4.10.1 MIB Counter

This page allows you to configure the MIB Counter settings for Managed PoE+ Switch as the screen in
The page includes the following fields:
Object
•
Port No.
Receive
• Packets
• Bytes
Transmit
• Packets
• Bytes
• Action
• Detail
Buttons
: press this button to refresh current MIB counter information.
: press this button to clear current MIB counter information.
Figure 4-10-2: MIB Counter Configuration Page Screenshot
Description
This column provides display per port list.
This column provides displaying per port traffic in packets receive counters.
This column provides displaying per port traffic in bytes receive counters.
This column provides displaying per port traffic in packets transmit counters.
This column provides displaying per port traffic in bytes transmit counters.
This column provides click to select all port or specific port for refresh or clear
current MIB counter information.
This column provides click to enter advanced per port MIB counter web page.
177
User's Manual of FGSW-Series
Figure 4-10-2 appears.
