4.7.2.4 IPv6

The Access Control List configuration includes the function that is based on IPv6 address as the screen in
The page includes the following fields:
Object
• Name
• Source IPv6 Address
• Source IPv6 Mask
• Destination IPv6 Address
• Destination IPv6 Mask
• Ingress Port
• Action
Button
: press this button to take effect.
Figure 4-7-6: ACL Profile List-IPv6 Configuration Page Screenshot
Description
Display the ACL profile name.
Configure the Source IPv6 Address.
Configure the Source IPv6 Mask and the available options are shown below:
FFFF:FFFF:FFFF:FFFF:FFFF:FFFF:FFFF:FFFF
FFFF:FFFF:FFFF:FFFF:FFFF:FFFF:0000:0000
FFFF:FFFF:FFFF:0000:0000:0000:0000:0000
FFFF:0000:0000:0000:0000:0000:0000:0000
Configure the Destination IPv6 Address.
Configure the Destination IPv6 Mask and the available options are shown
below:
FFFF:FFFF:FFFF:FFFF:FFFF:FFFF:FFFF:FFFF
FFFF:FFFF:FFFF:FFFF:FFFF:FFFF:0000:0000
FFFF:FFFF:FFFF:0000:0000:0000:0000:0000
FFFF:0000:0000:0000:0000:0000:0000:0000
Select the specific port as Ingress port.
Select the action and the available options are shown below:
Drop
Type 1
Type 2
115
User's Manual of FGSW-Series
Figure 4-7-6
appears.
