4.9.10.2 LLDP Port Setting

This page allows you to configure the LLDP Port settings for Managed PoE+ Switch as the screen in
The page includes the following fields:
Object
•
Port Selection
• Admin Status
• Port Description
Figure 4-9-33: LLDP Port Settings Configuration Page Screenshot
Description
This column provides selecting specific port for LLDP Port Settings function.
This column provides displaying and selecting the Admin status of LLDP and
the available options are :
Disable
The Managed PoE+ Switch will not send out LLDP information, and will drop
LLDP information received from neighbors.
Rx Only
The Managed PoE+ Switch will not send out LLDP information, but LLDP
information from neighbor units is analyzed.
Tx Only
The Managed PoE+ Switch will drop LLDP information received from
neighbors, but will send out LLDP information.
Tx & Rx
The switch will send out LLDP information, and will analyze LLDP information
received from neighbors.
This column provides displaying and configuring enable or disable the Port
Description function.
When enabling the "Port Description", the LLDP information will be transmitted.
174
User's Manual of FGSW-Series
Figure 4-9-33 appears.
