4.4.1 Port Configuration

This page displays current port configurations and each port can also be configured here as the Port configuration screen in
Figure 4-4-2
appears.
The page includes the following fields:
Object
• Port Selection
State
Speed/Duplex
Auto Negotiation
• Flow Control
• Address Learning
• Name
• Port
Setting
• State
Speed/Duplex
Figure 4-4-2 : Port Configuration Page Screenshot
Description
Select specific port for further configuration.
Enable or disable specific Port function.
Change specific Port speed duplex and the available optios are shown below:
Top Speed/10M Half/10M Full/100M Half/100M Full/1000M Full.
Enable or disable auto negotiation function on specific Port.
Enable or disable flow control function on specific Port.
Enable or disable address learning function on specific Port.
Configure the Managed PoE+ Switch per port description information on this
page; the maximum length is 20 characters.
Display per port list.
Display per port current operation setting mode.
Display per port current speed/duplex setting mode.
72
User's Manual of FGSW-Series
