Teknion Navigate height-adjustable bench Manual page 179

height-adjustable bench
Section: SCREENS AND GABLES
ATTACH BRACKETS TO FRAME
STEP 5: Secure Inner Bracket to Frame using the Screws provided.
2.3
Installation Guides
2.1
NOTE: For the installation instructions of the Wire
Channel (HNBFCNS), refer to guide HABN_223f. For
the Corridor Screen (HNBLS), refer to guide HAB_224.
STEP 6: If a Corridor Screen is installed, place the Stick-On Clear Bumper on the Screen.
ATTACH BUMPER (OPTIONAL)
Date: Sept 2019 Page: 5 of 6
HAB_225c
3
