4.9.1.2 STP Port Settings

This page allows you to configure the STP Port settings for Managed PoE+ Switch as the screen in
The page includes the following fields:
Object
• Port Selection
• State
• Edge Port
• BPDU Protect
• Root Protect
• Loop Protect
• Port
Figure 4-9-6: STP Port Settings Configuration Page Screenshot
Description
Select specific port for further configuration.
This column provides configuring enable or disable the spanning tree function
on specific port; the default mode is Disable. Also display current status of per
port.
This column provides configuring enable or disable the Edge Port function on
specific port; the default mode is Disable. Also display current status of per port.
This column provides configuring enable or disable the BPDU Protect function
on specific port; the default mode is Disable. Also display current status of per
port.
This column provides configuring enable or disable the Root Protect function on
specific port; the default mode is Disable. Also display current status of per port.
This column provides configuring enable or disable the Loop Protect function on
specific port; the default mode is Disable. Also display current status of per port.
Display per port list.
142
User's Manual of FGSW-Series
Figure 4-9-6 appears.
