALIGN WORKSURFACE STEP 11: Align Worksurface as shown above.
- Page 14 Section: FRAMES AND WORKSURFACES Date: Jan 2024 Page No: 13 of 16 Description: DOUBLE SIDED HA FRAME HABN_121 ATTACH SWITCH TO WORKSURFACE A14l STEP 12: Attach Switch to Worksurface as shown above. Secure with the screws provided.
- Page 15 Section: FRAMES AND WORKSURFACES Date: Jan 2024 Page No: 14 of 16 Description: DOUBLE SIDED HA FRAME HABN_121 ATTACH CABLE CLAMPS A14h A14e A14g A14g STEP 13: Using wire/Cable Clips and Screws, organize wires as shown above.
- Page 16 Section: FRAMES AND WORKSURFACES Date: Jan 2024 Page No: 15 of 16 Description: DOUBLE SIDED HA FRAME HABN_121 ATTACH CONTROL BOX TO WORKSURFACE ATTACH CONTROL BOX COVER A14f STEP 14: Attach Control box to worksurface with screws provided. STEP 15: Attach Control Box cover as shown above.
- Page 17 Section: FRAMES AND WORKSURFACES Date: Jan 2024 Page No: 16 of 16 Description: DOUBLE SIDED HA FRAME HABN_121 PLASTIC TRAY CABLE MANAGEMENT (OPTIONAL) CABLE ORGANIZER (OPTIONAL) NOTE: Refer to COM_151b for Dual NOTE: Refer to COM_151a Plastic Tray Cable Management. for Cable Organizer.
- Page 18 height adjustable bench Installation Guides Date: May 2019 Page: 1 of 5 Section: FRAMES & WORKSURFACE HABN_122 Rev. 1 NAVIGATE SYSTEMS LINK (HNBFNS) End Leg height- adjustable Bench (HAB) Frame IMPORTANT: The System Link is not intended to provide structural support to the Interpret Frame. Interpret Frame The System Link MUST ONLY be installed to Complete Interpret Frames with End Legs.
- Page 19 height adjustable bench Installation Guides Date: May 2019 Page: 2 of 5 Section: FRAMES & WORKSURFACE HABN_122 Part & Product Identification ITEM NO. PREVIEW DESCRIPTION PART NUMBER QTY. SYSTEM LINK TOP BRKT SUB ASSY, HAB TO N09-5120 INTERPRET SYSTEM LINK BOTTOM BRACKET, HAB TO INTERPRET A16-3051 SYSTEM LINK COVER, HAB TO INTERPRET A16-3200...
- Page 20 height adjustable bench Installation Guides Date: May 2019 Page: 3 of 5 Section: FRAMES & WORKSURFACE HABN_122 ATTACH TOP BRACKET TO INTERPRET FRAME PLACE BOTTOM BRACKET IN PLACE Center Beam Interpret Frame NOTE: DO NOT fully tighten nuts STEP 1: Using Interpret Frame Nuts, fasten Top Bracket to Center Beam of Interpret Frame, STEP 2: Place Bottomg Bracket in plscce by inserting Top Bracket studs into Bottom Bracket as shown.
- Page 21 height adjustable bench Installation Guides Date: May 2019 Page: 4 of 5 Section: FRAMES & WORKSURFACE HABN_122 ATTACH BOTTOM BRACKET TO HAB FRAME TIGHTEN BRACKET NUTS Stretcher Bar : HAB Frame NOTE: Make sure to level both Frames before tightening the system link nuts STEP 3: Align Bottom Bracket &...
- Page 22 height adjustable bench Installation Guides Date: May 2019 Page: 5 of 5 Section: FRAMES & WORKSURFACE HABN_122 ROUTE CABLES THROUGH SYSTEM LINK INSTALL FRAME LINK COVER UNDERSIDE VIEW OPTIONAL Connects to Interpret Connects to STEP 5: Route cables through System Link to electrically connect both systems STEP 6: Insert the Top Bracket hooks into the vertical slots on the System Link Cover and allow Cover to slide slightly down...
- Page 23 Section: FRAMES AND WORKSURFACES Date: Jan 2024 1 of 18 Page No: Description: 120 HA FRAME HABN_123 Rev. No: 2 Navigate 120 HA Frame (HNBFNT) and Navigate 120 Worksurface (HNBWTN)
- Page 24 Section: FRAMES AND WORKSURFACES Date: Jan 2024 2 of 18 Page No: Description: 120 HA FRAME HABN_123 Rev. No: 1 Parts & Products Indentification A - HAB Navigate 120 Frame (HNBFNT) x1 Frame Assm. Std Range Elec (N09-9008) x1 A1 - Navigate 120 HAB A8 - Navigate Strut Mid Gable Stratcher (A25-0630) x6...
- Page 25 Section: FRAMES AND WORKSURFACES Date: Jan 2024 3 of 18 Page No: Description: 120 HA FRAME HABN_123 Rev. No: 1 Part and Product Identification A19 - Plastic Tray Cable A18 - Cable Felt Organizer A20 - Plastic Tray Cable Management w/ IEC (N09-9781)x1 (YEYA01)x1 Management (YEYS01)x1 B - Navigate 120 Worksurface...
- Page 26 Section: FRAMES AND WORKSURFACES Date: Jan 2024 Page No: 4 of 18 Description: 120 HA FRAME HABN_123 LEVELLER ADJUSTMENT ASSEMBLE LEG AND MID GABLE STRATCHER Hanger Plate A17c NOTE: For Mid Gable assembly, refer to HABN_224b. STEP 1: Adjust the Leveller to have a 0.5" Gap on all the Legs. STEP 2: Assemble legs and Mid Gable stretcher as shown above.
- Page 27 Section: FRAMES AND WORKSURFACES Date: Jan 2024 Page No: 5 of 18 Description: 120 HA FRAME HABN_123 ATTACH POWER POLE MOUNT (OPTIONAL) ASSEMBLE CENTRE LEG TOP MOUNT A17b Power Pole Mount NOTE: For Power Pole assembly, refer to HABN_324. A17b STEP 3: Attach Power pole mount as shown above with screws and washers provided.
- Page 28 Section: FRAMES AND WORKSURFACES Date: Jan 2024 Page No: 6 of 18 Description: 120 HA FRAME HABN_123 INSTALL CROSS BEAM A17b STEP 5: Place Cross Beam as shown. Secure the cross beam using the Screws provided.
- Page 29 Section: FRAMES AND WORKSURFACES Date: Jan 2024 Page No: 7 of 18 Description: 120 HA FRAME HABN_123 INSTALL LEG ASSEMBLIES A17b A17b STEP 6: Place Cross Beam into the cross beam. Secure the Leg assemblies using the screws provided.
- Page 30 Section: FRAMES AND WORKSURFACES Date: Jan 2024 Page No: 8 of 18 Description: 120 HA FRAME HABN_123 INSTALL STRETCHER WELDMENT A17c A17c STEP 7: Align Stretcher Weldment as as shown above. Assemble Stretcher weldment with screws provided.
- Page 31 Section: FRAMES AND WORKSURFACES Date: Jan 2024 Page No: 9 of 18 Description: 120 HA FRAME HABN_123 ALIGN LEGS NOTE: The Unit must be leveled at the exact location of NOTE: Use Laser Mark use. If moved after installation or initial leveling, follow tool to check alignment.
- Page 32 Section: FRAMES AND WORKSURFACES Date: Jan 2024 Page No: 10 of 18 Description: 120 HA FRAME HABN_123 ATTACH STRUTS TO FRAME A17b STEP 8: Attach the Struts to the Leg assemblies and Secure it using the Screws provided.
- Page 33 Section: FRAMES AND WORKSURFACES Date: Jan 2024 Page No: 11 of 18 Description: 120 HA FRAME HABN_123 ATTACH STRUT COVERS A17b STEP 9: Attach the Strut Covers and Secure it using the Screws provided.
- Page 34 Section: FRAMES AND WORKSURFACES Date: Jan 2024 Page No: 12 of 18 Description: 120 HA FRAME HABN_123 POWER MODULE (OPTIONAL) POWER MODULE COVER (OPTIONAL) A12a A12c A12b STEP 10a: Attach Power Module as shown above and Secure using the Screws provided. STEP 10b: Attach Power Module Cover as shown above and Secure using the screws provided.
- Page 35 Section: FRAMES AND WORKSURFACES Date: Jan 2024 Page No: 13 of 18 Description: 120 HA FRAME HABN_123 WIRE CONNECTION A12a A13c A13b A13a A17i A13c A13b NOTE: Plug IEC Connector from item A12a A12a into item A11 to power the actuator. A12a Dongle NOTE: Make sure that the Dongle...
- Page 36 Section: FRAMES AND WORKSURFACES Date: Jan 2024 Page No: 14 of 18 Description: 120 HA FRAME HABN_123 WORKSURFACE AND SWITCH-1 A17a NOTE: The Power Module wire has been Hidden for Illustration Purpose. A17l STEP 12: Place Worksurface on the Frame assembly and Fasten with Screws provided. Place the Switch under the Worksurface and Fasten with Screws provided.
- Page 37 Section: FRAMES AND WORKSURFACES Date: Jan 2024 Page No: 15 of 18 Description: 120 HA FRAME HABN_123 WORKSURFACE AND SWITCH-2 NOTE: Align Top and Side edges of all Worksurfaces. STEP 13: Align the Side edges and Top Surface with other Worksurfaces.
- Page 38 Section: FRAMES AND WORKSURFACES Date: Jan 2024 Page No: 16 of 18 Description: 120 HA FRAME HABN_123 WORKSURFACE AND SWITCH-3 A17m NOTE: The Power Module wire has been Hidden for Illustration Purpose. STEP 14: Fasten Worksurfaces with the Frame assembly.
- Page 39 Section: FRAMES AND WORKSURFACES Date: Jan 2024 Page No: 17 of 18 Description: 120 HA FRAME HABN_123 ATTACH CONTROL BOX COVER A17f NOTE: The Power Module wire has been Hidden for Illustration Purpose. STEP 15: Secure the Control Box to the Worksurfaces using the Screws provided. Then Attach the Control Box cover to the Cross Beam.
- Page 40 Section: FRAMES AND WORKSURFACES Date: Jan 2024 Page No: 18 of 18 Description: 120 HA FRAME HABN_123 ATTACH FELT COVER CABLE ORGANIZER ATTACH DUAL PLASTIC TRAY CABLE MANAGEMENT NOTE: If YEYS is specified, NOTE: If YEYA is specified, refer refer to Complement Guide to Complement Guide COM_151a.
- Page 41 height-adjustable bench Installation Guides FRAMES AND WORKSURFACES Section: Date: Sep 2024 Page No: 1 of 14 Description: SINGLE SIDED HA FRAME HABN_124 Rev. No: 3 Navigate Single-Sided HA Frame (HNBFNZ), Navigate Rectangular Worksurface (HNBWRS), Navigate Rectangular Extended Worksurface (HNBWES)
- Page 42 height-adjustable bench Installation Guides FRAMES AND WORKSURFACES Section: Date: Sep 2024 Page No: 2 of 14 Description: SINGLE SIDED HA FRAME HABN_124 Rev. No: 3 Part and Product Identification Navigate Single Sided Std. Range Electric Frame (HNBFNZ)x1 A - Frame Assembly (N09-9082) x1 or (N09-9070) x1 A13 - Counter Weight, A14 - Counter Weight, A12 - Counter Weight...
- Page 43 height-adjustable bench Installation Guides FRAMES AND WORKSURFACES Section: Date: Sep 2024 Page No: 3 of 14 Description: SINGLE SIDED HA FRAME HABN_124 Rev. No: 3 Part and Product Identification Navigate Single Sided Std. Range Electric Frame (HNBFNZ) x1 Worksurface G - Cable Felt Organizer B - Integrated Power Bar (YEYA01) x0 or x1 (N08-8157) x1...
- Page 44 height-adjustable bench Installation Guides Section: FRAMES AND WORKSURFACES Date: Sep 2023 Page No: 4 of 14 Description: SINGLE SIDED HA FRAME HABN_124 INSTALL HEIGHT-ADJUSTABLE LEGS FASTEN SCREWS TO SECURE LEGS A22b STEP 1: Slide Height-Adjustable legs into the cross beam as shown above. STEP 2: Fasten screws to secure legs to Top Channel.
- Page 45 height-adjustable bench Installation Guides Section: FRAME AND WORKSURFACES Date: Sep 2023 Page No: 5 of 14 Description: SINGLE SIDED HA FRAME HAB_124 ALIGN LEGS NOTE: Use laser mark tool to check alignment. Laser Mark Laser Mark NOTE: Align laser mark as shown above before proceeding to the next step. If misaligned, adjust levelers.
