4.6.9 TCP/UDP Port-based QoS

This page allows you to configure the TCP/UDP Port-based QoS settings for Managed PoE+ Switch as the TCP/UDP
Port-based QoS screen in
The page includes the following fields:
Object
• TCP/UDP Port-based
Priority
• User Defined TCP/UDP
Port Number
Button
: press this button to take effect.
Figure 4-6-9 appears.
Figure 4-6-9: TCP/UDP Port-based QoS Configuration Page Screenshot
Description
Provides Q0 to Q7 and Drop options for the following protocols.
FTP/SSH/TELNET/SMTP/DNS/BOOTP/DHCP/TFTP/HTTP_0.1/POP3/NEWS/
SNTP/NETBIOS_0.1.2/IMAP_0.1/SNMP_0.1/HTTPS/User Defined A/ User
Defined B/ User Defined C/ User Defined D.
Provides four functions for setting.
User Defined A (Port #)
User Defined B (Port #)
User Defined C (From Port# To Port#)
User Defined D (From Port# To Port#)
107
