height-adjustable bench
Section:
SOLID GABLES & CABLE CHANNEL
2.1
STEP 8:Mount Outside Cover Assembly to the highlighted part of the Inside Cover Assembly as shown.
Installation Guides
MOUNT OUTSIDE COVER ASSEMBLY
NOTE: Parts of the Frame are
hidden for Illustration Purpose.
Section View
Date: Feb 2022
Page: 9 of 18
HABN_223b