- Page 46 height-adjustable bench Installation Guides Section: FRAMES AND WORKSURFACES Date: Sep 2023 Page No: 6 of 14 Description: SINGLE SIDED HA FRAME HABN_124 ATTACH STRUT ATTACH STRUT COVERS A22b A22d STEP 3: Attach Struts to all leg assemblies and Secure using the screws provided. STEP 4: Attach Strut covers to struts installed and secure with screws provided.
- Page 47 height-adjustable bench Installation Guides Section: FRAMES AND WORKSURFACES Date: Sep 2023 Page No: 7 of 14 Description: SINGLE SIDED HA FRAME HABN_124 ATTACH STRETCHER REMOVE LEG COVER & ADD COUNTER WEIGHTS A22c STEP 5: Attach Stretchers to the Frame as shown above and and Secure using the screws STEP 6: Remove covers from Rear Legs.
- Page 48 height-adjustable bench Installation Guides Section: FRAMES AND WORKSURFACES Date: Sep 2023 Page No: 8 of 14 Description: SINGLE SIDED HA FRAME HABN_124 ATTACH REAR LEGS TO STRETCHER BARS Rear Leg Assembly A22c Rear Leg Assembly STEP 7: Attach Rear Legs to the Stretcher bars and secure it using the screws provided. Adjust levelers if needed.
- Page 49 height-adjustable bench Installation Guides Section: FRAMES AND WORKSURFACES Date: Sep 2023 Page No: 9 of 14 Description: SINGLE SIDED HA FRAME HABN_124 ATTACH POWER MODULE (OPTIONAL) ATTACH POWER MODULE COVER (OPTIONAL) STEP 8a: Attach Power Module as shown above. STEP 8b: Attach Power Module Cover as shown above.
- Page 50 height-adjustable bench Installation Guides Section: FRAMES AND WORKSURFACES Date: Sep 2023 Page No: 10 of 14 Description: SINGLE SIDED HA FRAME HABN_124 WIRE CONNECTIONS A22i NOTE: Make sure that the Dongle is connected to the control box. STEP 9: Make the Wire Connections as shown above.
- Page 51 height-adjustable bench Installation Guides Section: FRAMES AND WORKSURFACES Date: Sep 2023 Page No: 11 of 14 Description: SINGLE SIDED HA FRAME HABN_124 ATTACH WORKSURFACE TO FRAME A22l A14a A22a STEP 10: Attach Worksurface to Frame with screws provided.
- Page 52 height-adjustable bench Installation Guides Section: FRAMES AND WORKSURFACES Date: Sep 2023 Page No: 12 of 14 Description: SINGLE SIDED HA FRAME HABN_124 SECURE CONTROL BOX ATTACH CONTROL BOX COVER A22h STEP 11a: Secure Control Box to the Worksurface using the Screws provided. STEP 11b: Attach Control Box Cover to the Cross Beam.
- Page 53 height-adjustable bench Installation Guides Section: FRAMES AND WORKSURFACES Date: Sep 2023 Page No: 13 of 14 Description: SINGLE SIDED HA FRAME HABN_124 ATTACH CABLE CLAMPS A22f A22e A22g A22g STEP 12: Using wire/Cable Clips and Screws, organize wires as shown above.
- Page 54 height-adjustable bench Installation Guides Section: FRAMES AND WORKSURFACES Date: Sep 2023 Page No: 14 of 14 Description: SINGLE SIDED HA FRAME HABN_124 PLASTIC TRAY CABLE MANAGEMENT (OPTIONAL) CABLE ORGANIZER (OPTIONAL) NOTE: Refer to COM_151b for Dual NOTE: Refer to COM_151a Plastic Tray Cable Management.
- Page 55 height-adjustable bench Installation Guides Date: May 2019 Page: 1 of 4 Section: SCREENS AND GABLES HABN_221a Rev. 0 DESK EDGE SCREEN - GLASS (HNBCDG)
- Page 56 height-adjustable bench Installation Guides Date: May 2019 Page: 2 of 4 Section: SCREENS AND GABLES HABN_221a Part & Product Identification ITEM PART ILLUSTRATION DESCRIPTION QTY. NUMBER H01-1921-X 10mm CLEAR (CL) TEMPERED GLASS SCREEN, HAB 10mm FROST (FT) ETCHED TEMPERED GLASS SCREEN, H02-047-X H01-1868-X 6mm CLEAR (CL) TEMPERED GLASS SCREEN, HAB...
- Page 57 height-adjustable bench Installation Guides Date: May 2019 Page: 3 of 4 Section: SCREENS AND GABLES HABN_221a SCREEN MOUNTING KIT ASSEMBLY MARK CENTRELINE STEP 1: Fasten Screen Bar Subassembly and Mounting Bracket to the Glass Screen STEP 2: Mark Centreline at the bottom of the Worksurface with pencil as shown. NOTE: If 48"...
- Page 58 height-adjustable bench Installation Guides Date: May 2019 Page: 4 of 4 Section: SCREENS AND GABLES HABN_221a ATTACH & ALIGN SCREEN SECURE SCREEN Bottom View Detail View STEP 3: Attatch Mounting Bracket to the back of the Worksurface. Make sure the cut out of STEP 4: Fasten mounting Bracket to the underside of the Worksurface as shown.
- Page 59 height-adjustable bench Installation Guides Date: May 2019 Page: 1 of 4 Section: SCREENS AND GABLES HABN_221b Rev. 0 DESK EDGE SCREEN - SOLID (HNBCDS)
- Page 60 height-adjustable bench Installation Guides Date: May 2019 Page: 2 of 4 Section: SCREENS AND GABLES HABN_221b Part & Product Identification ITEM PART ILLUSTRATION DESCRIPTION QTY. NUMBER C05-8870-X DESK EDGE WOOD SCREEN, HAB X06-0339-X SOLID DESK EDGE SCREEN MOUNTING KIT, HAB A16-2959-X DESK EDGE SCREEN MOUNTING BRKT, HAB N09-5045-X...
- Page 61 height-adjustable bench Installation Guides Date: May 2019 Page: 3 of 4 Section: SCREENS AND GABLES HABN_221b SCREEN MOUNTING KIT ASSEMBLY MARK CENTRELINE STEP 1: Fasten Screen Bar Subassembly and Mounting Bracket to the Screen STEP 2: Mark Centreline at the bottom of the Worksurface with pencil as shown. NOTE: If 48"...
- Page 62 height-adjustable bench Installation Guides Date:May 2019 Page: 4 of 4 Section: SCREENS AND GABLES HABN_221b ATTACH & ALIGN SCREEN SECURE SCREEN STEP 3: Attatch Mounting Bracket to the back of the Worksurface. Make sure the cut out of STEP 4: Fasten mounting Bracket to the underside of the Worksurface as shown. he Bracket aligns with the marked Centreline.
- Page 63 height-adjustable bench Installation Guides Date: May 2019 Page: 1 of 6 Section: SCREENS AND GABLES HABN_221c Rev. 0 DESK EDGE SCREEN - FABRIC (HNBCDF)
- Page 64 height-adjustable bench Installation Guides Date: May 2019 Page: 2 of 6 Section: SCREENS AND GABLES HABN_221c Part & Product Identification ITEM PART ILLUSTRATION DESCRIPTION QTY. NUMBER N03-2735-X FABRIC DESK EDGE SCREEN SUB-ASSY - HAB X06-0338-X FABRIC DESK EDGE SCREEN MOUNTING KIT, HAB A16-2959-X DESK EDGE SCREEN MOUNTING BRKT, HAB 1/4-20 X 1"...
- Page 65 height-adjustable bench Installation Guides Date: May 2019 Page: 3 of 6 Section: SCREENS AND GABLES HABN_221c SCREEN MOUNTING KIT ASSEMBLY INSERT WASHER & TIGHTEN BRACKET Side View STEP 1: Fasten Screen Bar Subassembly and Mounting Bracket to the Screen looseley. STEP 2: Insert Slotted Washers to Screws between Bracket and Fabric Frame, then Tighten the Screws fully.
- Page 66 height-adjustable bench Installation Guides Date: May 2019 Page: 4 of 6 Section: SCREENS AND GABLES HABN_221c MARK CENTRELINE STEP 3: Mark Centreline at the bottom of the Worksurface with a pencil as shown.
- Page 67 height-adjustable bench Installation Guides Date: May 2019 Page: 5 of 6 Section: SCREENS AND GABLES HABN_221c ATTACH & ALIGN SCREEN SECURE SCREEN Detail View Detail View STEP 4: Attatch Mounting Bracket to the back of the Worksurface. Make sure the cut-out of STEP 5: Fasten mounting Bracket to the underside of the Worksurface as shown.
- Page 68 height-adjustable bench Installation Guides Date: May 2019 Page: 6 of 6 Section: SCREENS AND GABLES HABN_221c ATTACH SHIMS ATTACH SHIMS OPTIONAL OPTIONAL STEP 6a: Unmount the screen, attach Shims by the edge of the bracket as illustrated and STEP 6b: Unmount the screen and attach Shims on the screen's side of the bracket as reinstall Screen.
- Page 69 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 8 Section: SCREENS AND GABLES HABN_222a Rev. 01 Fixed Centre Screen - Glass (HNBCFG)
- Page 70 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 8 Section: SCREENS AND GABLES HABN_222a Part & Product Identification ITEM ILLUSTRATION PART NUMBER DESCRIPTION QTY. 10mm CLEAR (CL) TEMPERED GLASS, FULL STYLE, FIXED HEIGHT SCREEN, H01-1860-X 10mm FROST (FT) ETCHED TEMPERED GLASS, FULL STYLE, FIXED HEIGHT H02-0467-X SCREEN, HAB 2.
- Page 71 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 8 Section: SCREENS AND GABLES HABN_222a INSERT CLAMP INTO CENTRE RAIL CLAMP LOCATIONS EQ = Eually Spaced FRONT VIEW MAX 27" MAX 27" NOTE: Make sure to USE ALL THE CLAMPS PROVIDED and space them as indicated on these drawings.
- Page 72 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 8 Section: SCREENS AND GABLES HABN_222a INSERT SPRINGS LOCK CLAMP STEP 2: Insert Springs into the Clamps' slots. STEP 3: Use Allen Key to rotate Mounting Nuts and lock Clamps into Centre Rail.
- Page 73 height-adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 8 Section: SCREENS AND GABLES HABN_222a INSTALL END CAPS INSERT RUBBER PADS AND SCREEN STEP 4: Insert both End Caps into Clamps STEP 5: Insert Rubber pads and Glass Screen into Clamps, as shown.
- Page 74 height-adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 8 Section: SCREENS AND GABLES HABN_222a INSERT SPACERS SIDE VIEW STEP 6: Insert spacers as shwon, on one side first, in between the Rubber Pads and the Clamps. Insert remaining spacers on the other side...
- Page 75 height-adjustable bench Installation Guides Date: Sept 2019 Page: 7 of 8 Section: SCREENS AND GABLES HABN_222a LOCK IN PLACE & LEVEL SCREEN (SIDE 1) LOCK IN PLACE & LEVEL SCREEN (SIDE 2) Opposite Side STEP 7a: Tighten Set Screws on both sides at the same time to make sure the Glass is located STEP 7b: Tighten Set Screws on both sides at the same time to make sure the Glass is located in the centre of the Clamps.
- Page 76 height-adjustable bench Installation Guides Date: Sept 2019 Page: 8 of 8 Section: SCREENS AND GABLES HABN_222a INSTALL BOTTOM COVERS SIDE VIEW STEP 8: Mount Bottom Covers on both sides of Clamps. NOTE: Make sure Covers click on the springs.
- Page 77 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 7 Section: SCREENS AND GABLES HABN_222b Rev. 01 Fixed Centre Screen - Solid (HNBCFS)
- Page 78 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 7 Section: SCREENS AND GABLES HABN_222b Part & Product Identification PART ITEM NO. DESCRIPTION QTY. ILLUSTRATION NUMBER C05-8955-X WOOD PANEL, FULL STYLE, FIXED HEIGHT SCREEN, HAB 2. WOOD CLAMP SUB ASSY. (N09-3980) (SEE PAGE 3 FOR QTY) A25-0395 CLAMP, WOOD CASUAL SCREEN A25-0396...
- Page 79 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 7 Section: SCREENS AND GABLES HABN_222b INSERT CLAMP INTO CENTRE RAIL CLAMP LOCATIONS EQ = Eually Spaced FRONT VIEW 27" MAX 27" MAX NOTE: Make sure to use all the clamps provided and space them as indicated on these drawings.
