• Priority
• GVRP Forward
• Action
Buttons
: press this button to create a new specific VLAN group.
: press this button to edit specific VLAN group.
: press this button to delete specific VLAN group.
Press the button to edit per member port state and the screen in
Figure 4-5-5: Edit VLAN Tag-based Entry Config Configuration Page Screenshot
The page includes the following fields:
Object
• VLAN Name
• VID
• Priority
• GVRP Forward
Display the Priority state of specific VLAN group.
Display the GVRP Forward state of specific VLAN group.
: press this button to edit specific VLAN group.
: press this button to delete specific VLAN group.
Description
Display and configure the name of specific VLAN group; the maximum length is 20
characters.
Display and configure the VLAN ID of specific VLAN group.
Display and configure the Priority value of specific VLAN group.
Display and configure the GVRP Forward mode
88
User's Manual of FGSW-Series
Figure 4-5-5 appears.
