Reset Button Pressed and Released
< 5 sec: System Reboot
> 5 sec: Factory Default
■ RJ45 Console Port
The console port is a DB9, RS-232 male serial port to RJ45 connector. It is an interface for connecting a terminal directly.
Through the console port, it provides rich diagnostic information including IP Address setting, factory reset, port
management, link status and system setting. Users can use the attached RS-232 to RJ45 console cable in the package
and connect to the console port on the device. After the connection, users can run any terminal emulation program (Hyper
Terminal, ProComm Plus, Telix, Winterm and so on) to enter the startup screen of the device.
Function
Reboot the Managed PoE+ Switch.
Reset the Managed PoE+ Switch to Factory Default
configuration. The Managed PoE+ Switch will then reboot
and load the default settings as below:
Default Username: admin
Default Password: admin
Default IP address: 192.168.0.100
Subnet mask: 255.255.255.0
Default Gateway: 192.168.0.254
24
User's Manual of FGSW-Series