- Page 80 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 7 Section: SCREENS AND GABLES HABN_222b INSERT SPRINGS LOCK CLAMP STEP 2: Insert Springs into the Clamps' slots. STEP 3: Use Alen Key to rotate Mounting Nuts and lock Clamps into Centre Rail.
- Page 81 height-adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 7 Section: SCREENS AND GABLES HABN_222b INSTALL END CAPS FRONT SPACERS AND SCREEN STEP 4: Insert both End Caps into Clamps STEP 5: Insert front spacers and Screen into Clamps, as shown.
- Page 82 height-adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 7 Section: SCREENS AND GABLES HABN_222b INSERT SPACERS SIDE VIEW STEP 6: Insert the remaining spacers spacers as shown on the remaining side.
- Page 83 height-adjustable bench Installation Guides Date: Sept 2019 Page: 7 of 7 Section: SCREENS AND GABLES HABN_222b SECURE SCREEN INSTALL BOTTOM COVERS STEP 7: Secure Screen by tightening Set Screws as shown. STEP 8: Mount Bottom Covers on both sides of Clamps. NOTE: Make sure Covers click as they are pushed into place.
- Page 84 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 6 Section: SCREENS AND GABLES HABN_222c Rev. 02 NAVIGATE FIXED CENTER SCREEN (HNBCFF)
- Page 85 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 6 Section: SCREENS AND GABLES HABN_222c Part & Product Identification ITEM NO. PREVIEW DESCRIPTION PART NUMBER QTY. HNB FIXED CENTRE SCREEN - FRAMED FABRIC HNBCFFXX MOUNTING KIT (X03-0283) SCREEN MOUNTING PIN A18-0251 BUSHING - FABRIC SCREEN B02-0469...
- Page 86 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 6 Section: SCREENS AND GABLES HABN_222c ASSEMBLE SUPPORT BRACKET INSERT ALLEN KEY STEP 1: Attach Mounting Pin, Support Bracket and Bushing as shown STEP 2: Insert Allen Key through the hole on the Mounting Pin...
- Page 87 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 6 Section: SCREENS AND GABLES HABN_222c ATTACH SUPPORT BRACKETS ATTACH SCREEN STEP 3: Insert Mounting Pin into the holes inside the Fabric Screen STEP 4: Rotate Mounting Nuts parallel with the Center Rail Channel, then attach Fabric Screen into the Center Rail Channel...
- Page 88 height-adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 6 Section: SCREENS AND GABLES HABN_222c TIGHTEN MOUNTING NUTS REMOVE ALLEN KEYS STEP 5: Rotate Allen Key to tighten Mounting Nuts STEP 6: Remove Allen Keys...
- Page 89 height-adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 6 Section: SCREENS AND GABLES HABN_222c PRESS DOWN ON SCREEN SECURE SCREEN STEP 7: Press Fabric Screen down and make sure Frame is secured with Bushing STEP 8: Fasten Support Brackets with Fabric Screen with Screws provided...
- Page 90 height-adjustable bench Installation Guides Date: Feb 2022 Page: 1 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a Rev. 02 Navigate End Gable - Metal (HNBCGEMN), Navigate Mid Gable - Metal (HNBCGMMN), Navigate Cable Channel (HNBFCN)
- Page 91 height-adjustable bench Installation Guides Date: Feb 2022 Page: 2 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a Part & Product Identification ITEM PART ITEM PART PREVIEW PREVIEW DESCRIPTION DESCRIPTION NUMBER NUMBER 1. NAVIGATE WIRE CHANNEL (HNBFCN) X1 1/4-20X5/8" MACH SCR, BLACK, E01-0113 CABLE...
- Page 92 height-adjustable bench Installation Guides Date: Feb 2022 Page: 3 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a Part & Product Identification ITEM PART ITEM PART PREVIEW DESCRIPTION PREVIEW DESCRIPTION NUMBER NUMBER 2. NAVIGATE END GABLE - METAL (HNBCGEMN) X2 3.
- Page 93 height-adjustable bench Installation Guides Date: Feb 2022 Page: 4 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a REMOVE SUPPORT BRACKETS STEP 1: Remove Support Brackets. Make sure the bolts do not come out of the assembly...
- Page 94 height-adjustable bench Installation Guides Date: Feb 2022 Page: 5 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a ATTACH SUPPORT BRACKET STEP 2: Insert Support Bracket through the cut-out on the Inside Cover Assembly as shown...
- Page 95 height-adjustable bench Installation Guides Date: Feb 2022 Page: 6 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a ATTACH CONNECTING PLATES TO FRAME LEGS MOUNT INSIDE COVER STEP 3 Loosen Legs Hex Bolt on both Legs to allow enough clearance for gable connecting STEP 4: Mount Inside Cover Assembly onto Frame Stretcher Bar (parts of the frame are plate.
- Page 96 height-adjustable bench Installation Guides Date: Feb 2022 Page: 7 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a FASTEN INSIDE COVER IN PLACE SECURE INSIDE COVER ASSEMBLY TO FRAME STEP 5: Make sure the face of the Inside Cover Assembly is flush with the Leg. Secure Inside STEP 6: Secure Inside Cover Assembly to Stretcher Bar with Bolts.
- Page 97 height-adjustable bench Installation Guides Date: Feb 2022 Page: 8 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a MOUNT OUTSIDE COVER ASSEMBLY Opposite side view STEP 7:Mount Outside Cover Assembly to the highlighted part of the Inside Cover Assembly as shown.
- Page 98 height-adjustable bench Installation Guides Date: Feb 2022 Page: 9 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a MID POWER POLE SUPPORT PLATE (OPTIONAL) NOTE: Cable Channels are Hidden for Illustration Purpose. Optional: If Mid Power Pole is specified. Please fasten Connecting Bracket to the underside of the Stretcher Bars as shown. NOTE: Please refer to installation guide HABN_322b...
- Page 99 height-adjustable bench Installation Guides Date: Feb 2022 Page: 10 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a ATTACH SUPPORT BRACKET SCREEN AND GABLES NOTE: Parts of the Frames are hidden for Illustration Purpose. STEP 8: Insert Support Bracket through the cut-out on the Side Cover Assembly STEP 9: Mount Side Cover Assembly onto the Stretcher Bar as shown NOTE: Please refer to Specification Drawing to mount the correct Side Cover Assembly...
- Page 100 height-adjustable bench Installation Guides Date: Feb 2022 Page: 11 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a SECURE SIDE COVER ASSEMBLY CABLE CHANNEL ASSEMBLY STEP 10: Secure Side Cover Assembly with Stretcher Bar with Screws NOTE: Electrics components to be installed on Cable Channel before connecting to Support Bracket.
- Page 101 height-adjustable bench Installation Guides Date: Feb 2022 Page: 12 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a ATTACH CABLE CHANNEL & CENTER RAIL SECURE CABLE CHANNEL Underside View STEP 11: Align holes on Support Brackets, Cable Channel Assembly. Insert Bolts inside STEP 12: Secure Cable Channel in place with Nuts Centre Rail Extrusion through Cable Channel Assembly and Brackets as shown...
- Page 102 height-adjustable bench Installation Guides Date: Feb 2022 Page: 13 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a ATTACH SUPPORT BRACKET MOUNT SIDE COVER ASSEMBLY STEP 13: Insert Support Bracket through the cut-out on the Side Cover Assembly STEP 14: Mount Side Cover Assembly onto the Stretcher Bar as shown...
- Page 103 height-adjustable bench Installation Guides Date: Feb 2022 Page: 14 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a SECURE SIDE COVER ASSEMBLY NOTE: Parts of the Frame are hidden for Illustration Purpose. STEP 15: Secure Side Cover Assembly with Stretcher Bar with Bolts.
- Page 104 height-adjustable bench Installation Guides Date: Feb 2022 Page: 15 of 18 METAL GABLES & CABLE CHANNEL Section: HABN_223a MOUNT FRONT COVER ASSEMBLIES NOTE: Legs are hidden for Illustration Purpose. STEP 16: Mount Front Covers onto the Side Covers as shown in Detail View NOTE: Make sure Magnets remain attached to the legs...
- Page 105 height-adjustable bench Installation Guides Date: Feb 2022 Page: 16 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a CABLE CHANNEL ASSEMBLY ATTACH TOP COVER NOTE: Parts of the Frames are hidden for Illustration Purpose. STEP 17: Align holes on Support Brackets, Cable Channel Assembly. Insert Bolts inside STEP 18: Attach Top Covers onto the highlighted extrusions on the Side and Front Cover Center Rail Extrusion through Cable Channel Assembly and Brackets as shown.
- Page 106 height-adjustable bench Installation Guides Date: Feb 2022 Page: 17 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a TOP COVER WITH POWER POLE CUTOUT (OPTIONAL) NOTE: Parts of the Frames are NOTE: Parts of the Frames are hidden for Illustration Purpose. hidden for Illustration Purpose.
- Page 107 height-adjustable bench Installation Guides Date: Feb 2022 Page: 18 of 18 Section: METAL GABLES & CABLE CHANNEL HABN_223a CENTER RAIL EXTRUSION CAP STEP 20: Insert Center Rail Extrusion Caps onto Center Rail Extrusion as shown.
- Page 108 height-adjustable bench Installation Guides Date: Feb 2022 Page: 1 of 18 Section: SOLID GABLES & CABLE CHANNEL HABN_223b Rev.02 Navigate Mid Gable - Solid (HNBCGMSN), Navigate Cable Channel (HNBFCN), Navigate End Gable - Solid (HNBCGESN) 3.10...
- Page 109 height-adjustable bench Installation Guides Date: Feb 2022 Page: 2 of 18 Section: SOLID GABLES & CABLE CHANNEL HABN_223b Part & Product Identification ITEM PART ITEM PART PREVIEW PREVIEW DESCRIPTION DESCRIPTION NUMBER NUMBER 1/4-20X5/8" 1. NAVIGATE WIRE CHANNEL (HNBFCN) X1 MACH SCR, E01-0113 BLACK, QUAD,TRUSS...
- Page 110 height-adjustable bench Installation Guides Date: Feb 2022 Page: 3 of 18 Section: SOLID GABLES & CABLE CHANNEL HABN_223b Part & Product Identification ITEM PART ITEM PART PREVIEW DESCRIPTION PREVIEW DESCRIPTION NUMBER NUMBER 2. Navigate End Gable - Solid (HNBCGESN) x1 1/4-20 UNCx0.500"...
- Page 111 height-adjustable bench Installation Guides Date: Feb 2022 Page: 4 of 18 Section: SOLID GABLES & CABLE CHANNEL HABN_223b Part & Product Identification ITEM PART ITEM PART PREVIEW DESCRIPTION QTY. PREVIEW DESCRIPTION QTY. NUMBER NUMBER FRONT HANGING BRKT 3. Navigate Mid Gable - Solid - Mid Condition (HNBCGMSN) x1 FOR WOOD MID GABLE, A16-3028 BOTTOM BRKT FOR...
- Page 112 height-adjustable bench Installation Guides Date: Feb 2022 Page: 5 of 18 Section: SOLID GABLES & CABLE CHANNEL HABN_223b REMOVE SUPPORT BRACKETS STEP 1: Remove Support Brackets.
- Page 113 height-adjustable bench Installation Guides Date: Feb 2022 Page: 6 of 18 Section: SOLID GABLES & CABLE CHANNEL HABN_223b ATTACH GABLE SUPPORT BRACKET ATTACH SUPPORT BRACKET STEP 2: Attach and Fasten Gable Brackets. STEP 3: Insert Support Bracket through the cut-out on the Inside Cover Assembly as shown.
- Page 114 height-adjustable bench Installation Guides Date: Feb 2022 Page: 7 of 18 Section: SOLID GABLES & CABLE CHANNEL HABN_223b ATTACH CONNECTING PLATES TO FRAME LEGS MOUNT INSIDE COVER ASSEMBLY NOTE: Parts of the Frame are hidden for Illustration Purpose. Leg Hex Bolt Leveler STEP 4: Loosen Legs Hex Bolt on both Legs to allow enough clearance for gable connecting STEP 5: Mount Inside Cover Assembly onto Frame Stretcher Bar.
- Page 115 height-adjustable bench Installation Guides Date: Feb 2022 Page: 8 of 18 Section: SOLID GABLES & CABLE CHANNEL HABN_223b SECURE INSIDE COVER IN PLACE SECURE INSIDE COVER ASSEMBLY TO FRAME STEP 6: Make sure the face of the Inside Cover Assembly is flush with the Leg. Secure Inside STEP 7: Secure Inside Cover Assembly to Stretcher Bar with Bolts.
