Planet Networking & Communication FGSD-1008HPS User Manual page 178

Press "Detail" from MIB Counter web page, which allows you to view advanced per port MIB counter information as the screen
in Figure 4-10-3 appears
The page includes the following fields:
Object
•
Port No.
• Type
Figure 4-10-3: Per Port Detail MIB Counter Page Screenshot
Description
This column provides displaying per port list.
This column provides displaying traffic with various packet lengths and types,
and the available options are :
64b
65-127b
128-255b
256-511b
512-1023b
1024-1518b
Oversize
Bcst: Broadcast
Mcst:Multicast
Ucst: Unicast
Pause
Pkts
Bytes
Drop
Drop others
CRC
