Buttons
: press this button to take affect.
: press this button to delete.
The SNMP group needs to create the view before group create.

4.2.4.3 SNMP User Table

The SNMP User Table provide to set SNMP user settings, the configured column is used to input the user name, select the
group name and input the password for Auth-Protocol MD5 /Priv-Protocol DES. The screen in
The page includes the following fields:
Object
User Name
Group Name
Auth-Protocol MD5
Priv-Protocol DES
Buttons
: press this button to take affect.
: press this button to delete.
Create SNMP views and groups are required to use, the security level of the user needs to be the same
as the security level of the group.
Figure 4-2-8: SNMP User Table Configuration Page Screenshot
Description
Configure the Managed PoE+ Switch user name information on this page, the
maximum length is 20 characters.
Select the exist SNMP group.
Set the authorization password with using the MD5 authentication level, the
available length is 8 to16 characters.
Set the authorization password with using the standard DES private encryption
protocol, the available length is 8 to16 characters.
55
User's Manual of FGSW-Series
Figure 4-2-8
appears.