- Page 116 height-adjustable bench Installation Guides Date: Feb 2022 Page: 9 of 18 Section: SOLID GABLES & CABLE CHANNEL HABN_223b MOUNT OUTSIDE COVER ASSEMBLY NOTE: Parts of the Frame are hidden for Illustration Purpose. Section View Section View STEP 8:Mount Outside Cover Assembly to the highlighted part of the Inside Cover Assembly as shown.
- Page 117 height-adjustable bench Installation Guides Date: Feb 2022 Page: 10 of 18 Section: SOLID GABLES & CABLE CHANNEL HABN_223b ATTACH CONNECTING PLATES TO FRAME Leg Hex Bolt 3.11 STEP 9: Loosen Hex Bolt to allow enough room for Gable Connecting Plate. Fasten Gable Connecting Plates to Frame Legs.
- Page 118 height-adjustable bench Installation Guides Date: Feb 2022 Page: 11 of 18 Section: SOLID GABLES & CABLE CHANNEL HABN_223b MOUNT BOTTOM ANGLE BAR MID POWER POLE SUPPORT PLATE 3.12 3.10 Connecting Bracket 3.10 Hex Bolt 5/16" x1" Long ZP NOTE: Refer to installation Underside View 3.12 guide HAB_322b for detail.
- Page 119 height-adjustable bench Installation Guides Date: Feb 2022 Page: 12 of 18 Section: SOLID GABLES & CABLE CHANNEL HABN_223b ATTACH MID GABLE SUPPORT BRACKET MOUNT SIDE COVER ASSEMBLY NOTE: Parts of the Frame are hidden for Illustration Purpose. NOTE: Please Refer to Specificstion Drawing to mount the correct side Cover Assembly.
- Page 120 height-adjustable bench Installation Guides Date: Feb 2022 Page: 13 of 18 Section: SOLID GABLES & CABLE CHANNEL HABN_223b SECURE SIDE COVER ASSEMBLY CABLE CHANNEL ASSEMBLY NOTE:Install Cable Channel Cover Plate on Cable Channel Where Vertical Wire Carrier is not specified or unused location. NOTE: Electrics are not included with the Cable Channel.
- Page 121 height-adjustable bench Installation Guides Date: Feb 2022 Page: 14 of 18 Section: SOLID GABLES & CABLE CHANNEL HABN_223b ATTACH CABLE CHANNEL & CENTER RAIL SECURE CABLE CHANNEL Underside View NOTE: Electrics Components to be installed on Cable Channel before connecting to support Bracket.
- Page 122 height-adjustable bench Installation Guides Date: Feb 2022 Page: 15 of 18 Section: SOLID GABLES & CABLE CHANNEL HABN_223b MOUNT FRONT COVER ASSEMBLY Sectrion View STEP 16: Mount Front Covers onto the Frame Link and Bottom connecting Brackets.
- Page 123 height-adjustable bench Installation Guides Date: Feb 2022 Page: 16 of 18 Section: SOLID GABLES & CABLE CHANNEL HABN_223b TOP COVER W/ POWER POLE CUTOUT (OPTIONAL) NOTE: Parts of the Frames are hidden for Illustartion Pupose. NOTE: Parts of the Frames are hidden for Illustartion Pupose.
- Page 124 height-adjustable bench Installation Guides Date: Feb 2022 Page: 17 of 18 Section: SOLID GABLES & CABLE CHANNEL HABN_223b ATTACH TOP COVER NOTE: Parts of the Frames are Hidden for Illustration Purpose. 3.14 STEP 17b: Rest Top Covers onto Gable structures as Shown.
- Page 125 height-adjustable bench Installation Guides Date: Feb 2022 Page: 18 of 18 Section: SOLID GABLES & CABLE CHANNEL HABN_223b CENTER RAIL EXTRUSION CAP STEP 18: Insert Center Rail Extrusion Caps onto Center Rail Extrusion as Shown.
- Page 126 height-adjustable bench Installation Guides Date: May 2019 Page: 1 of 4 Section: SCREENS & GABLES HABN_223c Rev. 01 Navigate End Cover - Metal (HNBCCEMN), Navigate Mid Cover - Metal (HNBCCMMN) Note: Mid Cover with Power Pole Cut-out is Shown as Example. For Cable Channel installation procedures, please refer to guide HABN_223a/223b...
- Page 127 height-adjustable bench Installation Guides Date: May 2019 Page: 2 of 4 Section: SCREENS & GABLES HABN_223c Part & Product Identification ITEM NO. PREVIEW DESCRIPTION PART NUMBER QTY. END COVER, DOUBLE SIDED, HAB A16-7445-X MID COVER, DOUBLE SIDED, HAB A16-7446-X...
- Page 128 height-adjustable bench Installation Guides Date: May 2019 Page: 3 of 4 Section: SCREENS & GABLES HABN_223c PLACE END COVER & BRACKET ON FRAME BAR SECURE END COVER IN PLACE Note: Support Bracket ships with Cable Channel. For Cable Channel installation procedures, please refer to guide HABN_223a/223b STEP 1: Slide Cable Channel Support Bracket into End Cover, making sure holes align.
- Page 129 height-adjustable bench Installation Guides Date: May 2019 Page: 4 of 4 Section: SCREENS & GABLES HABN_223c PLACE MID COVER ON STRETCHER BARS SECURE MID COVER IN PLACE Note: For Cable Channel installation procedures, please refer to guide HABN_223a/223b STEP 3: Place Metal Mid Cover on top of Stretcher Bars and Cable Channel Support STEP 4: Use Screws provided with Support Brackets to secure Metal Mid Cover in place.
- Page 130 height-adjustable bench Installation Guides Date: Aug 2019 Page: 1 of 5 Section: SCREENS & GABLES HABN_223d Rev. 01 Navigate End Screen Cover - Metal (HNBCCSMN), Navigate End of Run Screen (HNBTEF) 1.2.1 1.2.2...
- Page 131 height-adjustable bench Installation Guides Date: Aug 2019 Page: 2 of 5 Section: SCREENS & GABLES HABN_223d Rev. 01 Part & Product Identification ITEM NO. PREVIEW DESCRIPTION PART NUMBER QTY. 1. Navigate End of Run Fabric Screen (HNBTEF) x1 NAVIGATE END OF RUN FABRIC SCREEN HNBTEF-X 1.2.
- Page 132 height-adjustable bench Installation Guides Date: Aug 2019 Page: 3 of 5 Section: SCREENS & GABLES HABN_223d ATTACH BRACKETS TO SCREEN ATTACH BRACKETS TO FRAME NOTE: Ensure the Screen is leveled. 1.2.3 1.2.2 1.2.3 1.2.1 STEP 1: Attach Outer Brackets to Screen using Screws provided. STEP 2: Attach Inner Brackets to Frame using Screws provided.
- Page 133 height-adjustable bench Installation Guides Date: Aug 2019 Page: 4 of 5 Section: SCREENS & GABLES HABN_223d ATTACH SCREEN TO FRAME PLACE END COVER & BRACKET ON FRAME BAR NOTE: Support Bracket ships with Cable Channel. For Cable Channel installation procedures, please refer to guide HABN_223a/223b 1.2.2 1.2.1...
- Page 134 height-adjustable bench Installation Guides Date: Aug 2019 Page: 5 of 5 Section: SCREENS & GABLES HABN_223d INSTALL END COVER PLACE TOP COVER IN POSITION NOTE: Parts of the Frame are hidden for Illustration purpose. STEP 5: Secure Inside Cover in place using Support Bracket screws STEP 6: Place Top Cover on top of Inside Cover...
- Page 135 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 6 Section: SCREENS & GABLES HABN_223e Rev. 01 Navigate End Screen Gable - Metal (HNBCGSMN), Navigate End of Run Screen (HNBTEF) 1.2.2 1.2.1...
- Page 136 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 6 Section: SCREENS & GABLES HABN_223e Rev. 01 Part & Product Identification ITEM NO. PREVIEW DESCRIPTION PART NUMBER QTY. 1. Navigate End of Run Fabric Screen. (HNBTEF) x1 NAVIGATE END OF RUN FABRIC SCREEN HNBTEF 1.2.
- Page 137 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 6 Section: SCREENS & GABLES HABN_223e ATTACH OUTER BRACKETS TO SCREEN ATTACH GABLE CONNECTORS TO LEGS NOTE: Ensure the Screen is Leveled. NOTE: Bolts come with the Table Frame. 1.2.2 1.2.3 STEP 1: Attach Outer Bracket to End Screen using Screws provided STEP 2: Loosen Bolts that come with the Table Frame, and slide Gable Connector to...
- Page 138 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 6 Section: SCREENS & GABLES HABN_223e LINE UP INSIDE COVER AND BRACKET SECURE INSIDE COVER TO CONNECTOR STEP 3: Line up the Cable Channel Bracket with the Inside Cover, and place against the STEP 4: Use Screws provided to secure the Inside Cover to the Gable Connector horizontal frame...
- Page 139 height-adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 6 Section: SCREENS & GABLES HABN_223e SCREW COVER TO BRACKET ATTACH BRACKETS TO FRAME NOTE: Support Bracket ships with Cable Channel. For Cable Channel installation procedures, please refer to guide HABN_223a/223b 1.2.3 1.2.1 STEP 5: Screw the Inside Cover to the bracket using the Screws provided in the Cable...
- Page 140 height-adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 6 Section: SCREENS & GABLES HABN_223e ATTACH END SCREEN TO FRAME PLACE TOP COVER ON FRAME NOTE: Raise the 1.2.2 frame to its' maximum height before placing the Top Cover NOTE: Parts of the Frame are Hidden for Illustration Purpose.
- Page 141 height-adjustable bench Installation Guides SCREENS AND GABLES Section: Date: Sep 2024 Page No: 1 of 8 Description: SINGLE SIDED NAVIGATE WIRE CHANNEL HABN_223f Rev. No: 0 Navigate Wire Channel, Single Sided (HNBFCNS)
- Page 142 height-adjustable bench Installation Guides SCREENS AND GABLES Section: Date: Sep 2024 Page No: 2 of 8 Description: SINGLE SIDED NAVIGATE WIRE CHANNEL HABN_223f Rev. No: 0 Part and Product Identification E - Support Bracket - Screen Rail, A - Wire Channel, Single Sided Single Sided (N09-8570) x1 (A16-7245L) x1...
- Page 143 height-adjustable bench Installation Guides Section: SCREENS AND GABLES Date: Sep 2024 Page No: 3 of 8 Description: SINGLE SIDED NAVIGATE WIRE CHANNEL HABN_223f REMOVE SUPPORT BRACKETS STEP 1: Remove Support Brackets. Make sure the bolts do not come out of the assembly.
- Page 144 height-adjustable bench Installation Guides Section: SCREENS AND GABLES Date: Sep 2024 Page No: 4 of 8 Description: SINGLE SIDED NAVIGATE WIRE CHANNEL HABN_223f SECURE SUPPORT BRACKETS TO FRAME NOTE: Ensure that the Support Brackets are installed in the correct orientation as shown.
- Page 145 height-adjustable bench Installation Guides Section: SCREENS AND GABLES Date: Sep 2024 Page No: 5 of 8 Description: SINGLE SIDED NAVIGATE WIRE CHANNEL HABN_223f CABLE CHANNEL ASSEMBLY NOTE: Electrics components to be installed on Cable Channel before connecting to Support Brackets. Please refer to Installation Guide 321a, 321b, 322a, or 322b for corresponding Electrics installation.
- Page 146 height-adjustable bench Installation Guides Section: SCREENS AND GABLES Date: Sep 2024 Page No: 6 of 8 Description: SINGLE SIDED NAVIGATE WIRE CHANNEL HABN_223f ATTACH WIRE CHANNEL STEP 3: Align holes on Support Brackets and Wire Channel, Insert Bolts inside Center Rail Extrusion through Wire Channel and Brackets as shown.
- Page 147 height-adjustable bench Installation Guides Section: SCREENS AND GABLES Date: Sep 2024 Page No: 7 of 8 Description: SINGLE SIDED NAVIGATE WIRE CHANNEL HABN_223f SECURE WIRE CHANNEL Underside view STEP 4: Secure Wire Channel in place with Nuts.
- Page 148 height-adjustable bench Installation Guides Section: SCREENS AND GABLES Date: Sep 2024 Page No: 8 of 8 Description: SINGLE SIDED NAVIGATE WIRE CHANNEL HABN_223f CENTER RAIL EXTRUSION CAP STEP 5: Insert Center Rail Extrusion Caps onto Center Rail Extrusion as shown.
