4.9.8 Neighbor MAC ID Settings

On this page. Neighbor MAC ID Settings is used for searching for switch MAC Address ID from each port of Managed PoE+
Switch, according to send period setting for sending out the neighbor information packets. The Managed PoE+ Switch will add
or update the MAC Address ID when receiving the neighbor information packets; also the switch neighbor MAC address ID
information can be obtained by using the UDP NetCMD tools. The Neighbor MAC ID Settings Configuration screen in
4-9-28
is shown below.
The page includes the following fields:
Object
Status
Send Period
Aging Time
Neighbor MAC ID Information
Port No.
MAC Add
Aging Time
Buttons
: press this button to take effect.
: press this button to refresh current status.
Figure 4-9-28: Neighbor MAC ID Settings Configuration Page Screenshot
Description
This column providesconfiguring enable or disable the Neighbor MAC ID
settings function.
This column provides configuring Send Period settings; the default value is 3
and the available range is 1 to 65535. Unit is second.
This column provides configuring Aging Time settings; the default value is 6 and
the available range is 1 to 65535. Unit is second.
Display the per port list.
Display the MAC address from per port list.
Display the Aging time from per port list.
168
User's Manual of FGSW-Series
