- Page 1 User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G...
- Page 2 User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G Trademarks Copyright © PLANET Technology Corp. 2023. Contents are subject to revision without prior notice. PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their respective owners. Disclaimer PLANET Technology does not warrant that the hardware will work properly in all environments and applications, and makes no warranty and representation, either implied or expressed, with respect to the quality, performance, merchantability, or fitness for a particular purpose.
-
Page 3: Table Of Contents
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G TABLE OF CONTENTS 1. INTRODUCTION ..................6 1.1 P ..................... 6 ACKAGE ONTENTS 1.2 P ....................7 RODUCT ESCRIPTION 1.3 H ..................13 OW TO ANUAL 1.4 P ....................14 RODUCT EATURES 1.5 P ................... 16... - Page 4 User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 4.2.5 NMS .................... 39 4.2.6 Remote Syslog ................39 4.2.7 Event Log ..................40 4.3 N ........................41 ETWORK 4.3.1 LAN ..................... 41 4.3.2 IPv6 ..................... 42 4.3.3 DDNS ..................43 4.4 S ........................44 ECURITY 4.4.1 Firewall ..................
- Page 5 User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G APPENDIX A ....................67 A.1 MDI S ......................67 ETTINGS A.2 P ..............67 OWER EVICE LASSIFICATION ALUES A.3 DATA OUT P RJ45 P .......... 68 NJECTOR SSIGNMENTS...
-
Page 6: Introduction
1.1 Package Contents Open the box of the 802.3bt PoE++ Managed Injector Hub and carefully unpack it. The box should contain the following items: The UPOE-800G, UPOE-1600G or UPOE-2400G x 1 QR Code Sheet x 1 Power Cord x 1 ... -
Page 7: Product Description
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 1.2 Product Description PLANET’s UPOE Managed PoE++ Injector Hub series, a high-density, rack-mountable managed and quick PoE++ solution, is designed to perfectly upgrade an existing network infrastructure to IEEE 802.3bt Power over Ethernet Plus Plus network system without replacing the existing Ethernet Switch. The UPOE Managed PoE++ Injector Hub series’... - Page 8 User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 802.3bt PoE++ 95-watt Power over 4-pair UTP Solution As the UPOE Managed PoE++ Injector Hub series adopts the IEEE 802.bt PoE++ standard technology, it is capable to source up to 95 watts of power by using all the four pairs of standard Cat5e/6 Ethernet cabling to deliver power and full-speed data to each remote PoE compliant powered device (PD).
- Page 9 User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 802.3bt PoE++ and Advanced PoE Power Output Mode Management To meet the demand of various powered devices consuming stable PoE power, the UPOE Managed PoE++ Injector Hub series supports multi-PoE operation modes that include 95-watt 802.3bt type-4 PoE++ mode, and 4-pair legacy and force modes to solve the incompatibility of non-standard 4-pair PoE PDs in the field.
- Page 10 User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G Built-in Unique PoE Functions for Powered Device Management As it is the Managed PoE++ Injector Hub for surveillance, wireless and VoIP networks, the UPOE Managed PoE++ Injector Hub series features the following special PoE management functions: ...
- Page 11 User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G PoE Schedule for Energy Savings Under the trend of energy savings worldwide and contributing to environmental protection on the Earth, the UPOE Managed PoE++ Injector Hub series can effectively control the power supply besides its capability of giving high watts power.
- Page 12 User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G Cybersecurity Network Solution to Minimize Security Risks The cybersecurity feature included to protect the UPOE Managed PoE++ Injector Hub series management in a mission-critical network virtually needs no effort and cost to install. Both TLSv1.2 and TLSv1.3 protocols are utilized to provide strong protection against advanced threats.
-
Page 13: How To Use This Manual
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 1.3 How to Use This Manual This User Manual is structured as follows: Section 2, Installation It explains the functions of 802.3bt PoE++ Managed Injector Hub and how to physically install the 802.3bt PoE++ Managed Injector Hub. -
Page 14: Product Features
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 1.4 Product Features Interface UPOE-800G Complies with the IEEE 802.3, IEEE 802.3u and IEEE 802.3ab Ethernet standards 16-port RJ45 8-port 10/100/1000Mbps “Data input” 8-port 10/100/1000Mbps “Data + Power output” One 10/100/1000BASE-T management port UPOE-1600G ... - Page 15 Reset button for resetting to default setting and system reboot LED indicators for PoE ready and PoE activity LED indicators for power alert and fan alert LED indicators for PoE power usage status (watts) - UPOE-800G/UPOE-1600G only FCC Part 15 Class A, CE...