- Page 149 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 8 Section: SCREENS AND GABLES HABN_224 Rev. Navigate Single-Sided Corridor Screen – Fabric (HNBLSF), Navigate Single-Sided Corridor Screen – Solid (HNBLSS) 1.5.3 1.5.1 1.5.2...
- Page 150 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 8 Section: SCREENS AND GABLES HABN_224 Part & Product Identification ITEM PART ITEM PART PREVIEW DESCRIPTION QTY. PREVIEW DESCRIPTION QTY. NUMBER NUMBER 1. NAVIGATE SINGLE SIDED CORRIDOR SCREEN - FABRIC (HNBLSF) 1.5.
- Page 151 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 8 SCREENS AND GABLES Section: HABN_224 Part & Product Identification ITEM PART ITEM PART PREVIEW DESCRIPTION QTY. PREVIEW DESCRIPTION QTY. NUMBER NUMBER 2. NAVIGATE SINGLE SIDED CORRIDOR SCREEN - SOLID (HNBLSS) 2.3.
- Page 152 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 8 Section: SCREENS AND GABLES HABN_224 ATTACH BRACKETS ASSEMBLE T-NUTS NOTE: HNBLSF Shown 1.5.1 1.5.2 1.5.3 1.5.4 STEP 1a: Attach Brackets as shown above with screws provided. STEP 2a: Assemble T-Nuts as shown above.
- Page 153 height-adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 8 Section: SCREENS AND GABLES HABN_224 ATTACH BRACKETS ASSEMBLE T-NUTS NOTE: HNBLSS Shown 2.3.3 2.3.1 2.3.2 2.3.4 STEP 1b: Attach Brackets as shown above with screws provided. STEP 2b: Assemble T-Nuts as shown above.
- Page 154 height-adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 8 Section: SCREENS AND GABLES HABN_224 ALIGN T-NUTS NOTE: Frame and Worksurface Assmbly is not shown for illustration purpose. STEP 3: Align T-Nuts parallel to the wire channel.
- Page 155 height-adjustable bench Installation Guides Date: Sept 2019 Page: 7 of 8 Section: SCREENS AND GABLES HABN_224 FASTEN SCREWS NOTE: Worksurface not shown for illustration purpose. STEP 4: Fasten T-Nuts with an Allen Key. Make sure the screen is perpendicular to the ground.
- Page 156 height-adjustable bench Installation Guides Date: Sept 2019 Page: 8 of 8 Section: SCREENS AND GABLES HABN_224 ADJUST LEVERLLERS (OPTIONAL) STEP 5: Using a wrench, adjust Levellers to achieve stability.
- Page 157 height-adjustable bench Installation Guides Date: May 2019 Page: 1 of 4 Section: SCREENS & GABLES HABN_224a Rev. 00 Navigate 120 Mid Cover - Metal (HNBCCMMT)
- Page 158 height-adjustable bench Installation Guides Date: May 2019 Page: 2 of 4 Section: SCREENS & GABLES HABN_224a Rev. 00 Part & Product Identification ITEM NO. PREVIEW DESCRIPTION PART NUMBER QTY. TOP COVER MID GABLE WELDED ASSY. 120 NAV. HAB N09-8988X SPACER MID GABLE 120 NAVIGATE HAB A16-7672 COVER PLATE MID-GABLE 120 NAVIGATE HAB A16-7449...
- Page 159 height-adjustable bench Installation Guides Date: May 2019 Page: 3 of 4 Section: SCREENS & GABLES HABN_224a Rev. 00 ATTACH COVER PLATE TO FRAME ATTACH SPACER TO FRAME NOTE: Bracket and Screws come NOTE: Please refer to HABN_123 with Cable Channel for hardware components required STEP 1: Attach the Cover Plate to the Legs and Mid-Gable Stretcher Assembly using the STEP 2: Attach the Spacer to the Mid-Gable Stretcher Frame along with the Bracketm using...
- Page 160 height-adjustable bench Installation Guides Date: May 2019 Page: 4 of 4 Section: SCREENS & GABLES HABN_224a Rev. 00 PLACE TOP COVER STEP 3: Place the Top Cover on top of the Assembly.
- Page 161 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 4 Section: SCREENS & GABLES HAB_224b Rev. 00 Navigate 120 Mid Gable, Solid (HNBCGMST) Navigate 120 Mid Gable, Metal (HNBCGMMT)
- Page 162 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 4 Section: SCREENS & GABLES HAB_224b Part & Product Identification ITEM PREVIEW DESCRIPTION PART NUMBER QTY. TOP COVER MID GABLE WELDED N09-8988X ASSY. 120 NAV. HAB HANGER PLATE MID GABLE 120 A16-7458 NAVIGATE HAB NAVIGATE 120 HNB MID GABLE...
- Page 163 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 4 Section: SCREENS & GABLES HAB_224b ATTACH COVER PLATE TO FRAME ATTACH SPACER TO FRAME NOTE: Please refer to HAB_123 for hardware components required NOTE: Please refer to HAB_123 for hardware components required STEP 1: Attach the Cover Plate to the Legs and Mid-Gable Stretcher Assembly using STEP 2: Attach the Spacer to the Mid-Gable Stretcher Frame along with the Bracketm using the Machine Screws provided with the 120 Frame.
- Page 164 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 4 Section: SCREENS & GABLES HAB_224b PLACE TOP COVER STEP 3: Place the Top Cover on top of the assembly.
- Page 165 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 4 Section: SCREENS AND GABLES HABN_225a Rev. Navigate Single-Sided End Cover – Metal (HNBCCEMS), Navigate Single-Sided Mid Cover – Metal (HNBCCMMS)
- Page 166 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 4 Section: SCREENS AND GABLES HABN_225a Part & Product Identification ITEM ITEM PREVIEW DESCRIPTION PART NUMBER QTY. PREVIEW DESCRIPTION PART NUMBER QTY. 1. NAVIGATE END COVER, SINGLE SIDED, HAB (HNBCCEMS30L) 3.
- Page 167 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 4 Section: SCREENS AND GABLES HABN_225a PLACE GABLE COVER (RIGHT) PLACE GABLE COVER (LEFT) STEP 1a: Place the End Gable Cover - Right as shown above. STEP 1b: Place the End Gable Cover - Left as shown above.
- Page 168 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 4 Section: SCREENS AND GABLES HABN_225a PLACE THE MID GABLE COVER STEP 3: Place Mid-Gable Cover as shown above.
- Page 169 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 6 Section: SCREENS AND GABLES HABN_225b Rev. 0 NAVIGATE SINGLE-SIDED END SCREEN COVER (HNBCCSMS), NAVIGATE SINGLE-SIDED END OF RUN SCREEN - FABRIC (HNBTSF)
- Page 170 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 6 Section: SCREENS AND GABLES HABN_225b Part & Product Identification ITEM PREVIEW DESCRIPTION PART NUMBER QTY. NAVIGATE END OF RUN FABRIC SCREEN SS HNBTSF-X 2. FABRIC END SCREEN MOUNTING BRKT KIT, SINGLE SIDED, HAB (X06-0618) x1 END SCREEN BRKT ASSY, INNER, SINGLE N09-9207 SIDED, HAB...
- Page 171 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 6 Section: SCREENS AND GABLES HABN_225b ATTACH BRACKETS TO SCREEN ATTACH BRACKETS TO FRAME STEP 1: Attach Outer Brackets to Screen using Screws provided. STEP 2: Attach Inner Brackets to Frame using Screws provided.
- Page 172 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 6 Section: SCREENS AND GABLES HABN_225b ATTACH SCREEN TO FRAME (WITH CORRIDOR SCREEN ONLY) NOTE: For the installation instructions of the Wire Channel (HNBFCN), refer to guide HABN_225d/225e. For the Corridor Screen (HNBLS), refer to guide HAB_224.
- Page 173 height-adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 6 Section: SCREENS AND GABLES HABN_225b ATTACH SCREEN TO FRAME PLACE INSIDE COVER ON FRAME NOTE: If the Screen is tilted forwards or backwards, the slots in the Outer/Inner Brackets allow the screen to be adjusted STEP 4: Attach the End Screen to the Frame using the Screws Provided.
- Page 174 height-adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 6 Section: SCREENS AND GABLES HABN_225b PLACE TOP COVER IN POSITION STEP 6: Place Top Cover on top of the Inside Cover...
- Page 175 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 6 Section: SCREENS AND GABLES HAB_225c Rev. 0 NAVIGATE SINGLE-SIDED END OF RUN SCREEN GABLE (HNBCGSMS), NAVIGATE SINGLE-SIDED END OF RUN SCREEN - SOLID (HNBTSS)
- Page 176 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 6 Section: SCREENS AND GABLES HAB_225c Part & Product Identification ITEM ITEM PREVIEW DESCRIPTION PART NUMBER QTY. PREVIEW DESCRIPTION PART NUMBER QTY. STICK ON CLEAR BUMPER D04-0050 4. NAVIGATE END SCREEN GABLE, SINGLE SIDED, HAB (HNBCGSMS) x1 NAVIGATE END SCREEN, HNBTSS-X SOLID, SINGLE SIDED, HAB...
- Page 177 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 6 Section: SCREENS AND GABLES HAB_225c ATTACH OUTER BRACKETS TO SCREEN ATTACH GABLE CONNECTORS TO LEGS NOTE: Ensure the screen is leveled. NOTE: Bolts come with the Table Frame STEP 1: Attach Outer Brackets to the End Screen using Screws provided. STEP 2: Loosen Bolts that come with the Table Frame, and slide the Gable Connectors to the underside of the legs.
- Page 178 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 6 Section: SCREENS AND GABLES HAB_225c PLACE INSIDE COVER ON FRAME SECURE INSIDE COVER TO CONNECTOR STEP 3: Place the Inside Cover on the Frame. Ensure the Inside Cover Brackets are mounted STEP 4: Use Screws provided to secure the Inside Cover to the Gable Connector.
- Page 179 height-adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 6 Section: SCREENS AND GABLES HAB_225c ATTACH BRACKETS TO FRAME ATTACH BUMPER (OPTIONAL) NOTE: For the installation instructions of the Wire Channel (HNBFCNS), refer to guide HABN_223f. For the Corridor Screen (HNBLS), refer to guide HAB_224. STEP 5: Secure Inner Bracket to Frame using the Screws provided.
- Page 180 height-adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 6 Section: SCREENS AND GABLES HAB_225c ATTACH END SCREEN TO FRAME PLACE TOP COVER ON FRAME NOTE: Raise the frame to its' MAXIMUM height before placing the Top Cover. NOTE: If the screen is tilted forwards or backwards, the slots in the Outer/Inner brackets allow the screen to be adjusted.
- Page 181 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 7 Section: SCREENS AND GABLES HABN_225d Rev. Navigate Single-Sided End Gable - Metal (HNBCGEMS), Navigate Single-Sided Mid Gable - Metal (HNBCGMMS) HNBCGEMS shown HNBCGMMS shown...
- Page 182 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 7 Section: SCREENS AND GABLES HABN_225d Part & Product Identification ITEM ITEM PREVIEW DESCRIPTION PART NUMBER QTY. PREVIEW DESCRIPTION PART NUMBER QTY. 1. NAVIGATE END GABLE, METAL, SINGLE SIDED, HAB (HNBCGEMS) 2.
- Page 183 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 7 Section: SCREENS AND GABLES HABN_225d ATTACH CONNECTING PLATES TO FRAME LEGS MOUNT INSIDE COVER STEP 1: Loosen Leg Hex Bolt to attach Gable Connecting Plates to Frame leg. Then, Fasten STEP 2:Mount Inside Cover Assembly onto Frame Stretcher Bar.
- Page 184 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 7 Section: SCREENS AND GABLES HABN_225d FASTEN INSIDE COVER IN PLACE APPLY FOAM RUBBERS STEP 3: Make sure the face of the Inside Cover Assembly is flush with the Leg. Secure Inside STEP 4: Attach Foam Rubbers onto the center of the Frame Legs' inner side.
- Page 185 height-adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 7 Section: SCREENS AND GABLES HABN_225d MOUNT OUTSIDE COVER ASSEMBLY Side View Detailed Isometric View STEP 5: Mount Outside Cover Assembly to the highlighted part of the Inside Cover Assembly as shown.
- Page 186 height-adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 7 Section: SCREENS AND GABLES HABN_225d MOUNT SIDE COVER ASSEMBLY NOTE: Installation of HNBCGMSS shown Side View STEP 7: Mount Side Cover Assembly as shown above.
