Planet Networking & Communication FGSD-1008HPS User Manual page 77

•
Period for (Giga/100/10)
Storm Control State
• Port Selection
•
Broadcast
•
Multicast
• DLF
• ARP
• ICMP
• Port No.
•
Broadcast
•
Multicast
• DLF
• ARP
• ICMP
Button
: press this button to take effect.
Set reception period and the available options are shown below:
200us/2ms/20ms
1ms/10ms/100ms
10ms/10ms/10ms
100ms/100ms/100ms
Select specific port for further configuration.
Enable or disable the broadcast storm control function.
Enable or disable the multicast storm control function.
Enable or disable the unknown destination MAC packets control function.
Enable or disable the ARP packets control function.
Enable or disable the ICMP packets control function.
Display per port list.
Display per port broadcast storm control setting.
Display per port multicast storm control setting.
Display per port unknown destination MAC packets control setting.
Display per port ARP packets control setting.
Display per port ICMP packets control setting.
77
User's Manual of FGSW-Series