-
Page 16: Product Specifications
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 1.5 Product Specifications Product UPOE-800G UPOE-1600G UPOE-2400G Hardware Management Port 1 x RJ45; 10/100/1000BASE-T, auto-negotiation, auto-MDI/MDIX “Data” Input Ports 8 x RJ45 16 x RJ45 24 x RJ45 Interface “Data + Power” 8 x RJ45 16 x RJ45... - Page 17 User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 802.3bt mode: maximum 95 watts End-span mode: maximum 36 watts Mid-span mode: maximum 36 watts 802.3bt: 1/2(-), 3/6(+), 4/5(+), 7/8(-) Power Pin Assignment End-span: 1/2(-), 3/6(+) Mid-span: 4/5(+), 7/8(-) ...
- Page 18 User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G PLANET Smart Discovery utility PLANET NMS system and CloudViewer for deployment management Scheduled System Power RebootingNetwork Diagnostic − ICMPv6/ICMPv4 Remote Ping − Trace Route SNMP v1, v2c and v3 for system status monitoring SNMP Management SNMP trap for alarm notification of events...
-
Page 19: Installation
Figures 2-1-1, 2-1-2 and 2-1-3 show the front panels of the 802.3bt PoE++ Managed Injector Hubs. Front Panel of UPOE-800G Figure 2-1-1: UPOE-800G Front Panel Front Panel of UPOE-1600G Figure 2-1-2: UPOE-1600G Front Panel Front Panel of UPOE-2400G Figure 2-1-3: UPOE-2400G Front Panel ■... -
Page 20: Led Indicators
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G Reset Button Pressed and Released Function About 5 second Reboot the 802.3bt PoE++ Managed Injector Hub. Reset the 802.3bt PoE++ Managed Injector Hub to Factory Default configuration. The 802.3bt PoE++ Managed Injector About 10 seconds Hub will reboot and load the default IP settings. - Page 21 User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G UPOE-1600G System Color Function SYS Power Green Lights to indicate power on. PoE Failure Lights to indicate PoE module failure. Fan1 Failure Lights to indicate Fan 1 has stopped. Fan2 Failure Lights to indicate Fan 2 has stopped.
-
Page 22: Injector Rear Panel
Figures 2-1-5 & 2-1-6 & 2-1-7 shows the rear panel of the 802.3bt PoE++ Managed Injector Hub. Figure 2-1-5: UPOE-800G Rear Panel Figure 2-1-6: UPOE-1600G Rear Panel Figure 2-1-7: UPOE-2400G Rear Panel The 802.3bt PoE++ Managed Injector Hub is a power-required device, meaning 802.3bt PoE++ Managed Injector Hub will not work till it is powered. -
Page 23: Installing The 802.3Bt Poe++ Managed Injector Hub
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 2.2 Installing the 802.3bt PoE++ Managed Injector Hub This section describes how to install your 802.3bt PoE++ Managed Injector Hub and make connections to the 802.3bt PoE++ Managed Injector Hub. Please read the following topics and perform the procedures in the order being presented. -
Page 24: Rack Mounting
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 2.2.2 Rack Mounting To install the 802.3bt PoE++ Managed Injector Hub in a 19-inch standard rack, follow the instructions described below. Step 1: Place your 802.3bt PoE++ Managed Injector Hub on a hard flat surface, with the front panel positioned towards your front side. -
Page 25: Network Application Installation
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 2.2.3 Network Application Installation The 802.3bt PoE++ Managed Injector Hub is not an equipment with data switching function between data ports. To inject PoE power and transmit data packets to PDs, the 802.3bt PoE++ Managed Injector Hub is usually linked to an Ethernet switch. -
Page 26: Power Over Ethernet Powered Device
30~60 watts Since each PoE port of 802.3bt PoE++ Managed Injector Hub supports 54V DC (UPOE-800G/ UPOE-1600G/UPOE-2400G) PoE power output, be sure that the powered device’s acceptable DC power is 54V DC (UPOE-800G/UPOE-1600G/UPOE-2400G); otherwise, it will damage the PD. -
Page 27: Management