- Page 187 height-adjustable bench Installation Guides Date: Sept 2019 Page: 7 of 7 Section: SCREENS AND GABLES HABN_225d FRONT COVER ASSEMBLY PLACE TOP COVERS STEP 8: Place the magnet then, mount Front Cover Assembly as shown above. STEP 9: Place Back Top Cover and Top Cover as shown above.
- Page 188 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 10 Section: SCREENS AND GABLES HABN_225e Rev. Navigate Single-Sided End Gable - Solid (HNBCGESS), Navigate Single-Sided Mid Gable - Solid (HNBCGMSS) 2.13...
- Page 189 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 10 Section: SCREENS AND GABLES HABN_225e Part & Product Identification ITEM ITEM PREVIEW DESCRIPTION PART NUMBER QTY. PREVIEW DESCRIPTION PART NUMBER QTY. 1. NAVITAGE END GABLE, SOLID, SINGLE SIDED, HAB (HNBCGESS30) HANGING BRACKET FOR A16-3021...
- Page 190 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 10 Section: SCREENS AND GABLES HABN_225e Part & Product Identification ITEM PART ITEM PART PREVIEW DESCRIPTION QTY. PREVIEW DESCRIPTION QTY. NUMBER NUMBER GABLE CONNECTING 2.11 A16-3651 PLATE SIDE COVER FOR MID C07- GABLE, SINGLE 4718AL\30...
- Page 191 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 10 Section: SCREENS AND GABLES HABN_225e ATTACH CONNECTION PLATES TO FRAME LEGS ATTACH SUPPORT BRACKETS STEP 1: Loosen Legs Hex Bolt to allow enough room for Gable Connecting Plate. Fasten STEP 2: Fasten Brackets to Outside Cover Assembly Gable Connecting Plates to Frame Legs.
- Page 192 height-adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 10 Section: SCREENS AND GABLES HABN_225e MOUNT INSIDE COVER ASSEMBLY MOUNT INSIDE COVER ASSEMBLY STEP 3: Mount Inside Cover Assembly onto Stretcher Bar. STEP 4: Secure Inside Cover Assembly to Gable Connecting Plate on both sides using Tap Quad Pan screws provided.
- Page 193 height-adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 10 Section: SCREENS AND GABLES HABN_225e MOUNT OUTSIDE COVER ASSEMBLY STEP 5: Mount Outside Cover Assembly to Stretcher Bar as shown above.
- Page 194 height-adjustable bench Installation Guides Date: Sept 2019 Page: 7 of 10 Section: SCREENS AND GABLES HABN_225e ATTACH CONNECTING PLATES TO FRAME LEGS MOUNT BOTTOM ANGLE BAR 2.17 2.11 STEP 6: Loosen Legs Hex Bolt to allow enough room for Gable Connecting Plate. Fasten STEP 7: Mount Bottom Angle Bar and secure to Gable Connecting Plate on both sides using Gable Connecting Plates to Frame Legs Tap Quad Pan screws provided...
- Page 195 height-adjustable bench Installation Guides Date: Sept 2019 Page: 8 of 10 Section: SCREENS AND GABLES HABN_225e ATTACH SUPPORT BRACKETS - 1 ATTACH SUPPORT BRACKETS - 2 2.12 2.16 2.14 2.18 2.16 2.16 STEP 8: Fasten Brackets and Cover Plates to Side Cover Assemblies as shown. STEP 9: Fasten Brackets and Cover Plates to Front Covers as shown.
- Page 196 height-adjustable bench Installation Guides Date: Sept 2019 Page: 9 of 10 Section: SCREENS AND GABLES HABN_225e MOUNT SIDE COVER ASSEMBLY STEP 10: Mount Side Cover Assembly onto the Stretcher Bar as shown.
- Page 197 height-adjustable bench Installation Guides Date: Sept 2019 Page: 10 of 10 Section: SCREENS AND GABLES HABN_225e MOUNT FRONT COVER ASSEMBLY PLACE TOP COVERS STEP 11: Mount Front Covers onto the Frame Link and Bottom Connecting Brackets. STEP 12: Place Top Covers as shown above.
- Page 198 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 6 Section: METAL GABLES & CABLE CHANNEL HABN_225f Rev. 00 Navigate Single-Sided Transition Mid-Gable - Metal (HNBCGMMR)
- Page 199 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 6 Section: METAL GABLES & CABLE CHANNEL HABN_225f Rev. 00 Part & Product Identification ITEM PART ITEM PART PREVIEW DESCRIPTION QTY. PREVIEW DESCRIPTION QTY. NUMBER NUMBER TOP COVER FOR METAL MID GABLE W/POWER A16-7491-X POLE, DOUBLE SIDED,...
- Page 200 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 6 Section: METAL GABLES & CABLE CHANNEL HABN_225f Rev. 00 INSTALL BRACKET INSTALL FRAME LINK NOTE: Refer to HABN_101 for installation steps for the Frame Link STEP 1: Attach Bracket to stretcher bar using Screws provided. STEP 2: Install Frame Link to join both frames.
- Page 201 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 6 Section: METAL GABLES & CABLE CHANNEL HABN_225f Rev. 00 ASSEMBLE BACK COVER ATTACH SIDE COVER TO FRAME NOTE: Bracket and Screws included with Wire Channel, refer to HABN_223a for more steps.
- Page 202 height-adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 6 Section: METAL GABLES & CABLE CHANNEL HABN_225f Rev. 00 ATTACH SIDE COVER INSTALL BACK COVER STEP 5: Hook Side Cover over stretcher bar on Single-Sided Frame. STEP 6: Hook Back Cover assembly over the corners of rhe Side Covers. The magnet should stick to the leg of the Single-Sided Frame.
- Page 203 height-adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 6 Section: METAL GABLES & CABLE CHANNEL HABN_225f Rev. 00 ATTACH FRONT COVER PLACE TOP COVER ON GABLE STEP 7: Place magnets in between the rivets at the bottom of the Front Cover. Hook corners STEP 8: Raise the tables, then place the Top Cover on top of the gable assembly.
- Page 204 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 11 Section: SCREENS & GABLES HABN_225g Rev. 0 Navigate Transition Mid Gable - Solid (HNBCGMSR) NOTE: HNBCGMSR_L is Shown as an Example.
- Page 205 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 11 Section: SCREENS & GABLES HABN_225g Part & Product Identification ITEM PREVIEW DESCRIPTION PART NUMBER QTY. 1. NAVIGATE TRANSITION MID GABLE, SOLID (HNBCGMSR)x1 SIDE COVER FOR MID GABLE, DOUBLE SIDED, HAB C07-4593X-X SIDE COVER FOR MID GABLE, SINGLE SIDED, HAB C07-4718R-X...
- Page 206 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 11 Section: SCREENS & GABLES HABN_225g Part & Product Identification ITEM PREVIEW DESCRIPTION PART NUMBER QTY. 1. NAVIGATE TRANSITION MID GABLE, SOLID (HNBCGMSR)x1 GABEL CONNECTING PLATE A16-3651 HANGING BRACKET, FOR WOOD MID GABLE, A16-3203 BOTTOM CONNECTING BRKT ,WOOD MID A16-3026...
- Page 207 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 11 Section: SCREENS & GABLES HABN_225g Part & Product Identification ITEM PART PREVIEW DESCRIPTION QTY. NUMBER 1. NAVIGATE TRANSITION MID GABLE, SOLID (HNBCGMSR)x1 HANGING BRACKET, FOR WOOD MID GABLE, A16-7569R SINGLE SIDED, HAB CORNER BRKT, TRANSITION SOLID MID GABLE, A16-7732...
- Page 208 height-adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 11 Section: SCREENS & GABLES HABN_225g INSTALL BRACKET INSTALL FRAME LINK NOTE: Refer to HABN_101 for installation steps for thr Frame Link. STEP 1:Attach Bracket to Stretcher bar using Screws provided. STEP 2: Install Frame Link to join both frames.
- Page 209 height-adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 11 Section: SCREENS & GABLES HABN_225g ATTACH CONNECTING PLATES MOUNT BOTTOM ANGLE BAR NOTE: Parts of the Frames are Hidden for Illustration purpose. STEP 3: Loosen Hex Bolt to allow enough room for gable connecting Plate. Fasten Gable STEP 4: Mount both Bottom Angle Bars and Secure to Gable Connecting Plates on both Connecting plates to the Frame Legs.
- Page 210 height-adjustable bench Installation Guides Date: Sept 2019 Page: 7 of 11 Section: SCREENS & GABLES HABN_225g ATTACH MID GABLE SUPPORT BRACKETS STEP 5: Secure the Brackets and Cover Plates to Side cover, Back Cover, Front Cover and Transition Cover as shown. Rotate Screws Clockwise to Fasten.
- Page 211 height-adjustable bench Installation Guides Date: Sept 2019 Page: 8 of 11 Section: SCREENS & GABLES HABN_225g MOUNT SIDE COVER ASSEMBLY MOUNT BACK COVER ASSEMBLY NOTE: Parts of the Frames are Hidden for Illustration purpose. NOTE: Parts of the Frames are Hidden for Illustration purpose.
- Page 212 height-adjustable bench Installation Guides Date: Sept 2019 Page: 9 of 11 Section: SCREENS & GABLES HABN_225g ATTACH TRANSITION GABLE COVER SECURE TRANSITION GABLE COVER NOTE: Parts of the Frames are Hidden for Illustration purpose. NOTE: Parts of the Frames are Hidden for Illustration purpose.
- Page 213 height-adjustable bench Installation Guides Date: Sept 2019 Page: 10 of 11 Section: SCREENS & GABLES HABN_225g MOUNT SIDE COVER ASSEMBLY MOUNT FRONT COVER ASSEMBLY NOTE: Parts of the Frames are Hidden for Illustration purpose. NOTE: Parts of the Frames are Hidden for Illustration purpose.
- Page 214 height-adjustable bench Installation Guides Date: Sept 2019 Page: 11 of 11 Section: SCREENS & GABLES HABN_225g ATTACH TOP COVER NOTE: Parts of the Frames are Hidden for Illustration purpose. STEP 12: Rest Top Cover ontoGable Assembly as shown.
- Page 215 height-adjustable bench Installation Guides Section: SCREENS AND GABLES Date: Sept 2024 1 of 3 Page No: Description: DOUBLE SIDED END SCREEN HABN_225h Rev. No: 0 NAVIGATE END SCREEN, SOLID, DOUBLE SIDED (HNBTES) Part and Product Identification A - Part name (Part Number) xQty A - End Screen, solid (C07-5200x-x) x1...
- Page 216 height-adjustable bench Installation Guides Section: SCREENS AND GABLES Date: Sept 2024 Page No: 2 of 3 Description: DOUBLE SIDED END SCREEN HABN_225h STEP 1: Attach Outer Bracket (C) to the End Screen (A) using 5/8" Screws (D). STEP 2: Secure Bracket (B) to Frame using 5/8" Screws (D).
- Page 217 height-adjustable bench Installation Guides Section: SCREENS AND GABLES Date: Sept 2024 Page No: 3 of 3 Description: DOUBLE SIDED END SCREEN HABN_225h STEP 3: Attach the End Screen (A) to the frame with 5/8" Screws (D).
- Page 218 height-adjustable bench Installation Guides Section: SCREENS AND GABLES Date: Sept 2020 Page No: 1 of 4 Description: SCREEN ACCESSORIES HABN_226 Rev. No: 0 Navigate Single Sided Solid Screen Connection Bracket (HNBLBS) Part and Product Identification NOTE: HNBLBS090 and HNBLBS180 is shown as an example. A1 - Wood Screen Alignment Cover (A25-0691) x1 A2 - Wood Screen...
- Page 219 height-adjustable bench Installation Guides Section: SCREENS AND GABLES Date: Sept 2020 Page No: 2 of 4 Description: SCREEN ACCESSORIES HABN_226 POSITION ALIGNMENT COVER ALIGN BRACKET NOTE: Use the Gap created by the Alignment cover as the Clearance. STEP 1: Position Alignment Cover to the Top edge of the Screen. STEP 2: Align the Alignment Bracket to the Bottom Edge of the Cover, use the Alignment Cover as Clearance.
- Page 220 height-adjustable bench Installation Guides Section: SCREENS AND GABLES Date: Sept 2020 Page No: 3 of 4 Description: SCREEN ACCESSORIES HABN_226 SECURE ALIGNMENT BRACKET SECURE CORNER ALIGNMENT BRACKET STEP 3: Secure the Alignment Bracket to the Solid Screen using the Screws Provided. STEP 4: Secure the Corner Alignment Bracket to the Solid Screens using the Screws Provided.
