1.4 Product Features

Physical Port
■ 8/16/24 10/100BASE-TX RJ45 copper ports with IEEE 802.3at/af PoE+ injector function
■ 2 10/100/1000BASE-T Gigabit RJ45 copper ports (Combo Interface)
■ 2 1000BASE-X mini-GBIC/SFP slots (Combo Interface)
■ RJ45 console interface for switch basic management and setup
■ Reset button for system factory default
Switching
■ Hardware-based 10/100Mbps, half/full duplex and 1000Mbps full duplex mode, flow control and auto-negotiation, and
auto MDI/MDI-X
■ Features Store-and-Forward mode with wire-speed filtering and forwarding rates
■ IEEE 802.3x flow control for full duplex operation and back pressure for half duplex operation
■ Automatic address learning and address aging
■ Supports CSMA/CD protocol
Power over Ethernet
■ Complies with IEEE 802.3at Power over Ethernet Plus
■ Complies with IEEE 802.3af Power over Ethernet
■ Up to 8/16/24 ports of IEEE 802.3af/802.3at devices powered
■ Supports PoE Power up to 30 watts for each PoE port
■ 120/240/370-watt PoE budget
■ Auto detects powered device (PD)
■ Circuit protection prevents power interference between ports
■ Remote power feeding up to 250m via extend mode
■ PoE Management
− Per port PoE function enable/disable
− Per Port PoE operation mode selection
− Per PoE port power budget control
− PD classification detection and PoE consumption usage status
■ Intelligent PoE features
− PD alive check
− PoE port sequence
− PoE schedule
Layer 2 Features
■ Prevents packet loss with back pressure (half-duplex) and IEEE 802.3x pause frame flow control (full-duplex)
■ High performance Store and Forward architecture, runt/CRC filtering eliminates erroneous packets to optimize the
network bandwidth
■ Supports VLAN
- Port-based VLAN, up to 10/18/26 VLAN groups
- IEEE 802.1Q tagged VLAN