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 3 MANAGEMENT This chapter describes how to manage the 802.3bt PoE++ Managed Injector Hub with the following sections included: - Overview - Management Method - Logging on to the 802.3bt PoE++ Managed Injector Hub 3.1 Overview The 802.3bt PoE++ Managed Injector Hub provides a user-friendly, Web interface where you can perform various device... -
Page 28: Management Method
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 3.3 Management Method User can manage the 802.3bt PoE++ Managed Injector Hub by Web Management via a network connection. 3.3.1 Web Management The 802.3bt PoE++ Managed Injector Hub can be configured through an Ethernet connection. The factory default IP address is 192.168.0.100 with subnet mask 255.255.255.0, so please make sure the manager PC must be set to the... -
Page 29: Planet Smart Discovery Utility
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 3.3.2 PLANET Smart Discovery Utility For easily listing the 802.3bt PoE++ Managed Injector Hub in your Ethernet environment, the search tool -- PLANET Smart Discovery Utility -- is an ideal solution. The following installation instructions are to guide you to running the PLANET Smart Discovery Utility. - Page 30 User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G This utility shows all necessary information from the devices, such as MAC address, device name, firmware version and device IP subnet address. It can also assign new password, IP subnet address and description of the devices.
-
Page 31: Web Configuration
802.3bt PoE++ Managed Injector Hub to enable its smart function. The following web screen is based on the UPOE-2400G. The displays of the UPOE-800G and UPOE-1600G are the same as that of the UPOE-2400G. - Page 32 User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G Main Menu Object Description System Provides system information of the 802.3bt PoE++ Managed Injector Hub. Provides LAN and network configuration of the 802.3bt PoE++ Managed Injector Network Hub. Provides firewall and security configuration of the 802.3bt PoE++ Managed Security Injector Hub.
-
Page 33: System
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 4.2 System Use the system menu items to display and configure basic administrative details of the 802.3bt PoE++ Managed Injector Hub. The System menu shown in Figure 4-2-1 provides the following features to configure and monitor system. -
Page 34: System Information
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 4.2.1 System Information This section displays system information of 802.3bt PoE++ Managed Injector Hub as the screen in Figure 4-2-2 appears. Table 4-2-1 & 4-2-2 describes the system information of the 802.3bt PoE++ Managed Injector Hub. -
Page 35: System Service
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 4.2.2 System Service This section displays the system service status of the 802.3bt PoE++ Managed Injector Hub, the system service are shown in Figure 4-2-3 appears. Table 4-2-3 & 4-2-4 describes the system service object of 802.3bt PoE++ Managed Injector Hub. -
Page 36: Connection Status
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 4.2.3 Connection Status This section display the ARP table of 802.3bt PoE++ Managed Injector Hub as the screen in Figure 4-2-4 appears and Table 4-2-5 describes the ARP table object of 802.3bt PoE++ Managed Injector Hub. -
Page 37: Snmp
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 4.2.4 SNMP This section provides the SNMP Setting of 802.3bt PoE++ Managed Injector Hub as the screen in Figure 4-2-5 appears. Table 4-2-6 & 4-2-7 & 4-2-8 describes the Password Setting objects of 802.3bt PoE++ Managed Injector Hub. - Page 38 User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G SNMP Object Description SNMP Disable or enable the SNMP function. The default configuration is enabled. SNMP Versions Choose specific SNMP version. The default configuration is SNMPv1, v2c. Read/Write Community Allows entering characters for SNMP Read/Write Community of the 802.3bt PoE++ Managed Injector Hub.
