4.6.4 QoS Out Queue Aging

This page allows you to configure the QoS Out Queue Aging settings for all switch ports as the QoS Out Queue Aging screen in
Figure 4-6-4 appears.
The page includes the following fields:
Object
• Out Queue Aging Time
• Fast Aging Time Enable
•
Port Selection
•
Q0 ~ Q7
• Port No.
• Q0-Q7
Button
: press this button to take effect.
Figure 4-6-4: QoS Out Queue Aging Configuration Page Screenshot
Description
Set Out Queue Aging time and the available range is 0-255.
Set the conversion unit of aging time from 100ms to 1.638ms.
Select specific port for QoS Out Queue Aging settings.
Enable or disable the QoS Out Queue Aging settings.
Display per port list.
Display per port QoS Out Queue Aging settings.
