4.10.3 LLDP Remote MIB

This page allows you to configure the LLDP Remote MIB settings for Managed PoE+ Switch as the screen in
appears.
The page includes the following fields:
Object
•
Port
LLDP Remote System MIB Information
• Enrty
• Chassis ID
• Port ID
• Rx TTL
• Action
Button
: press this button to find LLDP Remote MIB information of specific port.
Figure 4-10-5: LLDP Remote MIB Page Screenshot
Description
This column provides selecting specific port for LLDP Remote MIB function.
This column provides displaying entry number of LLDP Remote MIB
information.
This column provides displaying chassis ID of LLDP Remote MIB information.
This column provides displaying Port ID of LLDP Remote MIB information.
This column provides displaying Rx TTL of LLDP Remote MIB information.
: press this button to delete specific LLDP Remote MIB information.
