4.9.1.6 STP Loop Detect Settings

This page allows you to configure the STP Loop Detect settings for Managed PoE+ Switch as the screen in
appears.
The page includes the following fields:
Object
STP Loop Detect Setting
• SFP Loop Detection State
• Block Release Time
Loop Detect Port State
• Port
• State
Buttons
: press this button to take effect.
: press this button to refresh current status.
Figure 4-9-10: STP Loop Detect Settings Configuration Page Screenshot
Description
This column provides configuring enable or disable the SFP Loop Detection
State function on specific port; the default mode is Enable.
This column providesconfiguring the Block Release Time settings; the
available range is 1 to 255.
Display per port list.
Display per port state information.
147
User's Manual of FGSW-Series
Figure 4-9-10