- Page 221 height-adjustable bench Installation Guides Section: SCREENS AND GABLES Date: Sept 2020 Page No: 4 of 4 Description: SCREEN ACCESSORIES HABN_226 MOUNT ALIGNMENT COVER STEP 5: Mount the ALignment Cover onto the Bracket as Shown.
- Page 222 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 8 Section: ELECTRICS HABN_321a Rev. 01 Navigate Power Module (HNBEPM), Navigate Receptacle Outlet (HNBERO), Navigate Power Harness (HNBEPH)
- Page 223 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 8 Section: ELECTRICS HABN_321a Part & Product Identification ITEM ITEM PREVIEW DESCRIPTION PART NUMBER QTY. PREVIEW DESCRIPTION PART NUMBER QTY. 1. NAVIGATE POWER MODULE (HNBEPM) #8-18X1/2"CROSS SQUARE E07-0012 COMB.SELF COMMUNICATION PLUG OUTLET $OUTLET ASSY...
- Page 224 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 8 Section: ELECTRICS HABN_321a ASSEMBLE OUTLET HOUSING FASTEN SCREWS STEP 1: Place Outlet Housing over Power Module. STEP 2: Fasten Outlet Housing with screws provided.
- Page 225 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 8 Section: ELECTRICS HABN_321a ASSEMBLE RECEPTACLE FASTEN SCREWS STEP 3: Slide and engage Receptacles into Outlet Housing STEP 4: Fasten Receptacles with screws provided.
- Page 226 height-adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 8 Section: ELECTRICS HABN_321a ASSEMBLE PLATES STEP 5: Attach the Bezel by snapping it onto the Housing. Then, attach Blank Plate onto the Bezel.
- Page 227 height-adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 8 Section: ELECTRICS HABN_321a POWER MODULE ASSEMBLY - 1 STEP 6: Fasten Power Module assembly to underside of Cable Tray, make sure to line up holes of Cable Tray to holes from Brackets.
- Page 228 height-adjustable bench Installation Guides Date: Sept 2019 Page: 7 of 8 Section: ELECTRICS HABN_321a POWER MODULE ASSEMBLY - 2 M-Clip Hanger-Club Talk Bracket NOTE: Installer is to determine the layout for Hanger-Club Talk Bracket and M-Clip within the rectangular area. STEP 7: Assemble M-Clips and Hanger-Club Talk Brackets.
- Page 229 height-adjustable bench Installation Guides Date: Sept 2019 Page: 8 of 8 Section: ELECTRICS HABN_321a POWER HARNESS ASSEMBLY NOTE: M-Clips are not illustrated STEP 8: Connect pre-assembled Base Feed to Power Module. If Power Harness is specified, connect Power Harness to Power Module.
- Page 230 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 7 Section: ELECTRICS HABN_321b Rev. 01 Navigate Chicago Power Module (HNBEPMCH), Navigate Single-Sided Chicago Power Module (HNBEPMCH) NOTE: Single-Sided Power Module follows same step.
- Page 231 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 7 Section: ELECTRICS HABN_321b Part & Product Identification ITEM NO. PREVIEW DESCRIPTION PART NUMBER QTY. 1. CHICAGO POWER MODULE (HNBEPMCH) SHEET MATAL HOUSING, CHICAGO MPA16-E020 OUTLET BOX, NAVIGAT HAB Inner Housing Assembly JNECPB Screw,#8x1/2"...
- Page 232 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 7 Section: ELECTRICS HABN_321b LOOSEN SCREWS DISASSEMBLE INNER HOUSING STEP 1: Remove Screws from the Inner Housings to loosen. STEP 2: Disassemble Inner Housing Assembly.
- Page 233 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 7 Section: ELECTRICS HABN_321b MAKE WIRE CONNECTIONS FASTEN SCREWS NOTE: Licensed Electrician need to make the Wire Connections. Before attaching the Inner Housing to Metal Housing. NOTE: The Wires are hidden for illustration purpose.
- Page 234 height-adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 7 Section: ELECTRICS HABN_321b ATTACH CHICAGO POWER MODULE TO WIRE CHANNEL NOTE: Base Feed is pre-assembled STEP 5: Fasten Chicago Power Module assembly to underside of Cable Tray, Make sure to lineup holes of cable tray to holes Brackets.
- Page 235 height-adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 7 Section: ELECTRICS HABN_321b POWER MODULE ASSEMBLY - 1 WARNING! *Do not connect to power source until installation is complete. *Connection to the building power source must be performed by a licensed electrician. *Not following these instruction could result in damage and/or injury.
- Page 236 height-adjustable bench Installation Guides Date: Sept 2019 Page: 7 of 7 Section: ELECTRICS HABN_321b POWER MODULE ASSEMBLY - 2 M-Clip Hanger-Club Talk Bracket NOTE: Installer is to determine the layout for Hanger-Club Talk Bracket and M-Clip within the rectangular area. STEP 7: Assemble M-Clips and Hanger-Club Talk Brackets.
- Page 237 height-adjustable bench Installation Guides Section: ELECTRICS Date: May 2022 Page No: 1 of 10 Description: NAVIGATE BASE FEED INSTALLATION HABN_321c Rev. No: 02 Navigate Base Feed (HNBEBF), Base Feed Cover (HNBEBC), Chicago Base Feed (HNBEBFCH), Split Base Feed (HNBEBFS NOTE: Navigate Height Adjustable Base is shown for reference.
- Page 238 height-adjustable bench Installation Guides Section: ELECTRICS Date: May 2022 Page No: 2 of 10 Description: NAVIGATE BASE FEED INSTALLATION HABN_321c Rev. No: 02 Part and Product Identification A - Base Feed - End Condition (HNBEBF_E) x1 D - Chicago Base Feed - End Condition (HNBEBFCH_E) x1 A1 - Base Feed w/ Bracket D1 - Chicago Base Feed w/ (HNBEBF-END) x1...
- Page 239 height-adjustable bench Installation Guides Section: ELECTRICS Date: May 2022 Page No: 3 of 10 Description: NAVIGATE BASE FEED INSTALLATION HABN_321c INSTALL SPLIT BASE FEED INSTALL BOX COVER (OPTIONAL) NOTE: Cable Channel is hidden for illustration purposes NOTE: Connect the Base Feed to Power Harness STEP 1a: Align the Split Base Feed Bracket with Pilot Holes and Fasten it as shown STEP 1b: Install Box Cover.
- Page 240 height-adjustable bench Installation Guides Section: ELECTRICS Date: May 2022 Page No: 4 of 10 Description: NAVIGATE BASE FEED INSTALLATION HABN_321c INSTALL BASE FEED ATTACH BASE FEED & INSTALL CABLE TRAY NOTE: Chicago Base Feed (HNBEBFCH) is similar to Base Feed(HNBEBF) NOTE: Power Harness should always be a 24"...
- Page 241 height-adjustable bench Installation Guides Section: ELECTRICS Date: May 2022 Page No: 5 of 10 Description: NAVIGATE BASE FEED INSTALLATION HABN_321c INSTALL BASE FEED COVER LOOSEN SCREW STEP 4: Fasten Bracket to underside of Stretch bar using hardware kit for HAB Base Feed STEP 5: Loosen screw to adjust the height of the cover bracket.
- Page 242 height-adjustable bench Installation Guides Section: ELECTRICS Date: May 2022 Page No: 6 of 10 Description: NAVIGATE BASE FEED INSTALLATION HABN_321c ADJUST COVER TIGHTEN SCREW STEP 6: Adjust cover to level onto finished floor. STEP 7: Tighten screw to secure base feed to table.
- Page 243 height-adjustable bench Installation Guides Section: ELECTRICS Date: May 2022 Page No: 7 of 10 Description: NAVIGATE BASE FEED INSTALLATION HABN_321c INSERT CABLE INTO BASE FEED COVER STEP 8: Insert Base Feed cable into Base Feed Cover as shown on illustration above.
- Page 244 height-adjustable bench Installation Guides Section: ELECTRICS Date: May 2022 Page No: 8 of 10 Description: NAVIGATE BASE FEED INSTALLATION HABN_321c ORIENTATION OF BASE FEED PARALLE AND VERTICAL ORIENTATION NOTE: Parallel Orientation NOTE: Vertical Orientation REMOVE SCREWS FROM PLATE STEP 9: Remove screws to loosen mounting plate for base feed STEP 10: Reposition the mounting plate to parallel or vertical orientation...
- Page 245 height-adjustable bench Installation Guides Section: ELECTRICS Date: May 2022 Page No: 9 of 10 Description: NAVIGATE BASE FEED INSTALLATION HABN_321c INSTALL MID BASE FEED NOTE:Wire Channel and other electrics are Hidden for illustration purposes STEP 11: Fasten Middle Bracket and Base Feed. Install assembly to Stretcher bar as shown. Installation for Chicago Power Module is Similar.
- Page 246 height-adjustable bench Installation Guides Section: ELECTRICS Date: May 2022 Page No: 10 of 10 Description: NAVIGATE BASE FEED INSTALLATION HABN_321c NOTE NOTE: Wire Management NOTE: M-Clips STEP 12: Installer is to determine the layout for the data, wire management brackets and m-clips in the hatched area...
- Page 247 height adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 9 Section: ELECTRICS HABN_322a Rev. 01 Navigate Ceiling Feed (HNBECF), Navigate Chicago Ceiling Feed (HNBECFCH), Navigate Power Pole - End(HNBEPP_E) NOTE: Parts of the Frame are hidden for illustration purpose.
- Page 248 height adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 9 Section: ELECTRICS HABN_322a Part & Product Identification ITEM ITEM PREVIEW DESCRIPTION PART NUMBER QTY. PREVIEW DESCRIPTION PART NUMBER QTY. 2. Power Pole - End (HNBEPP_E) x1 Ceiling Feed HNBECF AEA23-E014- Upper Pole Cover...
- Page 249 height adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 9 Section: ELECTRICS HABN_322a INSTALL BRACKET TO POWER POLE ALLIGN LOWER POWER POLE TO HAB FRAME 2.10 2.10 (Do Not Fully Tighten) HAB Frame Stretcher Bar STEP 1:Fasten Bracket to Lower Power Pole Extrusion. Do not fully tighten as bracket needs STEP 2: Bring Lower Power Pole Extrusion underneath Height Adjustable Bench (HAB) to slide up or down.
- Page 250 height adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 9 Section: ELECTRICS HABN_322a SECURE BOTTOM EXTRUSION TO FRAME TIGHTEN BRACKET TO LOWER POWER POLE Underside View 2.10 STEP 3: Use Screws and washers Provided to fasten Power Pole Bracket to HAB Frame as STEP 4: Make sure lower pole ectrusion sits on the floor &...
- Page 251 height adjustable bench Installation Guides Date: Sept 2019 Page: 5 of 9 Section: ELECTRICS HABN_322a CEILING CUT OUT INSTALL UPPER EXTRUSION Top Portion Shown 3 1/2" 3 1/2" Power Pole length Bottom Portion Shown =distance + 3" STEP 5:Mark Power Pole position on the ceiling using Plum Bob line. Cut 3 1/2" x 3 1/2" STEP 6: Insert Upper Power Pole extrusion inside ceiling cut-out (Uncut edge down).
- Page 252 height adjustable bench Installation Guides Date: Sept 2019 Page: 6 of 9 Section: ELECTRICS HABN_322a INSTALL CEILING FEED INSTALL CEILING FEED STEP 7: Drop Ceiling Feed cable down through ceiling cut-out down along the Power Pole. STEP 8: Feed cable underneath Bracket. Slide junction box bracket inside Power Pole Extrusion.
- Page 253 height adjustable bench Installation Guides Date: Sept 2019 Page: 7 of 9 Section: ELECTRICS HABN_322a ATTACH LOWER COVER ATTACH UPPER COVER STEP 9: Tuck Cable and attach Power Pole Covers by engaging them into Lower Extrusion. STEP 10: Insert Upper Covers inside ceiling cut-out then engage into Upper Power Pole Extrusion.
- Page 254 height adjustable bench Installation Guides Date: Sept 2019 Page: 8 of 9 Section: ELECTRICS HABN_322a ATTACH CEILING PLATE & DRILL HOLES INSTALL PLATES 2.11 NOTE: Wire Channel is hiddden for Illustration Purpose. 2.10 STEP 11: Attach Ceiling Plates to Power Pole under the Ceiling. Drill holes for T-Nuts using STEP 12: Push T-nuts inside holes from the Top of the Ceiling tile.
