4.9.3.1 IGMP Snooping Settings

This page allows you to configure the IGMP Snooping settings for Managed PoE+ Switch as the screen in
appears.
The page includes the following fields:
Object
•
IGMP Snooping State
• Version
• IGMP Group Aged Out
• GMI (10-65535)
• Router Aging Time
(10-65535)
• IGMP Immediate Leave
Button
: press this button to take effect.
Figure 4-9-17: IGMP Snooping Settings Configuration Page Screenshot
Description
This column provides configuring enable or disable the IGMP Snooping
function.
This column provides selecting the IGMP Snooping operation version; the
default version is IGMPv3 and available options are IGMPv1, IGMPv2 and
IGMPv3.
This column provides configuring enable or disable the IGMP Group Aged Out
function.
This column provides configuring the value for Group Member Interval Time; the
default value is 100 seconds and the available range is 10 to 65535 seconds.
After the dynamic Group is established, the time is used to ask if there is
member.
This column provides configuring the value for Router Aging Time; the default
value is 100 seconds and the available range is 10 to 65535 seconds.
The time the dynamic Router Port exists, and if the Query packet is not
continuously received, the dynamic Router Port clears.
This column provides configuring enable or disable the IGMP Immediate Leave
function.
155
User's Manual of FGSW-Series
Figure 4-9-17
