4.9.4 MLD Snooping

4.9.4.1 MLD Snooping Settings

This page allows you to configure the MLD Snooping settings for Managed PoE+ Switch as the screen in
appears.
The page includes the following fields:
Object
•
MLD Snooping State
• Version
• MLD Group Aged Out
• GMI (10-65535)
• Router Aging Time
(10-65535)
• MLD Immediate Leave
Button
: press this button to take effect.
Figure 4-9-21: MLD Snooping Settings Configuration Page Screenshot
Description
This column provides configuring enable or disable the MLD Snooping function.
This column provides selecting the IGMP Snooping operation version; the
default version is MLDv2 and available options are MLDv1 and MLDv2.
This column provides configuring enable or disable the MLD Group Aged Out
function.
This column provides configuring the value for Group Member Interval Time; the
default value is 100 seconds and the available range is 10 to 65535 seconds.
After the dynamic Group is established, the time is used to ask if there is
member.
This column provides configuring the value for Router Aging Time; the default
value is 100 seconds and the available range is 10 to 65535 seconds.
The time the dynamic Router Port exists, and if the Query packet is not
continuously received, the dynamic Router Port clears.
This column provides configuring enable or disable the MLD Immediate Leave
function.