- Page 255 height adjustable bench Installation Guides Date: Sept 2019 Page: 9 of 9 Section: ELECTRICS HABN_322a COVER PLATES INSTALL Backside View STEP 13: Expose the adhesive of the double sided tape on the back of the Cover Plate and slide Cover Plate from the top to cover cut-out on the side of Power Pole.
- Page 256 height-adjustable bench Installation Guides ELECTRICS Section: Date: May 2022 Page No: 1 of 9 HABN_322b Rev. No: 02 Navigate Power Pole - Mid (HNBEPP_M), Navigate Power Pole Single Sided - Mid (HNBEPP_S), Navigate Ceiling Feed (HNBECF) & Navigate Chicago Ceiling Feed (HNBECF) NOTE: HNBEPP_M is shown as an example.
- Page 257 height-adjustable bench Installation Guides ELECTRICS Section: Date: May 2022 Page No: 2 of 9 HABN_322b Rev. No: 02 Part and Product Identification B5 - Hardware Kit For Navigate Height Adjustable Bench Power Pole (X01-4349) x1 A - Ceiling Feed OR Chicago Ceiling Feed (HNBECF or HNBECFCH) x1 B5A - HAB Mid Mounting Bracket...
- Page 258 height-adjustable bench Installation Guides Section: ELECTRICS Date: May 2022 Page No: 3 of 9 HABN_322b CONNECT BRACKET ASSEMBLY (STANDARD) ATTACH LOWER EXTRUSION (STANDARD) NOTE: Cable Channels hidden for illustration NOTE: Cable Channels hidden for illustration NOTE: Install Connection Bracket then proceed Mid- Gable Installation STEP 1a: Install Connecting Bracket to the Underside of the Stretch Bar STEP 2a: After installing Mid-Gable, attach and align Lower Power Pole to Connecting Bracket...
- Page 259 height-adjustable bench Installation Guides Section: ELECTRICS Date: May 2022 Page No: 4 of 9 HABN_322b MOUNT CONNECTING BRACKET (SINGLE SIDED) ATTACH LOWER EXTRUSION (SINGLE SIDED) STEP 1b: Install Mounting Bracket on the Frame Link. Secure it by fastening the Thumb Screw STEP 2b: After installing Mid-Gable, attach and align Lower Power Pole to Connecting Bracket as shown...
- Page 260 height-adjustable bench Installation Guides Section: ELECTRICS Date: May 2022 Page No: 5 of 9 HABN_322b SECURE BOTTOM EXTRUSION CEILING CUT OUT NOTE: Frame Legs hidden for illustration Power Pole Length = distance +3" STEP 3: Fasten Bracket to Lower Power Pole Body STEP 4: Mark Power Pole position on the cieling using Plum Bob line.
- Page 261 height-adjustable bench Installation Guides Section: ELECTRICS Date: May 2022 Page No: 6 of 9 HABN_322b INSTALL UPPER EXTRUSION CEILING FEED ASSEMBLY NOTE: Cable Channel hidden for illustration STEP 5: Insert Upper Power Pole Extrusion inside Ceiling Cut-Out (Uncut edge down). STEP 6: Drop Ceiling Feed cable down through ceiling Cut-out down along the Power Pole Drop Power Pole Upper Extrusion on the Top of Lower Extrusion and Connect them Slide junction box Inside the Power Pole Extrusion...
- Page 262 height-adjustable bench Installation Guides Section: ELECTRICS Date: May 2022 Page No: 7 of 9 HABN_322b CABLE MANAGEMENT NOTE: Cable Channel Cable Channel hidden for illustration STEP 7: Open Mid-Gable Top Cover and Connect Ceiling Feed to fish Cable thru underside of Cable Channel...
- Page 263 height-adjustable bench Installation Guides Section: ELECTRICS Date: May 2022 Page No: 8 of 9 HABN_322b ATTACH LOWER COVER ATTACH UPPER COVER NOTE: Cable Channel, Leg, and Cable hidden for illustration STEP 8: Tuck cable and attach Power Pole Covers by engaging them into Lower Extrusion STEP 9: Insert Upper Covers inside ceiling cut-out then engage into Upper Power Pole Extrusion...
- Page 264 height-adjustable bench Installation Guides Section: ELECTRICS Date: May 2022 Page No: 9 of 9 HABN_322b ATTACH CEILING PLATE THEN DRILL HOLES SECURE PLATES WARNING:Don't connect to power source until installation is complete. All wire connections must be performed by a licensed electrician in accordance with applicable codes and regulations.
- Page 265 height adjustable bench Installation Guides ELECTRICS Section: Date: Sept 2020 Page No: 1 of 6 Description: NAVIGATE POWER CONSERVATION SYSTEM HABN_323 Rev. No: 0 Power Conservation System (HNBEPC) Part and Product Identification NOTE: 1. Sensor cables are identified by different Sensor Wire Color: Green: Circuit 1 colors.
- Page 266 height adjustable bench Installation Guides Section: ELECTRICS Date: Sept 2020 Page No: 2 of 6 Description: NAVIGATE POWER CONSERVATION SYSTEM HABN_323 INSTALL POWER CONSERVATION SYSTEM CONNECT POWER CONSERVATION SYSTEM Controlled Power (Output) NOTE: Only when 1 Power Conservation System Kit is specified per 2 stations Controlled Power...
- Page 267 height adjustable bench Installation Guides Section: ELECTRICS Date: Sept 2020 Page No: 3 of 6 Description: NAVIGATE POWER CONSERVATION SYSTEM HABN_323 MOUNT WORKSURFACES MOUNT SENSORS STEP 3: Mount Worksurfaces STEP 4: Mount Sensors using Wood Screws...
- Page 268 height adjustable bench Installation Guides Section: ELECTRICS Date: Sept 2020 Page No: 4 of 6 Description: NAVIGATE POWER CONSERVATION SYSTEM HABN_323 DESCRIPTION R 8.0' Note: Sensor placement will be based on location of User, Length of CAT3 Cable, and Desk Configuration...
- Page 269 height adjustable bench Installation Guides Section: ELECTRICS Date: Sept 2020 Page No: 5 of 6 Description: NAVIGATE POWER CONSERVATION SYSTEM HABN_323 CONNECT SENSOR TO POWER CONSERVATION SYSTEM Sensor signal port for controlled circuit 1 Note: Press CAT3 Cable into Wire Manager Sensor signal port for controlled circuit 2 STEP 5: Connect Sensor to Sensor using CAT3 Cable...
- Page 270 height adjustable bench Installation Guides Section: ELECTRICS Date: Sept 2020 Page No: 6 of 6 Description: NAVIGATE POWER CONSERVATION SYSTEM HABN_323 SENSOR GANGING STEP 6: Connect Sensors together using CAT3 Cable...
- Page 271 height-adjustable bench Installation Guides ELECTRICS Section: Date: Sep 2024 Page No: 1 of 7 Description: NAVIGATE POWER POLE 120 HABN_324 Rev. No: 1 Navigate Power Pole 120 (HNBEPPT), Navigate Ceiling Feed (HNBECF)
- Page 272 height-adjustable bench Installation Guides ELECTRICS Section: Date: Sep 2024 Page No: 2 of 7 Description: NAVIGATE POWER POLE 120 HABN_324 Rev. No: 1 Part & Product Identification A - Navigate Power Pole 120 (N09-8570) x1 A1 - Upper Power Pole Body (AEA21-0200) x1 A5i - Plastic Wire Cap A5a - Ceiling Plate for EPQE...
- Page 273 height-adjustable bench Installation Guides Section: ELECTRICS Date: Sep 2024 Page No: 3 of 7 Description: NAVIGATE POWER POLE 120 HABN_324 INSTALL BRACKETS ATTACH LOWER EXTRUSION A5 l A5 c A5 j A5 h STEP 1: Install Bracket to Mid Gable Top Mounting Plate. STEP 2: Align and attach Lower Power Pole to Connecting bracket as shown.
- Page 274 height-adjustable bench Installation Guides Section: ELECTRICS Date: Sep 2024 Page No: 4 of 7 Description: NAVIGATE POWER POLE 120 HABN_324 ATTACH UPPER EXTRUSION FASTEN SCREWS STEP 3: Insert Upper Power Pole Extrusion inside ceiling cut-out (uncut edge down). Drop STEP 4: Connect Upper and Lower Extrusion together using Connection Plate Screws. Power Pol Upper Extrusion on the top of the Lower Extrusion.
- Page 275 height-adjustable bench Installation Guides Section: ELECTRICS Date: Sep 2024 Page No: 5 of 7 Description: NAVIGATE POWER POLE 120 HABN_324 JUNCTION BOX INSTALLATION WIRE MANAGEMENT NOTE: Junction Box Wire not shown. STEP 5: Slide Junction Box Bracket inside the Power Pole Extrusion. STEP 6: Drop Ceiling Feed cable down through ceiling cut-out down along the Power Pole.
- Page 276 height-adjustable bench Installation Guides Section: ELECTRICS Date: Sep 2024 Page No: 6 of 7 Description: NAVIGATE POWER POLE 120 HABN_324 ATTACH LOWER COVER ATTACH UPPER COVER STEP 7: Tuck cable and attach Power Pole Covers by engaging them into Lower Extrusion. STEP 8: Insert Upper Covers inside ceiling cut-out then engage into Upper Power Pole Extrusion.
- Page 277 height-adjustable bench Installation Guides Section: ELECTRICS Date: Sep 2024 Page No: 7 of 7 Description: NAVIGATE POWER POLE 120 HABN_324 ATTACH CEILING PLATES FASTEN SCREWS STEP 9: Attach Ceiling Plates to Power Pole under the ceiling. STEP 10: Push T-nuts inside holes from the top of the ceiling tile. Wrap Cover plates around the Power Pole and fasten using hardware provided.
- Page 278 height-adjustable bench Installation Guides Date: Sept 2019 Page: 1 of 4 Section: ELECTRICS HABN_325 Rev. CENTER ELECTRICAL GROMMET (HNBECEG)
- Page 279 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 4 Section: ELECTRICS HABN_325 Part & Product Identification ITEM ITEM PREVIEW DESCRIPTION PART NUMBER QTY. PREVIEW DESCRIPTION PART NUMBER QTY. 1. NAVIGATE CENTER ELECTRICAL GROMMET (HNBECEG) XEPB-PD- POWER MODULE USBAC GROMMET YEAG01-RAW COVER...
- Page 280 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 4 Section: ELECTRICS HABN_325 ASSEMBLE ATTACHMENTS MOUNT POWER MODULE STEP 1: Assemble Plate, Bracket Mount, and Power Module with screws provided. STEP 2: Mount Power Module as shown above.
- Page 281 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 4 Section: ELECTRICS HABN_325 PLACE GROMMET COVER STEP 3: Place the Grommet Cover as shown above.
- Page 282 height-adjustable bench Installation Guides ELECTRICS Section: Date: Sep 2023 Page No: 1 of 4 Description: NAVIGATE E-CHAIN VERTICAL CABLE MANAGER HABN_326 Rev. No: 0 Navigate E-Chain Vertical Cable Manager (HNBEEE) Part and Product Identification A - Vertical Wire Carrier (N01-4577-X) x1 B - #8-18x1/2"...
- Page 283 height-adjustable bench Installation Guides Section: ELECTRICS Date: Sep 2023 Page No: 2 of 4 Description: NAVIGATE E-CHAIN VERTICAL CABLE MANAGER HABN_326 REMOVE KNOCK OUTS REMOVE ENDS OF E-CHAIN NOTE: There is a maximum of 4 E-Chains for HNBFCNB and 2 E-Chains for HNBFCNS STEP 1: Remove knock outs on Wire Channel as needed.
- Page 284 height-adjustable bench Installation Guides Section: ELECTRICS Date: Sep 2023 Page No: 3 of 4 Description: NAVIGATE E-CHAIN VERTICAL CABLE MANAGER HABN_326 INSERT CONNECTOR INTO CHANNEL SLOT SECURE OTHER CONNECTOR STEP 3: Install E-Chain Connector to Wire Channel by bringing the Connector through the previously made slot on the Wire Channel.
- Page 285 height-adjustable bench Installation Guides Section: ELECTRICS Date: Sep 2023 Page No: 4 of 4 Description: NAVIGATE E-CHAIN VERTICAL CABLE MANAGER HABN_326 INSERT WIRE INTO E-CHAIN SECURE WIRE STEP 6: Insert Wire into E-Chain body, bring Wire through the E-Chain and out the other side.