-
Page 39: Nms
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 4.2.5 NMS This section provide NMS Controller and CloudViewer Server – Internet screens – is shown in Figure 4-2-6. Table 4-2-9 describes the NMS Setting objects of 802.3bt PoE++ Managed Injector Hub. Figure 4-2-6: NMS Configuration Web Page Screen... -
Page 40: Event Log
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 4.2.7 Event Log This section provides display system event log, the screen shown in Figure 4-2-8. Table 4-2-11 describes the system event log objects of 802.3bt PoE++ Managed Injector Hub. Figure 4-2-8: Event Log Web Page... -
Page 41: Network
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 4.3 Network The Network function provides LAN, IPv6 and DDNS configuration of the 802.3bt PoE++ Managed Injector Hub as shown Figure 4-3-1. Figure 4-3-1: Network Menu Network Object Description Allows setting LAN interface. IPv6 Allows setting IPv6 interface. -
Page 42: Ipv6
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G LAN Configuration Object Description Connection Type Provide Static and DHCP for IP connection type, the default is Static. The LAN IP address of the 802.3bt PoE++ Managed Injector Hub and default IP Address is 192.168.0.100. Netmask Default is 255.255.255.0. -
Page 43: Ddns
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 4.3.3 DDNS The 802.3bt PoE++ Managed Injector Hub offers the DDNS (Dynamic Domain Name System) feature, which allows the hosting of a website, FTP server, or e-mail server with a fixed domain name (named by yourself) and a dynamic IP address, and then your friends can connect to your server by entering your domain name no matter what your IP address is. -
Page 44: Security
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G DDNS Configuration Object Description By default, the DDNS service is disabled. DDNS Service If user needs to enable the function, please set it as enable. User is able to select the interface for DDNS service. Interface By default, the interface is LAN. -
Page 45: Firewall
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 4.4.1 Firewall A "Denial-of-Service" (DoS) attack is characterized by an explicit attempt by hackers to prevent legitimate users of a service from using that service. The 802.3bt PoE++ Managed Injector Hub can prevent specific DoS attacks as shown in Figure 4-4-2. - Page 46 User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G If the function is enabled, when the number of the current UPD-FLOOD packets is beyond the set value, the 802.3bt PoE++ Managed Injector Hub Block UDP Flood will start the blocking function immediately. The default configuration is disabled.
-
Page 47: Mac Filtering
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 4.4.2 MAC Filtering Entries in this table are used to restrict certain types of data packets from your local network or Internet through the 802.3bt PoE++ Managed Injector Hub. Use of such filters can be helpful in securing or restricting your local network as... -
Page 48: Poe
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 4.5 PoE The PoE menu provides PoE Configuration, PoE Status, PoE Schedule and PoE Alive Check as shown in Figure 4-5-1. Please refer to the following sections for the details. Figure 4-5-1: PoE Menu Object Description... -
Page 49: Poe Configuration
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 4.5.1 PoE Configuration This section provides PoE (Power over Ethernet) Configuration and PoE output status of 802.3bt PoE++ Managed Injector Hub; screen in Figure 4-5-2 appears. Table 4-5-1 describes the PoE Configuration object of 802.3bt PoE++... - Page 50 User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G Object Description Allows user to disable/enable PoE function. • System PoE Admin Mode • Power Supply Displays PoE power supply status. Allows user to configure power limit mode, which can be chosen. Consumption: Based on the real device power consumption where PoE power is delivered as system default setting is in this mode.
-
Page 51: Poe Status
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G Displays PoE class level. • Device Class The IEEE 802.3af standard offers PoE class level from 1 to 3 and IEEE 802.3at standard offers the class from 1 to 4. • Current Used [mA] Displays PoE device current. -
Page 52: Poe Schedule
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 4.5.3 PoE Schedule This page allows the user to define PoE schedule and scheduled power recycling. PoE Schedule Besides being used as an IP Surveillance, the 802.3bt PoE++ Managed Injector Hub is certainly applicable to construct any PoE network including VoIP and Wireless LAN. - Page 53 User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G The screen in Figure 4-5-4 appears. Figure 4-5-4: PoE Schedule Screenshot Please press Add button to start setting PoE Schedule function. You have to set PoE schedule to profile and then go back to PoE Port Configuration, and select “Schedule” mode from per port “PoE Mode” option to enable you to indicate which schedule profile could be applied to the PoE port.
-
Page 54: Poe Alive Check
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 4.5.4 PoE Alive Check The 802.3bt PoE++ Managed Injector Hub can be configured to monitor connected PD’s status in real-time via ping action. Once the PD stops working and without response, the 802.3bt PoE++ Managed Injector Hub is going to restart PoE port power, and bring the PD back to work. - Page 55 User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G The page includes the following fields: PD Alive Check Object Description Mode Allows user to enable or disable per port PD Alive Check function. By default, all ports are disabled. Remote PD IP Address This column allows user to set PoE device IP address for system making ping to the PoE device.
