4.7.2.5 Advanced

The Access Control List configuration includes the function that is based on IPv6 address as the screen in
The page includes the following fields:
Object
• Name
• Source MAC Address
• Source MAC Mask
• Destination MAC Address
• Destination MAC Mask
Figure 4-7-7: ACL Profile List-IPv6 Configuration Page Screenshot
Description
Display the ACL profile name.
Configure the Source MAC Address.
Configure the Source MAC Mask and the available options are shown below:
FF:FF:FF:FF:FF:FF
FF:FF:FF:00:00:00
FF:FF:00:00:00:00
Configure the Destination MAC Address.
Configure the Destination MAC Mask and the available options are shown
below:
FF:FF:FF:FF:FF:FF
FF:FF:FF:00:00:00
FF:FF:00:00:00:00
116
User's Manual of FGSW-Series
Figure 4-7-7appears.
