4.9.3.3 IGMP Snooping Groups

This page allows you to configure the IGMP Snooping Groups settings for Managed PoE+ Switch as the screen in
appears.
Figure 4-9-19: IGMP Snooping Groups Settings Configuration Page Screenshot
The page includes the following fields:
Object
IGMP Snooping Static Group Configuration
•
Group Address
• Priority
• Member Port
IGMP Snooping Group Information
• Group
• State
• Member Port
• Priority
• Action
Button
: press this button to take effect.
Description
This column provides configuring the Group Address.
This column provides configuring the value for Priority, the default value is 0 and
the available range is 0 to 7.
This column provides configuring to select specific ports for IGMP Snooping
Groups settings.
Display per group list.
Display per group status.
Display per group member port status.
Display per group priority status.
: press this button to edit specific IGMP Snooping Groups Settings.
: press this button to delete specific IGMP Snooping Groups Settings.
157
User's Manual of FGSW-Series
Figure 4-9-19