-
Page 56: Maintenance
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 4.6 Maintenance The Maintenance menu provides the following features for managing the system Figure 4-6-1: Maintenance Maintenance Object Description Administrator Allows changing the login username and password. Date & Time Allows setting Date & Time function. -
Page 57: Administrator
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 4.6.1 Administrator To ensure the 802.3bt PoE++ Managed Injector Hub's security is secure, you will be asked for your password when you access the 802.3bt PoE++ Managed Injector Hub's Web-based utility. The default user name and password are "admin". -
Page 58: Date And Time
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 4.6.2 Date and Time This section assists you in setting the system time of the 802.3bt PoE++ Managed Injector Hub. You are able to either select to set the time and date manually or automatically obtain the GMT time from Internet as shown in Figure 4-6-3. -
Page 59: Saving/Restoring Configuration
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 4.6.3 Saving/Restoring Configuration This page shows the status of the configuration. You may save the setting file to either USB storage or PC and load the setting file from USB storage or PC as Figure 4-6-4... -
Page 60: Reboot/Reset
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 4.6.4 Reboot/Reset This page enables the device to be rebooted from a remote location. Once the Reboot button is pressed, users have to re-log in the Web interface as Figure 4-6-6 is shown below: Figure 4-6-6: Reboot/Reset Web Page... -
Page 61: Diagnostics
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 4.6.6 Diagnostics The page allows you to issue ICMP PING packets to troubleshoot IP connectivity issues. After you press “Ping”, ICMP packets are transmitted, and the sequence number and roundtrip time are displayed upon reception of a reply. The Page refreshes automatically until responses to all packets are received, or until a timeout occurs. - Page 62 User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G Figure 4-6-9: Trace Route Web Page Trace Route Object Description Target Host The destination IP Address or domain. Trace The time of ping. Table 4-6-8: Descriptions of the Trace Route Objects Screen Be sure the target IP address is within the same network subnet of the 802.3bt PoE++ Managed Injector Hub, or you have to set up the correct gateway IP address.
-
Page 63: Power Over Ethernet Overview
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 5. POWER OVER ETHERNET OVERVIEW What is PoE? Based on the global standard IEEE 802.3af, PoE is a technology for wired Ethernet, the most widely installed local area network technology adopted today. PoE allows the electrical power necessary for the operation of each end-device to be carried by data cables rather than by separate power cords. - Page 64 User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G Figure 5-1-1 - Power Supplied over the Spare Pins The data pairs are used. Since Ethernet pairs are transformer coupled at each end, it is possible to apply DC power to the center tap of the isolation transformer without upsetting the data transfer. In this mode of operation the pair on pins 3 and 6 and the pair on pins 1 and 2 can be of either polarity.
-
Page 65: The Poe Provision Process
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 6. THE POE PROVISION PROCESS While adding PoE support to networked devices is relatively painless, it should be realized that power cannot simply be transferred over existing Cat5e cables. Without proper preparation, doing so may result in damage to devices that are not designed to support provision of power over their network interfaces. -
Page 66: Start-Up
User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G 6.3 Start-up Once line detection and optional classification stages are completed, the PSE must switch from low voltage to its full voltage capacity (44-57 Volts) over a minimal amount of time (above 15 microseconds). A gradual startup is required, as a sudden rise in voltage (reaching high frequencies) would introduce noise on the data lines. - Page 67 User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G APPENDIX A A.1 MDI Settings The Medium-Dependent Interface (MDI or RJ45) serves as the data/power interface between Ethernet elements. As such, it has two optional connection methods to carry the power. Named Alternative A & B, Table 1 details the two power feeding alternatives.
- Page 68 User’s Manual of UPOE-800G/UPOE-1600G/UPOE-2400G A.3 DATA OUT PoE Injector RJ45 Port Pin Assignments PIN NO 10BASE-T 1000BASE-T 100BASE-TX A.4 RJ45 Pin Assignment of Non-802.3af/802.3at Standard PD with PoE Mid-span PD Pin out of Cisco non-802.3af standard PD Pin out of POE Mid-span...
