4.2.4.1 SNMP View Table

The SNMP View Table provide to set view rules for allow or deny access to certain MIB objects, the configured column is used
to input the view name, subtree OID and change the view type. The screen in
The Current column is used to show the SNMP View Table configuration.
Object
•
View Name
•
Subtree OID
•
View Type
Buttons
: press this button to take affect.
: press this button to delete.
Each view need to configure a view rule, otherwise it will affect the SNMP function.
Figure 4-2-6: SNMP View Table Configuration Page Screenshot
Description
Configure the Managed PoE+ Switch view name information on this web page, the
maximum length is 20 characters.
Configure the Managed PoE+ Switch Subtree OID information on this web page.
Configure the Managed PoE+ Switch view type mode on this web page, the available
options are Included and Excluded.
Figure 4-2-6
53
User's Manual of FGSW-Series
appears.
